Description
NO.
Product code
1 Front Grill
2 Drainage Joint
3 Front Side Plate Sub-Assy
4 Front Side Plate Sub-Assy
5 Insulated Board (Cover of Electric Box)
6 Cabinet
7 Axial Flow Fan
8 Brushless DC Motor
9 Motor Support Sub-Assy
10 Base Plate Sub-Assy
11 Compressor and Fittings
12 Retaining Plate Sub-Assy
13 Supporting Board
14 Tube Clip
15 Litter Liquid Pipe(Rubber Loop)
16 Supporting Board Sub-assy
17 Electrical Heater
18 Supporting Board Sub-assy
19 Accumulator
20 Rubber Band
21 Oil Separator Sub-Assy
22 Inhalation Tube Sub-Assy
23 Electromagnetic Valve Sub-assy
24 Electric Expansion Valve Sub-Assy
25 Electric Expand Valve Fitting
26 Electromagnetic Valve Sub-assy
27 Valve Support Assy
28 Right Side Plate
29 Wiring Cover Sub-assy
30 Handle Assy
31 Valve Cover
32 Wiring Clamp
33 Electric Expand Valve Fitting
34 Electric Expand Valve Fitting
35 Electric Expand Valve Fitting
36 Electric Expand Valve Fitting
37 Electric Box Assy
38 Magnet Coil
39 fusible plug
40 Magnet Coil
41 Magnet Coil
42 Rear Grill
43 Condenser Assy
44 Toggle Switch Sheath
45 Condenser support plate
46 Connection Pipe Sub-assy
47 Tube Clip
48 Pressure Protect Switch
49 Securing clip
50 Gas-liquid Separator
51 Clapboard Sub-Assy
52 Magnet Coil
53 Top Cover
54 4-way Valve Assy
55 Handle
56 Electrical Heater
57 Left Side Plate
58 Electric Box Cover
59 Main Board
60 Radiator
61 Terminal Board
62 Terminal Board
Above data is subject to change without notice.
Installation and Maintenance
Part Code
MULTIU36HP230V1DO
CB228W09600
016004060003
26113009
017101060008P
017101060008
20113003
01435007P
10335014
1570280000409
017012060043
017000060108P
00204100030
017032000118P
0189410008902P
021400053P
76518218
017056000201P
7651521242
017056060224P
07424100031
76510006
030079060004
030010060207
030025060016
030026060045
43000345
030025060014
030163060005
0131410002702P
000224060003
000223000003
200087000005
26115004
43000344
4300034411
4300034412
4300034414
100002060835
4304000404
035222000004
4304000449
4304000447
1574100007
011002060110
26905207
01895242
030062060112
0214000521
4602000603
02263702
07223048
017021060106
4300040029
0125500901P
030152060041
26233053
7651000417
01305064P
012020060060
300027060190
4901800000203
42200006001201
422000060015
Qty
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
1
1
1
1
5
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
3
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
4
41
