Pro Logic / Neo6; Pro Logic I (Pro Logic Emulation); Mic Check - Loewe INDIVIDUAL SOUND PROJECTOR Service Manual

SP-1

3. PRO LOGIC / NEO6

PRO LOGIC I, II, Neo:6 can be selected from the sub-
menu items.

PRO LOGIC I (PRO LOGIC EMULATION)

PRO LOGIC II
Neo:6
OPT1
OPT2
COAX
Analog1
Analog2
MIC

4. MIC CHECK

The signals input through the microphone are output
via A/D-D/A.
34
TI-DSP
DIR
# 1
ADC
3. PRO LOGIC / NEO6
PRO LOGIC I （PRO LOGIC EMULATION）
PRO LOGIC II
Neo:6
L/R L/R
Ti-DSP
SL/SR SL/SR
# 2
C/- C/LFC
BASS
YSS-930
DAC DAC
LFC
SWFR TXn(beam)
WFL/WFR
4. MIC CHECK
YSS-930 YSS-930
# 1 # 2 # 3
TXn(beam) TXn(beam)
