Gree Multi+ Ultra MULTIU18HP230V1DO Service & Parts Manual page 7

Service Manual
Cross-sectional Area of Power Cable Conductor
Recommended Power Cable(Core)
Connection Pipe Connection Method
Not Additional Gas Connection Pipe Length
Connection Pipe Gas Additional Charge
Outer Diameter of Liquid Pipe1(GREE Allocation)
(Metric)
Outer Diameter of Liquid Pipe2(GREE Allocation)
(Metric)
Outer Diameter of Liquid Pipe3(GREE Allocation)
(Metric)
Outer Diameter of Liquid Pipe4(GREE Allocation)
(Metric)
Outer Diameter of Liquid Pipe4(GREE Allocation)
(Metric)
Outer Diameter of Gas Pipe1(GREE Allocation)
(Metric)
Outdoor
Outer Diameter of Gas Pipe2(GREE Allocation)
Unit
(Metric)
Outer Diameter of Gas Pipe3(GREE Allocation)
(Metric)
Outer Diameter of Gas Pipe4(GREE Allocation)
(Metric)
Outer Diameter of Gas Pipe4(GREE Allocation)
(Metric)
Connection Pipe Max. Height Distance(indoor and
indoor)
Connection Pipe Max. Height Distance(indoor and
outdoor and indoor up)
Connection Pipe Max. Height Distance(indoor and
outdoor and outdoor up)
Max. equivalent connection pipe length(outdoor to
last indoor)
Connection Pipe Max. Length Distance(total lenght)
The above data is subject to change without notice; please refer to the nameplate of the unit.
Technical Information
sq in 0.013
N 3
- Flare Connection
ft 131.2
oz/ft. 0.2
inch 1/4
inch 1/4
inch 1/4
inch 1/4
inch /
inch 3/8
inch 3/8
inch 3/8
inch 3/8
inch /
ft 49.2
ft 49.2
ft 49.2
ft 82.0
ft 246.1
0.013
3
Flare Connection
131.2
0.2
1/4
1/4
1/4
1/4
1/4
3/8
3/8
3/8
3/8
3/8
49.2
49.2
49.2
82.0
262.5
5
