Gree Multi+ Ultra MULTIU18HP230V1DO Service & Parts Manual page 52

MULTIU36HP230V1DO MULTIU42HP230V1DO
Steps
1. Remove the handle and valve cover
Remove the screws connicting the handle with right
side plate and then remove the handle and valve
cover.
2. Remove top cover
Remove the screws connecting the top cover with
outer case, right side plate and left side plate; lift the
top cover upwards to remove it.
3.Remove front side plate
Remove the screws connecting the front side plate
with chassis and middle isolation sheet,and then
remove the front side plate
50
Procedure
front side plate
Service Manual
handle
valve cover
top cover
Installation and Maintenance
