User instructions
Master: 1-2-3-4-5-6-7-8.
Manager: 123456.
Users from 02 to 49: 02-020202, 03-030303, and so on. They always open with time delay if
set.
Override users from 50 to 59: 50-505050, 51-515151, and so on. They always open without time
delay.
This user manual describes the standard programming. According such programming and unless
different requests while ordering the product, an opening can be performed by entering sigle
users codes (no dual mode) and without time delay. Thus, the user manual must be adapted
according the configuration selected.
It is strongly recommended to change the default codes before using the lock.

Overview functions

Lock opening
After entering an opening code, it is possible to open the lock within 3 seconds. It's no necessary
instead with motorized locks: in this case indeed, the motor moves the bolt which remains in
opening position for about 8 seconds before returning in closing position. In the manual closing
version instead, the bolt can be closed by pressing
Penalty
Four consecutive wrong codes initiate a four minutes penalty time. During this period, LCD
shows the message "PENALTY" and no operation is allowed.
Time Delay
Programmable time delay in between 0 and 99 minutes. Programmable opening window in
between 1 and 19 minutes.
Dallas keys
Available as option for Manager and users (not for Master).
Power supply
Lock can be powered with:
• an ALKALINE 9V battery located in the battery compartement below the keypad;
• an internal battery box provided by Tecnosicurezza (6 ALKALINE 1.5 batteries);
• A power adapter (ref. N1212) with power supply interface (ref. T6005/W or T6005) both
provided by Tecnosicurezza.
8 di 22
key for few seconds.
