Gong connections
Isolated connections for three door gongs
(rating 30VDC / max. 1A), which are activated
at the press of a button. See Chapter 2.4 Door
opener/ Relay/ Gong.
Gong switch
The gong switch can be used to set the
number of gong strokes when the button is
pressed. See Chapter 2.5 Setting the door
gong.
Anti-tamper contact
See Chapter 1.2 General information.
Supply socket of the security relay
See Chapter 3.1 security relay.
Connection socket for security relay
See Chapter 3.1 security relay.
Connection for door opener button
See Chapter 2.4 Door opener/ Relay/ Gong.
www.behnke-online.de
myintercom Plus IP video door intercom Instructions
Electronics of the door station with two-wire
technology
Connection socket for coaxial cable
Data transmission and supply option for the
myintercom Plus video door station. See
Chapter 2-wire technology on page 54.
Attention: Simultaneous use of a 2-wire trans-
mitter and the ethernet is not allowed.
