8.2 Installation Instruction

8.2.1 Outline and dimension of the outdoor unit
NAME OF PARTS
WARNING
● If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified
person in order to avoid a hazard.
● Be sure to cut off the power supply before cleaning the air conditioner; otherwise electricshock might happen.
● Wetting of air conditioner may cause the risk of electric shock. Make sure not to wash your air conditioner in any case.
● Volatile liquids such as thinner or gasoline will cause damage to the appearance of air conditioner. (Only use soft dry cloth moist cloth clean
the air conditioner cabinet).
● Do not dispose this product as unsorted municipal waste. Collection of such waste separately for special treatment is necessary.
● The temperature of refrigerant circuit will be high, please keep the interconnection cable away from the copper tube.
OUTDOOR UNIT
No. Description
1 Air outlet grille
2 Valve
Note: The above figures are only intended to be a simple
diagram of the appliance and may not correspond to
the appearance of the units that have been purchased
TECHNICAL DATA
MODE
Electrical data
Electricity supply
Fuse or air switch
Minimum power cord section
Size and clearance
L
L
P
P
H
H
OUTDOOR UNIT WORKING TEMPERATURE RANGE
OutdoorsideDB/WB(
Maximum cooling 115°F(46°C)/-
Maximum heating 75.2°F(24°C)/-
24
MULTIU18HP230V1DO MULTIU24HP230V1DO
208/230V,60HZ 208/230V,60HZ
35
AWG10
36 7/21
14 61/64
31 7/64
c )
O
18/24K 1
MULTIU36HP230V1DO
MULTIU42HP230V1DO
208/230V,60HZ
40 60
AWG10 AWG8
36 7/21 40
14 61/64 17 21/64
31 7/64 43 27/64
Service Manual
36/42K 1
2
A
inch
inch
inch
Installation and Maintenance
2
