Technical features

6. TECHNICAL FEATURES
Standard features of the IP video door
intercom:
▸
IP camera
▸
Lighting ring
▸ Loudspeaker
▸ Microphone
▸
Acoustic echo canceller (AEC)
▸
Models with 1–3 call buttons possible
▸
Illuminated nameplates
(up to 3 nameplates possible)
▸ PoE compatible
▸
Tamper protection
▸
1 floating door opener relay, load rating
30 V DC/maximum current 1 A
▸
1 floating additional relay, load rating
30 V DC/maximum current 1 A
▸ 3 floating door gong relays, load rating
30 V DC/maximum current 1 A
▸
1 door opener (12 V DC/AC max. 9 W) can be
supplied directly
Optics
▸ ¼" CMOS sensor
▸
Focal length 2.9 mm, F2.0
▸
Horizontal picture angle 84°
▸
Vertical picture angle 48°
▸
Lighting 1.2 – 100000 Lux, F2.0,
0 Lux with LED switched on
▸ Shutter speed 1/24500s to 1/6s
Video
▸
Motion-JPEG, H.264 compression
▸
Axis Communications HDTV image sensor
▸ Proprietary video transmission to the
myintercom app
74
▸
Resolution, frame rate and quality are
adjusted dynamically to the network
connection
Audio
▸ Proprietary audio transmission to the
myintercom app
▸
Integrated acoustic echo suppression (AEC)
▸
Full-duplex
▸
Amplifier output 1 watt
Network
▸
IPv4, HTTP, HTTPS*, SSL/TLS*, QoS Layer 3
DiffServ, Bonjour, UPnP, SNMPv1/v2c/v3
(MIB-II), DNS, NTP, RTSP, RTP, TCP, UDP,
IGMP, RTCP, ICMP, DHCP, ARP, SOCKS.
* This product contains software, which has
been developed by the Open SSL project in
the Open SSL Toolkit (www.openssl.org)
▸
HTTPS encryption
Add-on modules
▸ Model variant of the myintercom Plus video
door station with card reader (only one call
button possible)
▸
Model variant of the myintercom Plus video
door station with two-wire receiver
▸ Optional security relay
Connection
▸
Supply through PoE to IEEE 802.af-2003 or
through two-wire technology
▸
Power input: ~5.8 W
