1.2 Part Names
The illustration below displays part naoes. Details oay vary between product groups.
0.4~2.2kW (Single Phase) and 0.4~4.0kW (3–Phase)
Cooling fan cover
Top cover
(Option)
Inverter body
Front cover (L)
Front cover (R)
Preparing the Installation
Cooling fan
Keypad
Control terminal block
