1-2 PRECAUTIONS

Do not install the unit on an
unstable surface.
Do not allow the infrared beam
from another detector to reach
the receiver.
Receiver
Receiver
(another
detector)

1-3 PARTS IDENTIFICATION

Beam blocking plate
FUNCTION SETTING SECTION >>
<Transmitter>
T
Power indicator
Do not install the pole in a
location where sufficient
stability can not be ensured.
Install the unit at a height
where an object can be
detected without fail.
Transmitter
Transmitter
(another
detector)
Transmitter
Cover
Optical lens
Horizontal alignment dial
Vertical alignment dial
Terminals
Vertical alignment dial
Horizontal alignment dial
Optical lens
Cover lock screw
<Receiver>
R
Monitor jack (+)
Monitor jack (-)
Alarm indicator
Dip switch
Do not install the unit in a
location where trees, leaves, or
other objects that may swing in
the wind and block the beam.
The pole size should be
34 - 48 mm
( 1.34 - 1.89 inch).
Receiver
This symbol indicates prohibition.
Main unit
View finder
Main unit base
Mounting screw holes
Tamper button
View finder
ACCESSORIES >>
3×6 self tapping for pole bracket: 4
4×20 self tapping for wall mounting
(with rubber washer): 4
M4×30 screws for pole mounting
(with rubber washer): 8
-2-
Do not install the receiver in a
location where it is exposed to
direct sunlight.
[Receiver]
Install the unit at least 1 m (3.3
ft.) away from the wall or fence
that may be running parallel to
the beam.
At least 1 m (3.3 ft.)
This symbol indicates recommendation.
Chassis
Cut bush
for wiring
Banding bands: 4
Pole brackets: 4
(attached on the back of the cover)
Pole mounting
screw holes
Wall mounting
screw holes
Pole mounting
screw holes
U-brackets: 4
Beam blocking plate: 2
