Service Manual
Steps
17. Remove valve support
Unsolder all spot welds connected with valve support
and then remove the valve support.
Note:When unsoldering the spot weld, wrap the gas
valve and liquid valve with wet cloth completely to
avoid damage to valve due to high temperature.
18. Remove accumulator
Remove the screws connecting the accumulator and
remove the accumulator.
19. Remove gas-liquid separator
Remove the screws connecting the gas-liquid
separator and remove the gas-liquid separator.
Installation and Maintenance
Procedure
valve support
accumulator
gas-liquid
separator
55
