Change for life
Installation & Owner's Manual
Original Instructions
Split Type Wall-mounted Air Conditioner
Model:
MULTIU18HP230V1DO
MULTIU24HP230V1DO
MULTIU36HP230V1DO
MULTIU42HP230V1DO
Thank you for choosing our product.
Please read this Owner's Manual carefully before operation and
retain it for future reference.
If you have lost the Owner's Manual, please contact your local
distributor or visit www.greecomcomfort.com/resources for the
electronic version.
Advertisement
Table of Contents
Related Manuals for Gree MULTIU18HP230V1DO
Summary of Contents for Gree MULTIU18HP230V1DO
- Page 1 Change for life Installation & Owner's Manual Original Instructions Split Type Wall-mounted Air Conditioner Model: MULTIU18HP230V1DO MULTIU24HP230V1DO MULTIU36HP230V1DO MULTIU42HP230V1DO Thank you for choosing our product. Please read this Owner’s Manual carefully before operation and retain it for future reference. If you have lost the Owner's Manual, please contact your local distributor or visit www.greecomcomfort.com/resources for the...
-
Page 3: Table Of Contents
In line with the company’s policy of continual product improvement, the aesthetic and dimensional characteristics, technical data and accessories of this appliance may be changed without notice. CONTENTS GENERAL INFORMATION Conformity And Range The Instructions Before Use Name of Parts Technical Data Outdoor Unit Working Temperature Range Electrical Connections... -
Page 4: Conformity And Range
Explanation of Symbols Indicates a hazardous situation that, if not avoided, will DANGER result in death or serious injury. Indicates a hazardous situation that, if not avoided, could WARNING result in death or serious injury. Indicates a hazardous situation that, if not avoided, may CAUTION result in minor or moderate injury. -
Page 5: The Instructions Before Use
THE INSTRUCTIONS BEFORE USE GENERAL INFORMATION WARNING If you smell something burning or The power supply must be Never cut off or damage power ★ ★ ★ see smoke, turn off the power supply connected to a properly sized and control wiring. If the power and contact an HVAC technician. -
Page 6: Name Of Parts
NAME OF PARTS GENERAL INFORMATION MULTIU18HP230V1DO WARNING If the supply wire is damaged, it must be replaced by the manufacturer or a licensed HVAC technician or a similarly qualified person in order to avoid a hazard. Be sure to disconnect the power supply before cleaning the air conditioner; to avoid an electrical shock. - Page 7 NAME OF PARTS GENERAL INFORMATION MULTIU36HP230V1DO MULTIU42HP230V1DO WARNING If the supply wire is damaged, it must be replaced by the manufacturer or a licensed HVAC technician or a similarly qualified person in order to avoid a hazard. Be sure to disconnect the power supply before cleaning the air conditioner; to avoid an electrical shock.
-
Page 8: Technical Data
TECHNICAL DATA GENERAL INFORMATION MULTIU18HP230V1DO MODE Electrical data Electricity supply 208/230V,60Hz Fuse or circuit breaker Minimum power wire section Size and clearance MODE MULTIU24HP230V1DO Electrical data Electricity supply 208/230V,60Hz Fuse or circuit breaker Minimum power wire section Size and clearance... -
Page 9: Electrical Connections
ELECTRICAL CONNECTIONS INSTALLER MULTIU18HP230V1DO 1. Remove the handle at the right side plate of the An all-pole disconnect switch having a contact outdoor unit (one screw). separation of at least 3mm in all poles should be connected to supply power wiring. - Page 10 ELECTRICAL CONNECTIONS INSTALLER MULTIU24HP230V1DO 1. Remove the handle at the right side plate of the An all-pole disconnect switch having a contact outdoor unit (one screw). separation of at least 3mm in all poles should be connected to supply power wiring. 2.
- Page 11 ELECTRICAL CONNECTIONS INSTALLER MULTIU36HP230V1DO 1. Remove the handle at the right side plate of the An all-pole disconnect switch having a contact outdoor unit (one screw). separation of at least 3mm in all poles should be connected to supply power wiring. 2.
- Page 12 ELECTRICAL CONNECTIONS INSTALLER MULTIU42HP230V1DO 1. Remove the handle at the right side plate of the An all-pole disconnect switch having a contact outdoor unit (one screw). separation of at least 3mm in all poles should be connected to supply power wiring. 2.
-
Page 13: Installing The Outdoor Unit
INSTALLING THE OUTDOOR UNIT INSTALLER Location Caution: Installation Must be Performed in Accordance with the NEC/CEC by Authorized Use bolts to secure the unit to a flat, solid surface. Personnel Only. When mounting the unit on a wall or the roof, make Install the drain fitting and the drain hose sure the support is firmly secured so that it cannot (for model with heat pump only) -
Page 14: Maintenance
Contact a licensed HVAC contractor for installation to avoid any issues that will void the warranty. Any disconnecting and relocation of a unit must be done by a qualified licensed HVAC technician. Ensure that the minimum spacing requirements (below) are adhered to. MULTIU18HP230V1DO MULTIU24HP230V1DO 20 in min... -
Page 15: Check After Installation
CHECK AFTER INSTALLATION INSTALLER Check Items Problems Due to Improper Installation Is the installation secure? The unit may drop, vibrate or make noises May cause unsatisfactory cooling (heating) Has the gas leakage been checked? problems Is the thermal insulation of the unit May cause condensation and water formation sufficient? Is the drainage sufficient? - Page 16 U.S. CONTACT INFORMATION TRADEWINDS, LLC www.greecomfort.com/resources E-mail: info@twclimate.com Contractor Support 888-850-7928 | Mon–Fri 8AM-5PM EDT GREE ELECTRIC APPLIANCES, INC. OF ZHUHAI Add: West Jinji Rd, Qianshan, Zhuhai,Guangdong, China, 519070 Tel: (+86-756) 8522218 Fax: (+86-756) 8669426 E-mail: gree@gree.com.cn www.gree.com CAT NO: GREE_MULTIU_INSTALL & OWNERS_062819...
