3. Uses of the HEYNER® MultiFix Twist
type of use

installation

rear facing
forwards facing
Depending on the height and weight of your child, the child car seat can be used facing forwards
and backwards.
WARNING:
The HEYNER MultiFix TWIST must be used rear facing: until your child is at least 15 months old or
more than 83 cm tall.
3.1. Usage of the infant pad
The infant insert includes a head cushion and an infant wedge-shaped pillow.
The cushions are intended for the special protection of small children with a weight of
9 kg - 18 kg. We recommend removing these only when the child is too big for them, at least if
the child weighs 18 kg.
Use the provided wedge-shaped pillow until your child weighs 13kg. It supports the flat reclining
position recommended by orthopaedist.
27
height of the child age reference
ca <4 years
<18 kg
40cm - 105cm
9-18 kg 15 months
83cm-105cm up to 4 years
4. Installation
NOTE:
Up to a height of at least 83 cm and until your child is at least 15 months old, they MUST be
transported rear facing. Accident statistics show that your child's rear facing transportation is
the safest. Therefore, we recommend that you use the child seat as long as possible backwards.

4.1. Installation of the HEYNER MultiFix TWIST in the vehicle

The current version can be found at www.heyner-germany.de.
Please also read the operating instructions of the vehicle manufacturer.

4.2. Positioning on the vehicle seat

Before placing the HEYNER® MultiFix TWIST on the car seat, fasten if necessary the two
provided installation aids (IH) to the ISOFIX mounting points (IA) in your car.
The ISOFIX mounting points are located between
the seat and the backrest of the car seat.
Always unfold the support device until it snaps into
place at the front.
NOTE: Do not place objects in the leg area in front
of the child car seat.Release the lock of the ISOFIX
connectors (IK) by simultaneously pressing the
locking button and pulling out both locking arms
out of the ISOFIX retract loop.
Check the safety indicators (IT). These must both
be RED. If the safety indicators (red) are not visible,
press the green release tabs until you hear an
audible << click >>.
Hold the child seat with both hands and push the
two ISOFIX-Connectors (IK) firmly in the slide-in
guides until the two ISOFIX-locking arms (IA) enga-
ge. You hear a clear >> click <<sound.
