  • Page 1 Operating Manual Audio Individual Sound Projector...

  • Page 2: Table Of Contents

    Intensity of sound field programmes ...3 Night mode ...3 Bass mode ...3 Audio Balance...3 Using the test sound ...3 Sound menu functions for Loewe TV sets with RS-3C System Interface ...4 Sound mode ...4 Subwoofer...4 Room parameter ...4 Dolby Digital/DTS dynamic range ...4 Sound from Sound Projector ...4...

  • Page 3: Remote Control Assist - Sound Projector Operation

    Special Functions ... (page 4) Loewe TV: Station up/down MENU: select/set Only for specialist staff Sound field programme "Sport" ... (page ) Sound field programme off ... (page )    Loewe TV: Function depending on model ...

  • Page 4: Rear View

    Rear View Microphone input Mains connection Sound input left/right (analogue) AUX3 Subwoofer output (nor for Loewe sound systems) Sound input left/right (analogue) TV Video input AUX1 Optical digital sound input AUX Video input AUX Optical digital sound input AUX1 Component video input AUX...

  • Page 5: Front View & Display

    Front view & Display Volume Input source quieter / louder (TV, AUX 1, , 3) (page 19) (page 19) in Standby (page 13) Night mode (page 3) NIGHT Display Decoder displays (page 1) Volume level display DIGITAL Status display Infrared receiver...

  • Page 6: Welcome

    Welcome Thank you for choosing a Loewe product. We are happy to welcome you as our customer. At Loewe we combine the highest standards of technology, design and user friendliness. This is equally true of TV, DVD, video, audio and accessories. Neither technology nor design is an end in itself, but both are intended to provide our customers with the best possible audio and visual experience.

  • Page 7: For Your Safety

    In this user guide you will initially find out how to set up and operate the combination of the Sound Projector with a Loewe TV set with chassis Digital+ HD100 (L710) or Digital+ HD (L700) with software from V4.x upwards. This combination offers...

  • Page 8: Initial Set-Up

    Install the Sound Projector exactly in the middle of the wall, measured precisely from the left and the right corner. Position in a corner Install the Sound Projector in a corner at an angle of 40º to 50º to the adjoining walls.

  • Page 9: Set-Up Solutions

    You can use the "Floor Stand 5 MU" which can be supplied as an accessory to set up your Sound Projector on the floor in connection with a Loewe TV set. Please ask your Loewe dealer about other set-up solutions.

  • Page 10: Connecting To Loewe Tv Sets With Rs-3C System Interface

    Connecting to Loewe TV sets with RS-232C system interface ➠ Loewe TV sets with Chassis Digital+ HD (L700) are compatible with the Sound Projector with software fromV4.x onwards. Please contact your Loewe dealer if you require a software update. Make the connections as shown here:...

  • Page 11: Connecting To Loewe Tv Sets Without Rs-3C System Interface

    Initial set-up Connecting to Loewe TV sets without RS-232C system interface Make the connections as shown here: Depending on the system, you either make the Analogue AUDIO or the Digital AUDIO connection or both together. Loewe Flat-TV VIDEO Loewe Individual Sound-System (Subwoofer) Power OUT Surr.

  • Page 12: Connecting The Accessories

    Initial set-up Connecting the accessories Make the connections as shown here (example: connection of a Loewe DVD recorder): Depending on the system, either make the Analogue AUDIO or the Digital AUDIO connection. As required, you can connect additional audio sources to the interfaces Optical AUX1/2, TV-COAXIAL, AUDIO IN TV or AUDIO IN AUX3.

  • Page 13: Connecting To The Mains Supply

    You can save up to three sound set-ups. This allows you, for example, to take different listening positions, the actual room or TV positions into consideration when using a Loewe TV with swivel caster control. These sound set-ups can then be requested again as required (page 15, 18).

  • Page 14: Connecting And Setting Up The Microphone

    Initial set-up Connecting and setting up the microphone Using the microphone supplied, the Sound Projector evaluates the test signals it generates and can thus adjust the sound output to your actual room. ➠ Protect the microphone from heat and from direct sunlight.

  • Page 15: Auto Set-Up (Tv Sets With Rs-3C System Interface)

    Sound projector Rotate TV Proceed If the Loewe TV set is equipped with swivel caster control, now use 34 to turn the TV to the required listening position. Sound components wizard Start the acoustic auto setup for the Sound projector now (please also read the manual for this).
  • Page 16 You can save three listening positions and call them up again, for example, to be able to take changing conditions in the listening room into consideration. ➠ Position the microphone at least 1.8 m away from the Sound Projector centred on it on a level surface.

  • Page 17: Auto Set-Up (Tv Sets Without Rs-3C System Interface)

    (page 11,13) and that the microphone is connected and set up correctly (page 14). Settings on TV set On your TV set, (with Loewe TV sets in the "Connection wizard"), set the audio output to HiFi/AV amplifier. Setting user interface language Set the remote control up for TV operation.

  • Page 18: Saving Sound Set-Up

    You can save up to three sound set-ups. This allows you, for example, to take different listening positions, the actual room or TV positions into consideration when using a Loewe TV with swivel caster control. You can than call up these sound set-ups at any time.

  • Page 19: Everyday Use

    6 Change to the menu line below. 34Make changes. ➠ You can also make additional sound settings on Loewe TV sets under the TV menu – Sound. Loading listening position You can call upthe listening position that you saved previously (page 15, 18).

  • Page 20: Tv Sets Without Rs-3C System Interface

    Everyday use TV sets without RS-232C system interface Press the button for a long time. The menu MEMORY appears. MEMORY 1) LOAD  2) SAVE [] / [] : Up / Down [OK] : Enter 56 Select the option LOAD. Confirm OK.

  • Page 21: Selecting Input Mode

    Decoder displays Depending on the input signal source and the surround mode selected, the indi- cators on the display of the Sound Projector light up as follows. PCM When playing back PCM signals. When playing back PCM or Neo:6 signals.

  • Page 22: Playback Of -Channel Signal Sources With Surround Sound

    Everyday use Playback of 2-channel signal sources with surround sound This unit can process -channel signal sources for 5.1 channel playback in such a way that by switching the surround mode, you can enjoy a number of surround sound effects. ➠...

  • Page 23: Intensity Of Sound Field Programmes

    Select Effect.Lvl : MID for normal compression. Select Effect.Lvl : MAX for maximum compression. Bass mode If a subwoofer is available, the Sound Projector is capable of producing the impression of an improved bass performance. The bass performance can also be improved without a subwoofer.

  • Page 24: Sound Menu Functions For Loewe Tv Sets With Rs-3C System Interface

    Sound menu functions for Loewe TV sets with RS-232C System Interface If the Sound Projector is being operated in connection with a Loewe TV set with an RS-3C system interface (page 10), some special menus will appear on the TV set.

  • Page 25: Troubleshooting

    The batteries in the remote control are dead. Remedy Plug the mains cable firmly into the socket on the Sound Projector and then into a 0-40 V 50 Hz socket with protec- tive ground. Wait for approx. 1 hour until the unit has cooled down and then switch it on again.

  • Page 26: Error Messages For Auto Set-Up

    ERROR E-9 Cancelled by user Special functions The Sound Projector has got additional setting options which are only intended for specialist staff. Press button for a long time. The menu SETTINGS appears. ➠ Unless you have sufficient expertise, do not make any changes to the settings in this area, as this may maladjust the unit to the extent that it no longer works properly afterwards.

  • Page 27: Technical Specifications

    RS-3C 9 pin D-SUB AUDIO-LINK 6 pin D-SUB Masthead Loewe Opta GmbH is a public limited company of German law with its Head Office in Kronach. Industriestrasse 11, 96317 Kronach Telephone: + 49 (0)961 / 99-0 Fax: + 49 (0)961 / 99-500 E-mail: ccc@loewe.de...

  • Page 28: Operation Of Additional Devices

    Operation of additional devices Setting the remote control Various Loewe devices can be set to be used with the remote control Assist as follows: Device Loewe TV set with RS-3C Loewe TV set without RS-3C Loewe ViewVision 8106 H Loewe Centros 11x...

  • Page 29: Remote Control Assist - Tv Operation

    DR+: Pause (Start viewing with time shift) Timer list Teletext Volume Switch on/off on standby Switch over to operate TV Radio Digital Switch over to operate Sound Projector Sound mode Select station directly; MENU: numbers or letters AV selection PIP (picture in picture) Menu "ASSIST+"...

  • Page 30: Service

    Fax +7 - 1 14 66 4 85 Estrada Circunvalacao, Email mail@loewe.co.za Quinta do Paizinho, Arm. 5 795-63 Carnaxide, Portugal Tel. +351 -  14 4 17 70 Fax +351 -  14 18 80 93 Email office@videoacustica.pt Россия © by Loewe Opta 07051...
