● Operation Procedure

Writing of CPU

1. Install DSP_FLASHER(YSP).exe into the PC.
2. Before turning on the power to YSP-1100 and PC, con-
nect between RS232C ports with the RS232C cable
(cross cable). (Fig. 1)
RS-232C cable
3. While pressing the reset switch of YSP-1100, connect
the power cable to the AC outlet. (Fig. 1, 2)
* Use a fine tipped pin or the like to push the reset
switch.
4. Start up DSP_FLASHER(YSP).exe, the screen will ap-
pear as shown below.
Bottom view
Bottom view
RS-232C port
Reset switch
Reset switch
Fig. 2
● 操作方法
2. YSP-1100とPCの電源を入れる前に、それぞれのRS232C
Fig. 1
