Introduction; What's In The Box; General Information - Telecom Behnke myintercom Plus Instructions Manual

myintercom Plus IP video door intercom Instructions
GB

Introduction

1. INTRODUCTION

1.1. What's in the box

▸
myintercom Plus IP video door station
▸
User instructions
▸ "Setup" leaflet
▸ For version with two-wire technology:
• 2 coaxial adapters
• 2-wire receiver for installation in the
protected indoor area

1.2. General information

Features
The myintercom IP video door station is a
compact device with integrated camera,
loudspeaker and microphone. It has up to
three call buttons, which are equipped with
illuminated nameplates.
The integrated tamper contact, together with
a separately available, remote security relay,
fulfils increased security and convenience
requirements.
Thanks to the integrated echo suppression
(acoustic echo canceller), a full duplex voice
connection exists between the smartphone or
tablet PC and the door. The last 20 events are
saved in the door station with a camera image
and the time so that no call from the door is
missed.
The myintercom technology also enables the
existing infrastructure to be used for video
door communication. With myintercom, the
44
smartphone or tablet PC becomes the remote
terminal for the myintercom IP video door
station. With the smartphone or tablet PC, the
user can see who is at the door, can speak to
them and if necessary can open the door from
their smartphone or tablet PC by pressing a
button. To this end the smartphone or tablet
PC is logged into the local WLAN.
In order to be able to accept the call from the
door when you are out, away from home or
the office, the video door station must be
activated via www.myintercom.de/activate.
The image and tone (sound) transmission then
takes place via the internet (WLAN / 3G / LTE).
In poor light conditions the lighting in the
video door station can be activated during the
call from a smartphone or tablet PC.
www.behnke-online.de
