Steps
20.Remove supporting board and supporting board sub-assy
Remove the screws connecting the gsupporting
board and supporting board sub-assy and remove the
gsupporting board and supporting board sub-assy.
21. Remove compressor
Remove the 3 foot nuts fixing compressor and then lift
the compressor upwards to remove the compressor
and damping cushion.
Note:
Keep the ports of discharge pipe and suction pipe from
foreign objects.
22.Remove compressor mounting plate sub-assy
Remove the 4 foot nuts fixing compressor mounting
plate sub-assy and chassis, to remove the compressor
mounting plate sub-assy.
56
Procedure
Service Manual
supporting board
supporting
board sub-assy
compressor
compressor mounting
plate sub-assy
Installation and Maintenance
