Multi-button extension for SIP intercom V3.0
GB

Introduction

IntroductIon
1.

1.1. What's in the box

▸
Multi-button electronics for SIP intercom
stations V 3.0 for mounting on Behnke
frames 20/21-4310, 20/21-4403, 20/21-
4611A, 20/21-4622A, 20/21-4623, 50-4903,
50-4906 (Please note: When installing
frames, the appropriate counter plates
must be open), 40-0013B-IP (this elec-
tronics can manage up to 50 call buttons,
use only in conjunction with 20-0001B-IP
/0014B-IP/0016B-IP). For 20-0001B-IP
/0014B-IP, clarify frame compatibility in
advance. For more than 25 call buttons,
expand the 40-0013B-IP with the additional
board 40-0009-IP.
▸ This manual
16

1.2. General Information

Performance Features
The Behnke multi-button electronics for SIP
intercom stations V3.0 is a VoIP intercom
station with acoustic echo cancellation for
full-duplex hands-free speech in best speech
quality. The voice connection is made via
Voice over IP (VoIP) according to the SIP stan-
dard over the connected Ethernet LAN either
with the help of a SIP-capable telephone
system, a SIP provider or via direct dialling
of an IP address (Please note: please make
sure the end device used as remote station
(in-house) also supports this function).
Configuration as well as software updates are
performed via a web browser, power is sup-
plied via the LAN (PoE). The intercom stations
allow the connection of external, floating
direct call buttons and have two freely con-
figurable switching outputs for door opening,
call indication or other switching functions.
System requirements
Please observe the following requirements
when installing Behnke SIP intercom stations:
▸
Network infrastructure with POE up to the
Behnke station
▸ Network-compatible PC in this network
▸
SIP account, SIP server
▸
When operating without SIP account, SIP
server:
End devices that support IP address dialling
and allow operation without SIP account,
SIP server, SIP end devices that support
H.264 communication. Function should be
