SP-1

• Details of DIAG menu

With full-bit output specified in some modes, it is possible
to execute 0dBFS output without head margin in each
channel.

1. DSP THROUGH

The signal is not changed into beam and output from
the channel specified by the sub-menu.
When 2CH signals are input, they are distributed as fol-
lows at DSP#1.
L CH ..... FRONT L, SURROUND L, CENTER, LFE
R CH .... FRONT R, SURROUND R
Delay of each channel processed at DSP#1 is invalid.

DSP THR ALL

• All outputs (FRONT L/R, CENTER, SURROUND L/R,
LFE) are provided.

DSP THR FRONT L

• FRONT L output.
• SWFR is output through FRONT L only but not in digital
full bit.
DSP THR CENTER
• CENTER output.
• SWFR is output through CENTER only but not in digital
full bit.
DSP THR FRONT R
• FRONT R output.
• SWFR is output through FRONT R only but not in digital
full bit.
DSP THR SURROUND R
• SURROUND R output.
• SWFR is output through SURROUND R only but not in
digital full bit.
DSP THR SURROUND L
• SURROUND L output.
• SWFR is output through SURROUND L only but not in
digital full bit.
DSP THR LFE
• LFE output.
30
● ダイアグメニュー詳細
1. DSP THROUGH
DSP THR ALL
DSP THR FRONT L
DSP THR CENTER
DSP THR FRONT R
DSP THR SURROUND R
DSP THR SURROUND L
DSP THR LFE
