Summary of Contents for LSIS SV-IS7

  • Page 2 SV-iS7 is the official name for the iS7 series inverters. • This operation manual is intended for users with basic knowledge of electricity and electric • devices. Keep this manual near the product for future reference whenever setting change, maintenance •...
  • Page 3 Safety Information Safety Information Read and follow all safety instructions in this manual precisely to avoid unsafe operating conditions, property damage, personal injury, or death. Safety symbols in this manual Indicates an imminently hazardous situation which, if not avoided, will result in severe injury or death.
  • Page 4 Safety Information This equipment must be grounded for safe and proper operation. • Do not supply power to a faulty inverter. If you find that the inverter is faulty, disconnect the • power supply and have the inverter professionally repaired. The inverter becomes hot during operation.

  • Page 6: Table Of Contents

    Table of contents Table of Contents About the Product ......................1 Preparing for Installation and Operation ............1 1.1.1 Identifying the Product ................. 1 1.1.2 Checking the Product for Defects or Damage .......... 3 1.1.3 Preparing the Product for Installation and Operation ......3 1.1.4 Installing the Product ..................
  • Page 7 Table of contents 3.7.1 Disassembling the Keypad Cover and Keypad ........42 3.7.2 Disassembling the IP54 Front Cover ............43 3.7.3 Mounting the Inverter ................44 3.7.4 Connecting the Power Cables ..............45 3.7.5 Reassembling the IP54 Front Cover and the Keypad ......46 Connecting the Cables....................
  • Page 8 Table of contents 4.12 Setting the Built-in Surge Filter ................75 4.13 Activating or Deactivating the Surge Filter ............. 76 4.13.1 iS7 30–75KW (400 V) Inverters ..............76 4.13.2 iS7 90–375 kW (400V) Inverters ..............76 4.14 Post-Installation Checklist................... 78 4.15 Test Run ........................
  • Page 9 Table of contents 5.8.3 Saving and Monitoring the Fault Trip History ........106 Initializing Parameters ..................108 Basic Functions ......................110 Setting Frequency References ................. 110 6.1.1 Keypad as the Source (KeyPad-1 setting) ..........111 6.1.2 Keypad as the Source (KeyPad-2 setting) ..........111 6.1.3 V1 Terminal as the Source ...............
  • Page 10 Table of contents 7.4.1 Products Rated below 7.5 kW ..............150 7.4.2 Products Rated at 11-15 kW 200 V/400 V and 18.5-22 kW 400 V ..150 7.4.3 Products Rated at more than 30 kW (200 V) / 90 kW (400 V), and 18.5– 22 kW (200 V) / 30–75 kW (200/400 V) ..........
  • Page 11 Bureau Veritas (Marine & Offshore Division) Marine Certification Details 11.3 ABS Marine Certification Details..............228 11.4 Marine Certification Models for SV-iS7 Products ......... 229 12 Using a Single Phase Power Source ..............231 12.1 Single Phase Rating ................... 231 12.2 Power(HP), Input Current and Output Current ...........

  • Page 12: About The Product

    About the Product 1 About the Product This chapter provides details on product identification and part names. To install the inverter correctly and safely, carefully read and follow the instructions. 1.1 Preparing for Installation and Operation 1.1.1 Identifying the Product Check the product name, open the packaging, and then confirm that the product is free from defects.
  • Page 13 About the Product Note1) Optional conduit parts are available for the Enclosed UL Type 1 models (0.75–75 kW products). Note2) Optional built-in DCR is available for the Web application models (0.75–375 kW / type 2/4 products). Note3) To use safety function, please buy 0.75-160kW product including safety option. However 185-375kW product users have to buy safety option and apply to standard products because safety option is not included.

  • Page 14: Checking The Product For Defects Or Damage

    1.1.2 Checking the Product for Defects or Damage If you suspect that the product has been mishandled or damaged in any way, contact the LSIS Customer Support center with the phone numbers listed on the back cover of this manual.

  • Page 15: Part Names

    About the Product 1.2 Part Names The illustration below displays part names. Details may vary between product groups. 1.2.1 Interior and Exterior View (IP 21 Model Types Less than 22 kW [200 V] / Less than 75 kW [400 V])

  • Page 16: Interior And Exterior View (Ip 54 Model Types Less Than 22 Kw [200/400 V])

    About the Product 1.2.2 Interior and Exterior View (IP 54 Model Types Less than 22 kW [200/400 V])

  • Page 17: Interior And Exterior View (Model Types 30 Kw And Up [200 V] / 90 Kw And Up [400 V])

    About the Product 1.2.3 Interior and Exterior View (Model Types 30 kW and up [200 V] / 90 kW and up [400 V]) Note Refer to the installation manual provided with the optional module products before installing communication modules in the inverter.

  • Page 18: Technical Specifications

    Technical Specifications 2 Technical Specifications 2.1 Input and Output Specifications 200 V Class (0.75– 22 kW) Model SV xxx iS7–2x 0008 0015 0022 0037 0055 0075 0110 0150 0185 0220 Normal load 18.5 Applied Motor Heavy load 0.75 18.5 Rated Capacity (kVA) 1.9 12.2 17.5 22.9 28.2...

  • Page 19: Input And Output Specifications 200 V Class (30-75 Kw)

    Technical Specifications 2.2 Input and Output Specifications 200 V Class (30– 75 kW) Model SV xxx iS7–2x 0300 0370 0450 0550 0750 Normal load Applied Motor Heavy load Rated Capacity (kVA) Normal Rated load Current Rated Heavy output load 0–400 Hz (Sensorless-1: 0–300 Hz, Sensorless-2, Vector: 0.1–120 Output Frequency Output Voltage (V) 3-Phase 200–230 V...

  • Page 20: Input And Output Specifications 400 V Class (0.75-22 Kw)

    Technical Specifications 2.3 Input and Output Specifications 400 V Class (0.75– 22 kW) Model SV xxx iS7–2x 0008 0015 0022 0037 0055 0075 0110 0150 0185 0220 Normal load 18.5 Applied Motor Heavy load 0.75 18.5 Rated Capacity 12.2 18.3 22.9 29.7 34.3...

  • Page 21: Input And Output Specifications 400 V Class (30-160 Kw)

    Technical Specifications 2.4 Input and Output Specifications 400 V Class (30– 160 kW) Model SV xxx iS7–2x 0300 0370 0450 0550 0750 0900 1100 1320 1600 Normal load Applied Motor Heavy load Rated Capacity (kVA) Normal Rated load Current Rated Heavy output load...

  • Page 22: Input And Output Specifications 400 V Class (185-375 Kw)

    Technical Specifications 2.5 Input and Output Specifications 400 V Class (185– 375 kW) Model SV xxx iS7–2x 1850 2200 2800 3150 3750 Normal load Applied Motor Heavy load Rated Capacity (kVA) Normal Rated load Rated Current output Heavy load Output Frequency 0–400 Hz (Sensorless-1: 0–300 Hz, Sensorless-2, Vector: 0–120 Hz) Output Voltage (V) 3-Phase 380–480 V...

  • Page 23: Product Specification Details

    Technical Specifications 2.6 Product Specification Details 2.6.1 Control Items Description V/F control, V/F PG, slip compensation, sensorless vector-1, Control modes sensorless vector-2, vector control Frequency Digital command: 0.01 Hz settings resolution Analog command: 0.06 Hz (maximum frequency: 60 Hz) Frequency Digital command: 0.01% of maximum output frequency Control accuracy...
  • Page 24 Technical Specifications Items Description Easy start • Select NPN (Sink) or PNP (Source) mode. Reverse direction • Forward direction operation • operation Reset • External trip • Emergency stop • Jog operation • Multi- Multi-step speed frequency- • Multi-step acc/dec- •...

  • Page 25: Protection Function

    Technical Specifications 2.6.3 Protection Function Items Description Over voltage • Low voltage • Lost command • Over current • Hardware failure • Earth current detection • Cooling fan failure • Inverter overheat • Trips Pre-PID failure • Motor overheat • No motor trip •...
  • Page 26 Technical Specifications Items Description recommended that less than 80% load is applied. IP54 product: -10–40℃ • No ice or frost should be present. Storage -20C–65C (-4–149F) temperature. Relative humidity less than 90% RH (to prevent condensation Ambient humidity from forming) Maximum 1000m above sea level for standard operation.

  • Page 27: Installing The Inverter

    Installing the Inverter 3 Installing the Inverter 3.1 Installation Considerations Inverters are composed of various precision electronic devices, and therefore the installation environment can significantly impact the lifespan and reliability of the product. The table below details the ideal operation and installation conditions for the inverter. Items Description CT load (heavy duty): -10℃–50℃...

  • Page 28: Selecting And Preparing A Site For Installation

    Installing the Inverter Do not allow the ambient temperature to exceed the allowable range while operating the inverter. 3.2 Selecting and Preparing a Site for Installation When selecting an installation location, consider the following requirements: The inverter must be installed on a wall that can support the inverter’s weight. •...
  • Page 29 Installing the Inverter Install the inverter on a non-flammable surface, and do not place flammable material near the inverter. Otherwise, a fire may result. Note Model types with capacities of 30 kW or more require a minimum of 8” clearance above and below the unit.
  • Page 30 Installing the Inverter Ensure that the cable conduits do not obstruct the air flow to and from the cooling fan. • Ensure sufficient air circulation is provided around the inverter when it is installed. If the • inverter is to be installed inside a panel, enclosure, or cabinet rack, carefully consider the position of the inverter’s cooling fan and vents.
  • Page 31 Installing the Inverter If you are installing multiple inverters of different ratings, provide sufficient clearance to • meet the clearance specifications of the larger inverter. The iS7 inverters rated for up to 30 kW may be installed side by side.

  • Page 32: Exterior And Dimensions (Ul Enclosed Type 1, Ip21 Type)

    Installing the Inverter 3.3 Exterior and Dimensions (UL Enclosed Type 1, IP21 Type) SV0008-0037iS7 (200 V/400 V) Units: mm (inch) Inverter Capacity SV0008–0037 iS7 - 2/4 (5.90) (5.00) (11.18) (10.11) (0.70) (7.87) (0.19) (0.19)
  • Page 33 Installing the Inverter SV0055-0075iS7 (200 V/400 V) Units: mm (inch) Inverter Capacity SV0055–0075 iS7 - 2/4 (7.87) (6.92) (13.97) (12.87) (0.74) (8.85) (0.19) (0.19)
  • Page 34 Installing the Inverter SV0110-0150iS7 (200 V/400 V) Units: mm (inch) Inverter Capacity SV0110–0150 iS7- 2/4 214.6 23.6 (9.84) (8.44) (15.15) (13.97) (0.92) (11.18) (0.25) (0.25)
  • Page 35 Installing the Inverter SV0185-0220iS7 (200 V/400 V) Units: mm (inch) Inverter Capacity SV0185–0220iS7- 2/4 243.5 461.6 10.1 (11.02) (9.58) (18.17) (17.51) (0.39) (11.73) (0.25) (0.25)
  • Page 36 Installing the Inverter SV0300-iS7 (200 V, IP00 Type) Units: mm (inch) Inverter Capacity 265.2 SV0300 iS7-2 (11.81) (7.48) (7.48) (22.44) (21.73) (0.39) (10.44) (0.39) (0.39)
  • Page 37 Installing the Inverter SV0370-0450iS7 (200 V, IP00 Type) Units: mm (inch) Inverter Capacity SV0370–0450 281.2 iS7-2 (14.56) (10.63) (10.63) (24.8) (23.97) (0.43) (11.07) (0.39) (0.39)
  • Page 38 Installing the Inverter SV0300-0450iS7 (400 V) Units: mm (inch) Inverter Capacity W1 DCR type 303.2 SV300–450 (11.93) (6.33) 300.1 242.8 594.1 24.1 iS7-4 (11.81) (9.55) (23.38) (22.12) (0.94) (0.39) (0.39) Non-DCR type 271.2 (10.67) (5.78)
  • Page 39 Installing the Inverter SV0550-0750iS7 (200 V, IP00 Type) Units: mm (inch) Inverter Capacity SV0550–0750 723.5 15.5 355.6 iS7-2 (18.3) (15.0) (15.0) (29.52) (28.48) (0.61) (14.0) (0.43) (0.43)
  • Page 40 Installing the Inverter SV0550-0750iS7 (400 V) Units: mm (inch) Inverter Capacity DCR type 373.3 211.5 SV0550–0750 (14.69) (8.32) 370.1 312.8 663.5 631.4 24.1 iS7-4 (14.57) (12.31) (26.12) (24.85) (0.94) (0.39) (0.39) Non-DCR type 312.4 150.6 (12.29) (5.92)
  • Page 41 Installing the Inverter SV0900-1100iS7 (400 V, IP00 Type) Units: mm (inch) Inverter Capacity SV0900–1100 783.5 15.5 422.6 iS7-4 (20.07) (15.0) (13.77) (30.84) (29.88) (0.61) (16.63) (0.43) (0.43)
  • Page 42 Installing the Inverter SV1320-1600iS7 (400 V, IP00 Type) Units: mm (inch) Inverter Capacity SV1320–1600 836.5 15.5 422.6 iS7-4 (20.07) (15.0) (13.77) (33.89) (32.93) (0.61) (16.63) (0.43) (0.43)
  • Page 43 Installing the Inverter SV1850-2200iS7 (400 V, IP00 Type) Units: mm (inch) Inverter Capacity SV1850/ 1078 1043.5 25.5 2200iS7-4 (27.16) (22.87) (20.79) (42.44) (41.08) (1.00) (17.72) (0.55) (0.59)
  • Page 44 Installing the Inverter SV2800iS7 (400 V, IP00 Type) Units: mm (inch) Inverter Capacity W1 1138 1110 SV2800iS7-4 (30.35) (19.69) (19.69) (44.80) (43.70) (0.59) (17.32) (0.51) (0.51) For 280 kW model types, I volts are supplied with the product.
  • Page 45 Installing the Inverter SV3150-3750iS7 (400 V, IP00 Type) Units: mm (inch) Inverter Capacity W1 SV3150/ 1302.5 1271.5 3750iS7-4 (36.30) (22.83) (22.83) (51.28) (50.06) (0.59) (19.49) (0.55) (0.55) For 315-375 kW model types, I volts are supplied with the product.

  • Page 46: Exterior And Dimensions (Ul Enclosed Type 12, Ip54 Type)

    Installing the Inverter 3.4 Exterior and Dimensions (UL Enclosed Type 12, IP54 Type) SV0008-0037iS7 (200 V/400 V) Units: mm (inch) Inverter Capacity 204.2 95.1 SV0008–0037 iS7-2/4 (8.03) (5.0) (16.49) (10.11) (3.74) (8.18) (0.19) (0.19)
  • Page 47 Installing the Inverter SV0055-0075iS7 (200 V/400 V) Units: mm (inch) Inverter Capacity 460.6 88.1 232.3 SV0055–0075 iS7-2/4 (10.0) (6.92) (18.13) (12.87) (3.46) (9.14) (0.19) (0.19)
  • Page 48 Installing the Inverter SV0110-0150iS7 (200 V/400 V) Units: mm (inch) Inverter Capacity 313.1 214.6 590.8 101.7 294.4 SV0110–0150 iS7-2/4 (12.32) (8.44) (23.25) (13.97) (4.0) (11.59) (0.25) (0.25)
  • Page 49 Installing the Inverter SV0185-0220iS7 (200 V/400 V) Units: mm (inch) Inverter Capacity 343.2 243.5 750.8 91.6 315.5 SV0185–0220 iS7-2/4 (13.51) (9.58) (29.55) (17.51) (3.60) (12.42) (0.25) (0.25)

  • Page 50: Frame Dimensions And Weight (Ul Enclosed Type 1, Ip 21 Type)

    Installing the Inverter 3.5 Frame Dimensions and Weight (UL Enclosed Type 1, IP 21 Type) Weight[Kg] Weight[Kg] Weight[Kg] Weight[Kg] Inverter W[mm] H[mm] D[mm] w/ built-in w/ built-in w/ built-in non-DCR Capacity EMC and DCR types SV0008iS7-2/4 SV0015iS7-2/4 SV0022iS7-2/4 SV0037iS7-2/4 SV0055iS7-2/4 SV0075iS7-2/4 SV0110iS7-2/4 17.2...
  • Page 51 Installing the Inverter Weight[Kg] Weight[Kg] Weight[Kg] Weight[Kg] Inverter W[mm] H[mm] D[mm] w/ built-in w/ built-in w/ built-in non-DCR Capacity EMC and DCR types SV0300iS7-4 300.4 SV0370iS7-4 300.4 SV0450iS7-4 300.4 SV0550iS7-4 663.4 SV0750iS7-4 663.4 SV0900iS7-4 SV1100iS7-4 SV1320iS7-4 SV1600iS7-4 SV1850iS7-4 1078 SV2200iS7-4 1078 SV2800iS7-4 1138...

  • Page 52: Frame Dimensions And Weight (Ul Enclosed Type 12, Ip54 Type)

    Installing the Inverter 3.6 Frame Dimensions and Weight (UL Enclosed Type 12, IP54 Type) Weight[Kg] Weight[Kg] Weight[Kg] Weight[Kg] Inverter W[mm] H[mm] D[mm] w/ built-in w/ built-in w/ built-in non-DCR Capacity EMC and DCR types SV0008iS7-2/4 SV0015iS7-2/4 SV0022iS7-2/4 SV0037iS7-2/4 SV0055iS7-2/4 12.8 10.2 12.1 SV0075iS7-2/4...

  • Page 53: Installation Procedures For Ul Enclosed Type12 And Ip54 Type Products

    Installing the Inverter 3.7 Installation Procedures for UL Enclosed Type12 and IP54 Type Products 3.7.1 Disassembling the Keypad Cover and Keypad Loosen the screws that secure the keypad cover and remove the keypad cover. Depress the tab at the top of the keypad and gently lift the keypad from the inverter to remove it.

  • Page 54: Disassembling The Ip54

    Installing the Inverter Depress the tab on the keypad cable connector and disconnect the cable from the back of the keypad. 3.7.2 Disassembling the IP54 Front Cover Loosen the screws that secure the front cover to the chassis. There are 9–13 screws on the cover depending on the model type.

  • Page 55: Mounting The Inverter

    Installing the Inverter Remove the cover by lifting it upwards from the bottom. 3.7.3 Mounting the Inverter Remove the 4 rubber feet from the corners.

  • Page 56: Connecting The Power Cables

    Installing the Inverter Place the inverter on a flat wall or in a cabinet, and use 4 screws or bolts to securely fix the inverter to the surface. 3.7.4 Connecting the Power Cables Connect the power cables to the input (R, S, T) and output (U, V, W) terminals. Then, tighten the terminal screws.

  • Page 57: Reassembling The Ip54 Front Cover And The Keypad

    Installing the Inverter 3.7.5 Reassembling the IP54 Front Cover and the Keypad Place the front cover on the chassis and align the screw holes on each side. Insert and tighten the screws. There are 9–13 screws on the cover depending on the model type.
  • Page 58 Installing the Inverter Connect the signal cable to the keypad, align the lower part of the keypad to the bottom of the keypad receptacle, and then push the top part of the keypad into the chassis until the keypad snaps into place. Place the keypad cover on top of the keypad, and secure it using 2 screws.

  • Page 59: Connecting The Cables

    Connecting the Cables 4 Connecting the Cables Connect cables to the power and signal terminal blocks of the inverter. ESD (Electrostatic discharge) from the human body may damage sensitive electronic components on the PCB. Therefore, be extremely careful not to touch the PCB or the components on the PCB with bare hands while you work on the I/O PCB.
  • Page 60 Connecting the Cables Depress the tab on the keypad cable connector and disconnect the cable from the back of the keypad. Loosen the screw from the bottom part of the front cover, and then remove the front cover.

  • Page 61: Ip 54 Type Products

    Connecting the Cables 4.1.2 IP 54 Type Products Loosen the two screws securing the keypad cover, and then remove the keypad cover. Depress the tab at the top of the keypad and gently lift the keypad from the inverter to remove it.

  • Page 62: Kw, 400 V And 30-75 Kw, 200 V Products

    Connecting the Cables Remove the screws from each side of the front cover, and then remove the front cover. 4.1.3 90–375 kW, 400 V and 30–75 kW, 200 V Products Loosen the two screws on the front cover. Slide the cover downwards and remove it from the inverter.

  • Page 63: Activating And Deactivating The Built-In Emc Filter

    Connecting the Cables 4.2 Activating and Deactivating the Built-in EMC Filter Some iS-7 inverter models have built-in EMC filters to reduce conductive and radiational noise at the inverter input. Refer to 1.1.1 Identifying the Product on page 1 and check your inverter’s model type and specifications to see if it has a built-in EMC filter.
  • Page 64 Connecting the Cables Connect the two jumper pins using a short circuit connector to activate the EMC filter. To remove the short circuit connector and deactivate the EMC filter, pull the connector while pressing the latch on the side of the connector. Use pliers or tweezers if you cannot reach the latch with your fingers.

  • Page 65: Kw Inverters

    Connecting the Cables 4.2.2 11–22 kW Inverters Locate the EMC filter cable and the ground terminal at the bottom of the inverter. The EMC filter is deactivated if the EMC filter cable is connected to the insulated stud. <EMC filter is turned OFF> Remove the EMC filter cable from the insulated stud and connect it to the ground terminal (metal) to activate the EMC filter.
  • Page 66 Connecting the Cables Asymmetrical Grounding Connection Intermediate One phase of grounding a delta point on one connection is phase of a grounded delta connection A 3-phase The end of a connection single phase is without grounded grounding...

  • Page 67: Precautions For Wiring The Inverter

    Connecting the Cables 4.3 Precautions for Wiring the Inverter Do not connect power to the inverter until installation has been fully completed and the inverter • is ready to be operated. Doing so may result in electric shock. Wiring and inspection of wiring must be performed by an authorized engineer. •...

  • Page 68: Ground Connection

    Connecting the Cables 4.4 Ground Connection Install ground connections for the inverter and the motor by following the correct specifications to ensure safe and accurate operation. Using the inverter and the motor without the specified grounding connections may result in electric shock. Do not use the ground terminal as the signal (control) ground.

  • Page 69: Terminal Wiring Diagram

    Connecting the Cables 4.5 Terminal Wiring Diagram 4.5.1 Up to 7.5 kW Inverters R (L1) S (L2) T (L3) 3-phase AC input P (+) N (-) Dynamic brake To motor resistor 4.5.2 11–22 kW Inverters R (L1) S (L2) T (L3) P (+) N (-) 4.5.3 30–75 kW Inverters...

  • Page 70: Kw Inverters

    Connecting the Cables 4.5.5 185–220 kW Inverters R (L1) S (L2) T (L3) P2 (+) N (-) 4.5.6 280–375 kW Inverters R (L1) S (L2) T (L3) P1 (+) P2 (+) N (-) Note Inverters with a rated capacity of 11 kW or more are equipped with linearly arranged terminal •...

  • Page 71: Connecting Cables To The Power Terminal Block

    Connecting the Cables 4.6 Connecting Cables to the Power Terminal Block Power supply cables must be connected to the R, S, and T terminals. Connecting power cables to other terminals will damage the inverter. Note The motor will rotate in the opposite direction if the U, V, and W terminals are connected in a wrong phase order.

  • Page 72: Kw (200 V/400 V)

    Connecting the Cables Cable connection for utilizing the optional dynamic braking unit Connect the cables from dynamic braking unit to P (+) and N (-) terminals to utilize the optional dynamic braking unit. Do not connect cables to B terminal. Terminal Symbol Terminal Name Description...

  • Page 73: Kw (400 V)

    U, V, W Inverter output terminals motor *Contact LSIS Customer Support before configuring the P2 (+) and N (-) terminals as the DC common source. There are a few factors that require special attention for this application. Note External DC reactors cannot be used with 30–75 kW inverters. To use a DC reactor with these inverters, purchase a 30–75 kW inverter that has a built-in DC reactor.

  • Page 74: Kw (400 V)

    Connecting the Cables Terminal Symbol Terminal Name Description R (L1), S (L2), T (L3) AC power supply input terminals AC input terminals N (-) (-) DC voltage terminal (-) DC link voltage terminal P2 (+), N (-) Dynamic brake resistor terminal Dynamic brake resistor terminals Output terminals to a 3-phase U, V, W...

  • Page 75: Kw (200 V/400 V)

    Inverter output terminals motor *Contact LSIS Customer Support before configuring the P2 (+) and N (-) terminals as the DC common source. There are a few factors that require special attention for this application. Apply rated torques to the terminal screws. Loose screws may cause the terminals to short •...

  • Page 76: Specifications Of The Power Terminal Block And Exterior Fuse

    Connecting the Cables 4.7 Specifications of the Power Terminal Block and Exterior Fuse Cable Terminal Screw torque Exterior fuse Inverter capacity mm² AWG or kcmil screw size (Kgf· cm) R,S,T U,V,W R,S,T U,V,W Current Voltage 0.75 kW M4 7.1–12 10 A 500 V 1.5 kW 7.1–12...

  • Page 77: Cable Length Between The Inverter And The Motor

    Connecting the Cables Cable Exterior fuse Terminal Screw torque Inverter capacity mm² AWG or kcmil screw size (Kgf· cm) R,S,T U,V,W R,S,T U,V,W Current Voltage 220 kW 182.4–215.0 800 A 500 V 280 kW 182.4–215.0 1000 A 500 V 182.4–215.0 315 kW 2x200 2x200 2x400 2x400 1200 A...

  • Page 78: Protective Measures For The Inverter And The Motor

    Connecting the Cables a) If the output peak voltage is too high even when the motor cable length is shorter than the maximum recommended cable length for the inverter capacity: - use a motor with a high insulation rating. - install an output circuit filter (micro surge filter). - install a dv/dt filter, or a sine wave filter.

  • Page 79: Control Terminal Wiring For Is7 Inverters Rated For Up To 22 Kw

    Connecting the Cables Only use Class H or RK5 UL listed input fuses and UL listed breakers. See the table above for the voltage and current ratings for the fuses and breakers. Utiliser UNIQUEMENT des fusibles d’entrée homologués de Classe H ou RK5 UL et des disjoncteurs UL.

  • Page 80: Npn Mode (Sink)

    Connecting the Cables 4.8.1 NPN Mode (Sink) Select NPN using the PNP/NPN selection switch. The factory default setting is NPN mode. CM (24V GND) is the common ground terminal for all terminal inputs. 4.8.2 PNP Mode (Source) Select PNP using the PNP/NPN selection switch. The factory default setting is NPN mode. CM (24 V GND) is the common ground terminal for all terminal inputs, and 24 is the 24 V internal source.

  • Page 81: 22 Kw (Basic I/O)

    Connecting the Cables 4.8.3 0.75–22 kW (Basic I/O) Wiring Examples Default Functions Assigned for the Multi-Function Terminals Sp-L Sp-M Sp-H Note The TR (termination resistor) switch is used to terminate the RS485 network connection (120 Ω). • For analog voltage input, use a potentiometer rated at 0.5W, 1kOhm. •...

  • Page 82: Control Terminal Wiring For Is7 Inverters Rated For 30 Kw Or More

    Connecting the Cables 4.9 Control Terminal Wiring for iS7 Inverters Rated for 30 kW or More 30–375 kW (control terminal block)

  • Page 83: Terminal Inputs For Inverter Operation

    Connecting the Cables Note The TR (termination resistor) switch is used to terminate the RS485 network connection (120 Ω). • Use a potentiometer rated for 0.5 W, 1 kΩ. • If the analog voltage (V) or current (I) input is used to set the frequency reference, the analog input is reflected when the input is actually received.
  • Page 84 Connecting the Cables Input Type Symbol Name Description Used to setup or modify a frequency reference via the analog voltage input terminal. Voltage input for Unipolar: 0–10 V frequency reference Bipolar: -10–10 V Input resistance 20 kΩ Used to setup or modify a frequency reference via Current input for the current input terminals.

  • Page 85: Cable Specifications For Control Block Wiring

    Connecting the Cables 4.11 Cable Specifications for Control Block Wiring Cable size Terminal Name Specifications P1–P8 Multi-function input terminal Common terminal input Common earth for multi-function input (5G common is used for terminal analog frequency inputs only). Analog frequency setting (+) Output voltage: +12 V power 0.33–...

  • Page 86: Setting The Built-In Surge Filter

    Connecting the Cables 4.12 Setting the Built-in Surge Filter The iS7 series inverters have a built-in surge filter between the input phases and the ground connection to absorb and mitigate surge current. This filter consists of a Y-CAP and multiple varistors.

  • Page 87: Activating Or Deactivating The Surge Filter

    4.13 Activating or Deactivating the Surge Filter 4.13.1 iS7 30–75KW (400 V) Inverters Contact LSIS Customer Support and ask for assistance to deactivate the built-in surge filter for the 30–75 KW (400 V) inverters. 4.13.2 iS7 90–375 kW (400V) Inverters Remove the keypad and the screws from the front cover, and then remove the front cover.
  • Page 88 Connecting the Cables Refer to the following figures to locate the jumper switch on the SCR snubber board and install or remove the jumper cap to activate or deactivate the built-in surge filter. SV900-1600iS7 (400 V) SV1850-2200iS7 (400 V) SV2800-3750iS7 (400 V)

  • Page 89: Post-Installation Checklist

    Connecting the Cables 4.14 Post-Installation Checklist After completing the installation, check the items in the following table to make sure that the inverter has been safely and correctly installed. Items Check Point Result Is the installation location appropriate? Does the environment meet the inverter’s operating conditions? Installation Location/Power Does the power source match the inverter’s rated input?

  • Page 90: Test Run

    Connecting the Cables Items Check Point Result defined prior to the installation of the control wiring connections? Are the control cables properly wired? Are the control terminal screws tightened to their specified torques? Is the total cable length of all control wiring < 328 ft (100 m) for model types rated at 3.7 kW and below, and 984 ft (300 m) for model types rated at more than 3.7 kW? Is the total length of safety wiring <...

  • Page 91: Setting The Basic Parameters In Easy Start Mode

    Connecting the Cables Note Before setting the parameter values for a user application, initialize the parameter settings to • make sure that the default setting is applied to all parameters. If you initialized all parameters after an inverter trip occurred, the inverter starts in Easy Start •...

  • Page 92: Checking The Inverter Operation

    Connecting the Cables 4.15.3 Checking the Inverter Operation Using an inverter, you can easily operate a motor at a high speed. Before operating a motor using an inverter, ensure that the set speed is within the motor's rated speed. Follow the instructions to ensure that the motor operates correctly according to the inverter settings, and adjust the settings if required.

  • Page 93: Using The Keypad

    Using the Keypad 5 Using the Keypad 5.1 About the Keypad A keypad is used to set inverter parameters, monitor the inverter’s status, and operate the inverter. 5.1.1 Dimensions...

  • Page 94: Key Functions

    Using the Keypad 5.1.2 Key Functions The following table lists the names and functions of the keypad’s operation keys. Section Buttons Key Name Function Description [MODE] key Used to switch between modes. If this button is pressed once, the parameter can be edited at the status of the editable parameter code.

  • Page 95: Display Items

    Using the Keypad 5.1.3 Display Items Monitor Mode Parameter Mode 5.1.4 Display Item List The following table lists the items in the display. Item Description Displays the current mode’s display items. For more details, refer Mode display items to 5.3 Navigating Modes on page 90.
  • Page 96 Using the Keypad Item Description Displays the current parameter group’s items. For more details, Parameter group items refer to 5.4 Navigating Modes and Parameters on page 93. Command source / Displays the types of sequences and the number of steps during an frequency reference items auto sequence operation.
  • Page 97 Using the Keypad Function Display Description Jog frequency command Internal 485 frequency command 1-9 A-F Multi-step frequency command JOG key Used to switch to Keypad JOG mode Local/Remote Used to select local or remote operation Multi-function Used to register parameters as a user group in key settings User Group Parameter mode or delete parameters in the user...

  • Page 98: Menu Items

    Using the Keypad 5.2 Menu Items The SV-iS7 series inverter uses 5 modes to monitor or configure different functions. Each mode has its own function items suitable for the desired properties. The parameters in Parameter mode and User & Macro mode are divided into smaller groups of relevant functions.

  • Page 99: Parameter Mode

    Using the Keypad Mode Display Description Displays the inverter’s operation status information. You can Monitor mode monitor the frequency setting, operating frequency display, output current, voltage, etc. Used to configure the functions required to operate the inverter. Parameter mode These functions are divided into 12 groups based on purpose and complexity.

  • Page 100: User & Macro Mode

    Using the Keypad Mode Display Description Output terminal Configures the inverter output terminal block-related features, function group including the relay and analog outputs. Communication Configures the communication features for the RS-485, if one is function group installed. Application Configures the features related to PID control and auto sequence function group operation.

  • Page 101: Navigating Modes

    Using the Keypad 5.3 Navigating Modes 5.3.1 Mode Navigation at the Factory Default You can change the display to navigate modes by using the [MODE] key. The User & Macro Mode and Trip Mode are not displayed when the inverter is set to the factory default settings. Displays when the inverter is powered on.

  • Page 102: Mode Navigation With User/Macro Mode And Trip Mode

    Using the Keypad You are now in Config mode (CNF). • Press the [MODE] key. • You are now in Monitor mode again. • 5.3.2 Mode Navigation with User/Macro Mode and Trip Mode If you register a user code or set the macro function using the [MULTI] key, the User & Macro mode will be displayed, unlike the factory default settings during mode navigation.
  • Page 103 Using the Keypad You are now in User & Macro mode (U&M). • Press the [MODE] key. • You are now in Trip mode (TRP). • Press the [MODE] key. • You are now in Config mode (CNF). • Press the [MODE] key. •...

  • Page 104: Navigating Modes And Parameters

    Using the Keypad 5.4 Navigating Modes and Parameters You can navigate modes by using the [Left] or [Right] keys after navigating to the Parameter Mode or User & Macro Mode via the [Mode] key. 5.4.1 Group Navigation in Parameter mode If you press the [Right] key in Parameter mode, the display will change as shown below.
  • Page 105 Using the Keypad You are now in Parameter mode (PAR). • The Drive Group (DRV) of Parameter mode is • displayed. Press the [Right] key. • You are now in the Basic Function Group (BAS). • Press the [Right] key. •...

  • Page 106: Group Shift In User & Macro Mode

    Using the Keypad 5.4.2 Group Shift in User & Macro Mode To navigate to User & Macro Mode, the user code should be registered or the macro function should be selected. If the user code is registered and the macro function is selected, you can navigate to the group as shown below.

  • Page 107: Navigating Through Codes (Function Items)

    Using the Keypad 5.5 Navigating through Codes (Function Items) 5.5.1 Code Navigation in Monitor Mode To display the frequency, output current, and output voltage, press the [Up] or [Down] keys to scroll through the items. Displays when the inverter is powered on. This •...

  • Page 108: Code Navigation (Function Items) In Other Modes And Groups

    Using the Keypad The output voltage text has disappeared and the • cursor has moved to the third display item. Press the [Up] key twice. • The first item displays the frequency. • The frequency text has disappeared and the cursor •...

  • Page 109: Code Navigation Using Jump Code

    Using the Keypad Displays the Drive (DRV) group of Parameter mode. • If the DRV group is not displayed, press the [MODE] key until the DRV group appears, or press the [ESC] key. If you press the [Down] key, you will navigate to •...
  • Page 110 Using the Keypad The cursor flashes and you can enter the code • number. Press the [Up] key to enter 9 and then press the • [PROG/ENT] key. You have moved to code No. 09 of the DRV group. • Press the [ESC] key to move to code No.

  • Page 111: Setting Parameters

    Using the Keypad 5.6 Setting Parameters 5.6.1 Parameter Settings in Monitor Mode You can set some parameters, such as the frequency, in Monitor mode. The following example demonstrates how to set the frequency. Ensure that the cursor is at the frequency item. Also, •...

  • Page 112: Parameter Settings In Other Modes And Groups

    Using the Keypad 5.6.2 Parameter Settings in Other Modes and Groups The following example demonstrates how to change the frequency of the Drive (DRV) group in Parameter mode. The frequency in the other modes or groups can be set as follows. This is the initial display in Parameter mode.

  • Page 113: Monitoring Operating Status

    Using the Keypad 5.7 Monitoring Operating Status 5.7.1 Using Monitor Mode Three items can be displayed in Monitor mode at a time. Also, some items, such as the frequency item, can be edited. You can select the displayed items in Configuration (CNF) mode. This is the initial display in Monitor mode.

  • Page 114: Monitoring Items

    Using the Keypad 5.7.2 Monitoring Items Mode Code Function Display Setting Range Initial Value Anytime Para Frequency 0: Frequency Monitor Line-1 Speed 0: Frequency Monitor Line-2 Output Current 2:Output Current Output Voltage Output Power WHour Counter DCLink Voltage DI Status DO Status V1 Monitor [V] V1 Monitor [%]...

  • Page 115: Using The Status Display

    Using the Keypad 5.7.3 Using the Status Display The items displayed on the right-top of the display are shown in other modes, including Monitor mode. If you register a desired variable in the display, you can monitor it at any time regardless of the mode navigation or change.

  • Page 116: Monitoring Faults

    Using the Keypad 5.8 Monitoring Faults 5.8.1 Faults during Inverter Operation If a fault trip occurs during inverter operation, the • inverter enters Trip mode automatically and displays the type of fault trip that has occurred. Press the [Down] key to view the information on the •...

  • Page 117: Multiple Faults At A Time During Inverter Operation

    Using the Keypad 5.8.2 Multiple Faults at a Time during Inverter Operation If multiple fault trips occur at the same time, the • number of fault trips that occurred is displayed next to the fault trip type. Press the [PROG/ENT] key. •...
  • Page 118 Using the Keypad If a fault trip occurs during inverter operation, the • inverter enters Trip mode and displays the type of fault trip that has occurred. If you press the [STOP/RESET] key or an input is • entered on the terminal, the fault trip is automatically saved and the display status that was displayed before the fault trip occurred is displayed.

  • Page 119: Initializing Parameters

    Using the Keypad 5.9 Initializing Parameters You can initialize the changed parameters. In addition to initializing the entire parameter, you can also select the individual parameter mode to be initialized. • Monitor mode is displayed. Press the [MODE] key to move to Configuration •...
  • Page 120 Using the Keypad The Parameter Initialization option is displayed • again when the initialization is complete.

  • Page 121: Basic Functions

    Basic Functions 6 Basic Functions 6.1 Setting Frequency References The iS7 inverter provides several methods to set up and modify a frequency reference for an operation. The keypad, analog inputs [for example voltage (V1) and current (I1) signals], or RS- 485 (digital signals from higher-level controllers, such as PCs or PLCs) can be used.

  • Page 122: Keypad As The Source (Keypad-1 Setting)

    Basic Functions 6.1.1 Keypad as the Source (KeyPad-1 setting) You can modify the frequency reference using the keypad and apply changes by pressing the [ENT/PROG] key. To use the keypad as a frequency reference input source, go to DRV-07 (Frequency reference source) and change the parameter value to “0 (Keypad-1)”. Input the frequency reference for an operation at DRV-01 (Frequency reference).
  • Page 123 Basic Functions 6.1.3.1 Setting a Frequency Reference for 0–10 V Input Set IN-06 (V1 Polarity) to “0 (unipolar)”. Use a voltage output from an external source or use the voltage output from the VR terminal to provide inputs to V1. Refer to the diagrams below for the wiring required for each application.
  • Page 124 Basic Functions 0–10 V Input Voltage Setting Details Code Description Configures the frequency reference at the maximum input voltage when a potentiometer is connected to the control terminal block. A frequency set with code IN-01 becomes the maximum frequency only if the value set in code IN- 11 (or IN-15) is 100%.
  • Page 125 Basic Functions Code Description Inverts the direction of rotation. Set this code to “1 (Yes)” if you need the motor IN-16 V1 Inverting to run in the opposite direction from the current rotation. Quantizing may be used when the noise level is high in the analog input (V1 terminal) signal.
  • Page 126 Basic Functions Code Description [V1 Quantizing]...
  • Page 127 Basic Functions 6.1.3.2 Setting a Frequency Reference for -10–+10 V Input Set DRV-07 (Frequency reference source) to “2 (V1)”, and then set IN-06 (V1 Polarity) to “1 (bipolar)”. Use the output voltage from an external source to provide an input to V1. [External source application] [Internal source (VR) application] [V1 terminal wiring]...
  • Page 128 Basic Functions Group Code Name LCD Display Parameter Setting Setting Range Unit V1 input monitor V1 Monitor 0.00 0.00–10.00 V V1 polarity options V1 Polarity Bipolar 0–1 V1 minimum input V1- volt x1 0.00 0.00–10.00 V voltage V1 output at V1- Perc y1 0.00 -100.00–0.00%...
  • Page 129 Basic Functions Code Description For details about the 0–+10 V analog inputs, refer to the code descriptions IN- 08 V1 volt x1–IN-11 V1 Perc y2 on page 113.
  • Page 130 Basic Functions 6.1.3.3 Setting a Reference Frequency using Input Current (I1) You can set and modify a frequency reference using input current at the I1 terminal. Set DRV- 07 (Frequency reference source) to “3 (I1)” and apply an input current of 0–20 mA to I1. Group Code Name LCD Display Parameter Setting...
  • Page 131 Basic Functions Input Current (I1) Setting Details Code Description Configures the frequency reference for operation at the maximum current (when IN-26 is set to 100%). If IN-01 is set to 40.00, and default settings are used for IN-23–26, an • IN-01 Freq at input current of 20 mA (max) to I1 will produce a frequency reference of 100%...

  • Page 132: Setting A Frequency Reference Using An I/O Expansion Module (Terminal V2/I2)

    Basic Functions 6.1.4 Setting a Frequency Reference Using an I/O Expansion Module (Terminal V2/I2) After installing an optional I/O I/O expansion moduleto the iS7 inverter, you can set and modify a frequency reference using the input voltage or current at the V2/I2 terminal. 6.1.4.1 Setting a Reference Frequency using Input Voltage at V2 Terminal Set the DRV-07 (Frequency reference source) to “4 (V2)”...
  • Page 133 Basic Functions Group Code Name LCD Display Parameter Setting Setting Range Unit maximum V2’ voltage Invert V2 rotational V2 Inverting No/Yes direction 0.00*, 0.04– V2 quantizing level 0.04 Quantizing 10.00 * Quantizing is disabled if “0” is selected. 6.1.4.2 Setting a Reference Frequency using Input Current at I2 Terminal Set the DRV-07 (Frequency reference source) to “5 (I2)”...

  • Page 134: Setting A Frequency With Pulse Input (With An Optional Encoder Module)

    Basic Functions 6.1.5 Setting a Frequency with Pulse Input (with an optional encoder module) After installing an optional encoder module, you can set a frequency reference by setting DRV- 07 (Frequency reference source) to “9 (Pulse)” and providing a pulse frequency of 0–32.00 kHz to the pulse input terminal.
  • Page 135 Basic Functions Pulse Input Setting Details Code Description APO-01 Enc Opt Sets the encoder option mode. Set APO-01 to “2 (Reference)” to receive a Mode pulse input for the frequency reference. APO-04 Enc Type Sel Sets the output type. APO-05 Enc Pulse Selects the encoder pulse to use.

  • Page 136: Setting A Frequency Reference Via Rs-485 Communication

    Basic Functions 6.1.6 Setting a Frequency Reference via RS-485 Communication Control the inverter with upper-level controllers, such as PCs or PLCs, via RS-485 communication. Set DRV-07 (Frequency reference source) to “6 (Int 485)” and use the RS-485 signal input terminals (S+/S-/SG) for communication. Group Code Name LCD Display Parameter Setting...

  • Page 137: Frequency Hold By Analog Input

    Basic Functions 6.2 Frequency Hold by Analog Input If you set a frequency reference via the analog input at the control terminal block, you can hold the operation frequency of the inverter by assigning a multi-function input as the analog frequency hold terminal.

  • Page 138: Changing The Displayed Units (Hz↔Rpm)

    Basic Functions 6.3 Changing the Displayed Units (Hz↔Rpm) You can change the units used to display the operational speed of the inverter by setting DRV- 21 (Speed unit selection) to “0 (Hz Display)” or “1 (Rpm Display)”. Group Code Name LCD Display Parameter Setting Setting Range...
  • Page 139 Basic Functions Multi-step Frequency Setting Details Code Description BAS Group 50–64 Configure multi-step frequency 1–15. Choose the terminals to set up as multi-step inputs, and then set the relevant codes (IN-65–75) to 7 (Speed-L), 8 (Speed-M), 9 (Speed-H), or 10 (Speed-X). Provided that terminals P6, P7, and P8 have been set to Speed-L, Speed-M and Speed-H respectively, the following multi-step operation will be available.
  • Page 140 Basic Functions Code Description the highest bit is Speed-X. Speed Fx/Rx                              ...

  • Page 141: Command Source Configuration

    Basic Functions 6.5 Command Source Configuration Various devices can be selected as command input devices for the iS7 inverter. Input devices available include the keypad, multi-function input terminal, RS-485 communication, and field bus adapter. Group Code Name LCD Display Parameter Setting Setting Range Unit Keypad...

  • Page 142: The Terminal Block As A Command Input Device (Fwd/Rev Run Commands)

    Basic Functions 6.5.2 The Terminal Block as a Command Input Device (Fwd/Rev run commands) Multi-function terminals can be selected as a command input device. This is configured by setting DRV-06 (command source) to “1 (Fx/Rx-1)”. Select two terminals for the forward and reverse operations, and then set the relevant codes (2 of the 11 multi-function terminal codes, IN-65–75 for P1–P8 [optional: P9–P11]) to “1 (Fx)”...

  • Page 143: The Terminal Block As A Command Input Device (Run And Rotation Direction Commands)

    Basic Functions 6.5.3 The Terminal Block as a Command Input Device (Run and Rotation Direction Commands) Multi-function terminals can be selected as a command input device. This is configured by setting DRV-06 (command source) to “2 (Fx/Rx-2)”. Select two terminals for run and rotation direction commands, and then set the relevant codes (2 of the 11 multi-function terminal codes, IN-65–75 for P1–P11 [optional: P9–P11]) to “1 (Fx)”...

  • Page 144: Communication As A Command Input Device

    Basic Functions 6.5.4 RS-485 Communication as a Command Input Device Internal RS-485 communication can be selected as a command input device by setting DRV-06 (command source) in the Drive group to “3 (Int 485)”. This configuration uses upper level controllers, such as PCs or PLCs, to control the inverter by transmitting and receiving signals via the S+, S-, and RS-485 signal input terminals at the terminal block.

  • Page 145: Power-On Run

    Basic Functions Forward/Reverse Run Prevention Setting Details Code Description Choose a direction to prevent. Setting Description ADV-09 Run None Do not set run prevention. Prevent Forward Prev Set forward run prevention. Reverse Prev Set reverse run prevention. 6.7 Power-on Run The Power-on Run feature can be set up to start an inverter operation after powering up based on the run commands by terminal inputs (if they are configured).

  • Page 146: Setting Acceleration And Deceleration Times

    Basic Functions Note To prevent a repeat fault trip from occurring when a load, such as a fan, is free-running on a • Power-on Run, set CON-71 (speed search options) bit 4 to “1”. The inverter will perform a speed search at the beginning of the operation.
  • Page 147 Basic Functions Code Description Delta Freq Set the acc/dec time based on the operating frequency. If, for example, the maximum frequency is 60.00 Hz, the acc/dec times are set to 5 seconds, and the frequency reference for operation is set at 30 Hz (half of 60 Hz).

  • Page 148: Acc/Dec Time Based On Operation Frequency

    Basic Functions 6.8.2 Acc/Dec Time Based on Operation Frequency Acc/Dec times can be set based on the time required to reach the next frequency from the existing operation frequency. To set the acc/dec time values based on the existing operation frequency, set BAS-08 (Acc/Dec reference) to “1 (Delta Freq)”.

  • Page 149: Multi-Step Acc/Dec Time Configuration

    Basic Functions 6.8.3 Multi-Step Acc/Dec Time Configuration The acc/dec times can be configured via a multi-function terminal by setting the ACC (acceleration time) and DEC (deceleration time) codes in the DRV group. Group Code Name LCD Display Parameter Setting Setting Range Unit 75 kW and less 20.0 Acceleration time...

  • Page 150: Configuring Acc/Dec Time Switch Frequency

    Basic Functions Code Description acc/dec commands are recognized as binary code inputs and will control the acceleration and deceleration based on parameter values set at BAS-70–75 If, for example, the P7 and P8 terminals are set as XCEL-L and XCEL-M respectively, the following operation will be available.
  • Page 151 Basic Functions Group Code Name LCD Display Parameter Setting Setting Range Unit Multi-step Dec Time-1 20.0 0.0–600.0 deceleration time1 Acc/dec time 0–Maximum Xcel Change Fr 30.00 Hz/RPM switch frequency frequency Acc/Dec Time Switch Frequency Setting Details Code Description After the acc/dec switch frequency has been set, the acc/dec gradients configured at BAS-70 and 71 will be used when the inverter’s operation frequency is at or below the switch frequency.

  • Page 152: Output Voltage Setting

    Basic Functions 6.9 Output Voltage Setting Output voltage settings are required when a motor’s rated voltage differs from the input voltage to the inverter. Set BAS-15 to configure the motor’s rated operating voltage. The set voltage becomes the output voltage of the inverter’s base frequency. When the inverter operates above the base frequency, and when the motor’s voltage rating is lower than the input voltage at the inverter, the inverter adjusts the voltage and supplies the motor with the voltage set at BAS-15 (motor-rated voltage).

  • Page 153: Troubleshooting And Maintenance

    This chapter explains how to troubleshoot a problem when inverter protective functions, fault trips, warning signals, or faults occur. If the inverter does not work normally after following the suggested troubleshooting steps, please contact the LSIS Customer Support. 7.1 Protection Functions 7.1.1 Protection from Output Current and Input Voltage...

  • Page 154: Abnormal Circuit Conditions And External Signals

    Troubleshooting and Maintenance Type Category Details Remarks Open phases in an open circuit condition. Operates only when bit 2 of PRT-05 is set to “1”. Displayed when the inverter has been protected from overload and resultant overheating, based on inverse time limit thermal characteristics.
  • Page 155 Troubleshooting and Maintenance Type Category Details Remarks ADC Off Set: An error in the current sensing circuit (U/V/W terminal, current sensor, etc.). Gate Pwr Loss: An interruption in the supply of power to the IGBT Gate of a product rated 30 kW or higher (when a fault occurs in a 22 kW-rated product, the capacity settings should be checked).

  • Page 156: Keypad And Optional Expansion Modules

    Troubleshooting and Maintenance Type Category Details Remarks When Control Mode (DRV-09) is Vector: The trip occurs when OUT-31-32 is set to BR Control and the current is lower than half of the BAS-14 value. 7.1.3 Keypad and Optional Expansion Modules Type Category Details Remarks...

  • Page 157: Warning Messages

    If the inverter is still in a fault condition after it is powered on again, please contact the supplier or the LSIS Customer Support. The function for saving the fault history and the fault signal output may not be performed if the functions are not set or the inverter is seriously damaged.

  • Page 158: Troubleshooting Fault Trips

    Troubleshooting and Maintenance Type Description Displayed when operating commands come from the keypad or there is any problem with the communication between the keypad and inverter’s main body Lost Keypad in Keypad JOG mode after setting PRT-11 (Lost KPD Mode) to “0”. Set the Lost Keypad (29) at OUT31-33.
  • Page 159 Open The DC link capacitor needs to be Replace the DC link capacitor. Contact the replaced. retailer or the LSIS Customer Support. The load is greater than the rated Replace the motor and inverter with motor capacity. models that have increased capacity.
  • Page 160 The ambient temperature is too low. 10℃. NTC Open There is a fault with the internal Contact the retailer or the LSIS Customer temperature sensor. Support. There is a foreign object in the inverter Remove the foreign object from the air vent where the fan is located.

  • Page 161: Replacing The Cooling Fan

    Troubleshooting and Maintenance 7.4 Replacing the Cooling Fan 7.4.1 Products Rated below 7.5 kW To replace the cooling fan, push the bracket on the bottom in the direction of the arrows in the diagram below and then pull it forward. Then, disconnect the fan connector. <Below 3.7 kW>...

  • Page 162: Products Rated At More Than 30 Kw (200 V) / 90 Kw (400 V), And 18.5-22 Kw (200 V) / 30-75 Kw (200/400 V)

    Troubleshooting and Maintenance 7.4.3 Products Rated at more than 30 kW (200 V) / 90 kW (400 V), and 18.5–22 kW (200 V) / 30–75 kW (200/400 V) To replace the cooling fan, loosen the screws at the top of the product and disconnect the fan connector.

  • Page 163: Daily And Regular Inspection Lists

    Troubleshooting and Maintenance 7.5 Daily and Regular Inspection Lists Inspection Cycle Inspection Inspection Inspection Inspection Inspection Regular Judgment standard area item details method equipment (Year) Daily Is the ambient No ice temperature (ambient and humidity temperature: -10℃ within the Thermometer, Ambient Visual designated...
  • Page 164 Troubleshooting and Maintenance Inspection Cycle Inspection Inspection Inspection Inspection Inspection Regular Judgment standard area item details method equipment (Year) Daily 2) Is there any damage to cable  insulation? Terminal Is there any Visual inspection No abnormality  block damage? 1) Is liquid 1), 2) Visual 1),2) No...
  • Page 165 Troubleshooting and Maintenance Inspection Cycle Inspection Inspection Inspection Inspection Judgment Inspection Regular area item details method standard equipment (Year) Daily 1) Check for 1) Balance the output voltage 1) Measure voltage between imbalance while voltage between phases: within 4 V ...

  • Page 166: Table Of Functions

    Table of Functions 8 Table of Functions 8.1 Parameter Mode – DRV Group (DRV) DRV Group (PAR  DRV) Note1) Control Mode Communi- Shift in cation LCD Display Name Setting Range Initial Value Opera- Address tion Jump Code Jump code 1-99 O O O O O Starting frequency...
  • Page 167 Table of Functions DRV Group (PAR  DRV) Control Communi- Shift in Mode cation LCD Display Name Setting Range Initial Value Opera- tion Address 0 No Torque 0h110A Torque control 0: No X X X O O Control 1 Yes 0.5–maximum 0h110B Jog frequency...
  • Page 168 Table of Functions DRV Group (PAR  DRV) Control Communi- Shift in Mode cation LCD Display Name Setting Range Initial Value Opera- tion Address 0h111A Adv ATB Filter Adv ATB Filter X X X O O 1~1000[msec] Note2) Adv ATB M 0h111B Adv ATB M Gain 0~300.0[%] O O O O O...

  • Page 169: Parameter Mode - Basic Function Group (Bas)

    Table of Functions 8.2 Parameter Mode – Basic Function Group (BAS) BAS Group(PAR  BAS) Control Mode Communi- Shift in cation LCD Display Name Setting Range Initial Value Opera- tion Address Jump Code Jump code 0-99 O O O O O 0 None 1 V1 Auxiliary...
  • Page 170 Table of Functions BAS Group (PAR  BAS) Control Mode Communi- Shift in cation LCD Display Name Setting Range Initial Value Opera- tion Address 1 Keypad-2 2 V1 3 I1 4 V2 5 I2 Second torque 6 Int 485 0h1206 Trq 2nd Src command 0:Keypad-1...
  • Page 171 Table of Functions BAS Group (PAR  BAS) Control Mode Communi Shift in Initial -cation Name Setting Range Opera- Display Value Address tion Dependent on motor Stator resistance X O O O O setting Dependent on motor Lsigma Leakage inductance X O O O O setting Dependent on motor...
  • Page 172 Table of Functions Control Mode Communi Shift in Initial -cation Name Setting Range Opera- Display Value Address tion Step Freq- Multi-step speed frequency 0h1240 5.00 O O O X X 0h1246 Acc Time-1 Multi-step acceleration time 1 0–600 (sec) 20.0 O O O X X 0h1247 Dec Time-1 Multi-step deceleration time 1 0–600 (sec)

  • Page 173: Parameter Mode - Expansion Function Group (ParAdv)

    Table of Functions 8.3 Parameter Mode – Expansion Function Group (PARADV) Expansion Function Group (PAR  ADV) Control Mode Communi- Shift in Initial Name Setting Range Opera- cation LCD Display Value tion Address Jump Code Jump code 0–99 O O O O O 0h1301 Acc Pattern Acceleration pattern...
  • Page 174 Table of Functions Expansion Function Group (PAR  ADV) Control Mode Communi- Shift in Initial cation Name Setting Range Opera- Value Display tion Address 0h1318 Freq Limit Frequency limit 0:No O O O X X Freq Limit 0h1319 Frequency lower limit 0–upper limit (Hz) 0.50 O O O X X Note 10 )
  • Page 175 Table of Functions Expansion Function Group (PAR  ADV) Control Mode Communi- Shift in Initial cation LCD Display Name Setting Range Opera- Value tion Address Load Spd Revolution display 0.1-6000.0 (%) 100.0 O O O X X Gain gain x 0.1 Load Spd Revolution display x 0.01...
  • Page 176 Table of Functions Control Mode Communi- Shift in Initial cation LCD Display Name Setting Range Opera- Value tion Address RegenAvd Regeneration evasion 0h134E 20–30000 (ms) 500 (ms) O O O O X X Igain for press I gain 200 V : 350–400 (V) 390 (V) DB Turn On DB unit operating...

  • Page 177: Parameter Mode - Control Function Group (Con)

    Table of Functions 8.4 Parameter Mode – Control Function Group (CON) Control Function Group (PAR  CON) Control Mode Communi- Shift in Name Setting Range Initial Value Opera- cation LCD Display tion Address Jump Code Jump code 0-99 O O O O O Below 22 0.7–15 (kHz)
  • Page 178 Table of Functions Control Mode Communi- Shift in cation LCD Display Name Setting Range Initial Value Opera- tion Address Note 17 ) Gain2 controller on motor proportional capacity gain 2 Sensorless2 Dependent ASR-SL I 0h1418 speed controller 1.0–1000.0 (%) on motor X X X X X Gain2 integral gain 2...
  • Page 179 Table of Functions Control Function Group (PAR  CON) Control Mode Communi- Shift in LCD Display Name Setting Range Initial Value Opera- cation tion Address Sensorless2 speed Dependent 0h141F S-Est P Gain2 estimator proportional 1.0–1000.0 (%) on motor X X X X X gain 2 capacity Dependent...
  • Page 180 Table of Functions Control Function Group (PAR  CON) 1)Control Communi- Shift in Mode cation LCD Display Name Setting Range Initial Value Opera- tion Address 0 Keypad-1 1 Keypad-2 2 V1 3 I1 Torque bias 0h143A Trq Bias Src 4 V2 0:Keypad-1 X X O X X setting options...
  • Page 181 Table of Functions Control Function Group (PAR  CON) Shift 1)Control Mode Communi -cation LCD Display Name Setting Range Initial Value Opera- Address tion Speed search Flying Start - 1 0h1446 SS Mode O O O X X mode selection Flying Start - 2 Bit 0000-1111 Speed search...
  • Page 182 Table of Functions Shift 1)Control Mode Communi -cation LCD Display Name Setting Range Initial Value Opera- Address tion Select function for 0h145A New AHR Sel preventing current 0:No O X X X X hunting Gain from current 0h145B AHR P-Gain 0-32767 1000 O X X X X...

  • Page 183: Parameter Mode - Input Terminal Block Function Group (In)

    Table of Functions 8.5 Parameter Mode – Input Terminal Block Function Group (IN) Input Terminal Block Function Group (PAR  IN) Control Mode Communi Shift in Initial Name Setting Range Opera- -cation LCD Display Value tion Address Jump Code Jump code 0-99 O O O O O Start...
  • Page 184 Table of Functions Input Terminal Block Function Group (PAR  IN) Control Mode Communi Shift in Initial -cation LCD Display Name Setting Range Opera- Page Value tion Address 0h1523 V2 input display 0–10 (V) 0.00 121 O O O O O Note 25) Monitor(V) 0 Unipolar...
  • Page 185 Table of Functions Input Terminal Block Function Group (PAR  IN) Control Communi- Shift in Mode Initial cation Name Setting Range Opera- Value Display tion Address NONE 0h1541 P1 Define P1 terminal function setting 1:FX O O O O O 0h1542 P2 Define P2 terminal function setting 2 2:RX...
  • Page 186 Table of Functions Input Terminal Block Function Group (PAR  IN) Control Mode Communi- Shift in Initial cation LCD Display Name Setting Range Opera- Value tion Address 33 -Reserved- 34 Pre Excite 35 Speed/Torque 36 ASR Gain 2 37 ASR P/PI 38 Timer In 39 Thermal In 40 Dis Aux Ref...

  • Page 187: Parameter Mode - Output Terminal Block Function Group (Out)

    Table of Functions 8.6 Parameter Mode – Output Terminal Block Function Group (OUT) Output Terminal Block Function Group (PAR  OUT) Control Mode Communi Shift in LCD Display Name Setting Range Initial Value Opera- -cation tion Address JumpCode Jump code 0-99 O O O O O 0 Frequency...
  • Page 188 Table of Functions Output Terminal Block Function Group (PAR  OUT) Control Communi Shift in Mode Initial -cation Name Setting Range Opera- Value Display tion Address 0h1608 AO2 Gain Analog output 2 gain -1000–1000 (%) 80.0 O O O O O 0h1609 AO2 Bias Analog output 2 bias...
  • Page 189 Table of Functions Output Terminal Block Function Group (PAR  OUT) Control Communi Shift in Mode Initial -cation LCD Display Name Setting Range Opera- Value tion Address 0h1615 AO4 Gain Analog output 4 gain -1000–1000 (%) 80.0 O O O O O 0h1616 AO4 Bias Analog output 4 bias...
  • Page 190 Table of Functions Output Terminal Block Function Group (PAR  OUT) Control Mode Communi Shift in -cation LCD Display Name Setting Range Initial Value Opera- tion Address 29 Trip 30 Lost Keypad 31 DB Warn %ED 32 ENC Tune 33 ENC Dir 34 On/Off Control 35 BR Control 36 KEB Operating...

  • Page 191: Parameter Mode - Communication Function Group (Com)

    Table of Functions 8.7 Parameter Mode – Communication Function Group (COM) Communication Function Group (PAR  COM) Control Communi- Mode Shift in Initial Name Setting Range Opera- cation LCD Display Value tion Address Jump Code Jump code 0–99 O O O O O Built-in communication 0h1701 Int485 St ID...
  • Page 192 Table of Functions Communication Function Group (PAR  COM) Control Mode Communi- Shift in Initial cation LCD Display Name Setting Range Opera- Value tion Address Number of input 0h1732 Para Ctrl Num 0–8 O O O O O parameters 0h1733 Para Control-1 Input address 1 0000-FFFF Hex 0005...
  • Page 193 Table of Functions Control Mode Communi- Shift in Initial cation LCD Display Name Setting Range Opera- Value tion Address I-Term Clear Openloop P Gain2 XCEL Stop 2nd Motor Trv Offset Lo Trv Offset Hi Interlock 1 Interlock 2 Interlock 3 Interlock 4 Reserved Pre Excite...

  • Page 194: Parameter Mode - Applied Function Group (App)

    Table of Functions 8.8 Parameter Mode – Applied Function Group (APP) Applied Function Group (PAR  APP) Control Mode Communi- Shift in Initial cation LCD Display Name Setting Range Opera- Value tion Address Jump Code Jump code 0–99 O O O O O None Traverse Proc PID...
  • Page 195 Table of Functions Applied Function Group (PAR  APP) Control Mode Communi- Shift in cation LCD Display Name Setting Range Initial Value Opera- tion Address 0 V1 1 I1 2 V2 3 I2 4 Int 485 21 0h1815 PID feedback selection 0:V1 O O O X X F/B Source...
  • Page 196 Table of Functions Control Mode Communi- Shift in cation LCD Display Name Setting Range Initial Value Opera- tion Address 4 KPa 5 Hz 6 rpm 9 kW 10 HP 11 ℃ 12 ℉ PID Unit 43 0h182B PID unit gain 0–300 (%) 100.00 O O O X X...

  • Page 197: Parameter Mode - Auto Sequence Operation Group (Aut)

    Table of Functions 8.9 Parameter Mode – Auto Sequence Operation Group (AUT) Auto Sequence Operation Group (PAR  AUT) Control Mode Communi- Shift in Initial LCD Display Name Setting Range Opera- cation Value tion Address Jump Code Jump code 0-99 O O O X X 0 Auto-A 0h1901...
  • Page 198 Table of Functions Control Mode Communi- Shift in Initial cation LCD Display Name Setting Range Opera- Value tion Address 1 Forward 0.01–maximum 0h191E Seq 1/6 Freq 1/6 step frequency 60.00 O O O X X frequency (Hz) 0h191F Seq 1/6 XcelT 1/6 Acc/Dec time 0.1–600.0 (sec) O O O X X Seq 1/6...
  • Page 199 Table of Functions Control Mode Communi- Shift in Initial cation LCD Display Name Setting Range Opera- Value tion Address frequency (Hz) 0h193C Seq 2/5 XcelT 2/5 Acc/Dec time 0.1–600.0 (sec) O O O X X Seq 2/5 2/5 steady speed 0h193D 0.1–600.0 (sec) O O O X X...

  • Page 200: Parameter Mode - Option Module Function Group (Apo)

    Table of Functions 8.10 Parameter Mode – Option Module Function Group (APO) Option Module Function Group (PAR  APO) Control Mode Communi- Shift in Initial cation LCD Display Name Setting Range Opera- Value tion Address Jump Code Jump code 0-99 O O O O O 0 None Encoder function...
  • Page 201 Table of Functions Control Mode Communi- Shift in Initial cation LCD Display Name Setting Range Opera- Value tion Address 1st auxiliary motor 0h1A1B Stop Freq 1 0–60 (Hz) 15.00 O O O X X stop frequency 2nd auxiliary motor 0h1A1C Stop Freq 2 0–60 (Hz) 15.00...
  • Page 202 Table of Functions Control Mode Communi- Shift in Initial cation LCD Display Name Setting Range Opera- Value tion Address 0h1A42 PLC Wr Data 7 PLC write data 7 0–FFFF (Hex) 0000 O O O O O 0h1A43 PLC Wr Data 8 PLC write data 8 0–FFFF (Hex) 0000 O O O O O...

  • Page 203: Parameter Mode - Protective Function Group (Prt)

    Table of Functions 8.11 Parameter Mode – Protective Function Group (PRT) Protective Function Group (PAR  PRT) Control Mode Communi- Shift in Initial Name Setting Range Opera- cation LCD Display Value tion Address Jump Code Jump code 0–99 O O O O O 0 Normal Duty 1:Heavy 0h1B04...
  • Page 204 Table of Functions Control Mode Communi- Shift in Initial cation LCD Display Name Setting Range Opera- Value tion Address 0h1B15 OL Trip Level Overload trip level 30–200 (%) O O O O O 0h1B16 OL Trip Time Overload trip time 0–60 (sec) 60.0 O O O O O...
  • Page 205 Table of Functions Control Mode Communi Shift in Initial -cation LCD Display Name Setting Range Opera- Value tion Address Bit 0000–1111 Accelerating 50 0h1B32 Stall Prevent Stall prevention Steady speed 0000 O O X O X Decelerating Flux Breaking Start frequency 51 0h1B33 Stall Freq 1 Stall frequency 1...

  • Page 206: Parameter Mode - 2Nd Motor Function Group (M2)

    Table of Functions 8.12 Parameter Mode – 2nd Motor Function Group (M2) 2nd Motor Function Group (PAR  M2) Control Mode Communi Shift in -cation LCD Display Name Setting Range Initial Value Opera- tion Address 00 - Jump Code Jump code 0–99 O O X O X Below 75 kW 20.0...

  • Page 207: Trip Mode (Trp Current (Or Last-X))

    Table of Functions 8.13 Trip Mode (TRP Current (or Last-x)) Trip Mode (TRP Last-x) No. LCD Display Name Setting Range Initial Value Trip Name ( x) Trip type display Output Freq Output frequency at trip Output Current Output current at trip Inverter State Acc/Dec status at trip DCLink Voltage...
  • Page 208 Table of Functions LCD Display Name Setting Range Initial Value 4 Output Power Voltage 5 WHour Counter 6 DCLink Voltage 7 DI State 8 DO State 9 V1 Monitor (V) 10 V1 Monitor (%) 11 I1 Monitor (mA) 12 I1 Monitor (%) 13 V2 Monitor (V) 14 V2 Monitor (%) 15 I2 Monitor (mA)
  • Page 209 Table of Functions LCD Display Name Setting Range Initial Value 1 JOG Key 2 Local/Remote 3 UserGrp SelKey 0 None Macro Select Macro function item 1 Draw App 0:None 2 Traverse 0 No Erase All Trip Delete trip history 0:No 1 Yes 0 No UserGrp AllDel...

  • Page 210: User/Macro Mode - Draw Operation Function GroupMc1

    Table of Functions 8.15 User/Macro Mode – Draw Operation Function GroupMC1 U&M  MC1 No. LCD Display Name Setting Range Initial Value Jump Code Jump code 0–99 Below 75 kW 20 Acc Time Acceleration time 0–600 (sec) Above 90 kW 60 Below 75 kW 30 Dec Time Deceleration time...

  • Page 211: User/Macro Mode - Traverse Operation Function Group (Mc2)

    Table of Functions 8.16 User/Macro mode – Traverse Operation Function Group (MC2) Traverse Operation Function Group (U&M  MC2) LCD Display Name Setting Range Initial Value Jump Code Jump code 0–99 Below 75 kW Acc Time Acceleration time 0–600 (sec) Above 90 kW Below 75 kW Dec Time...

  • Page 212: Peripheral Devices

    Peripheral Devices 9 Peripheral Devices The reference diagram below shows a typical system configuration showing the inverter and peripheral devices. Prior to installing the inverter, ensure that the product is suitable for the application (power rating, capacity, etc.). Also, ensure that all of the required peripherals and optional devices (resistor brakes, contactors, noise filters, etc.) are available.

  • Page 213: Wiring Switch, Electronic Contactor, And Reactor Specifications

    Peripheral Devices 9.1 Wiring Switch, Electronic Contactor, and Reactor Specifications 9.1.1 Wiring Switch, Short Circuit Switch, and Electronic Contactor Wiring Switch Short Circuit Switch Electronic Contactor Inverter METASOL SUSOL Capacity Rated Rated Rated Rated Model Model Model Model current[A] current[A] current[A] current[A] 0008iS7-2 ABS33c...
  • Page 214 Peripheral Devices Wiring Switch Short Circuit Switch Electronic Contactor Inverter METASOL SUSOL Capacity Rated Rated Rated Rated Model Model Model Model current[A] current[A] current[A] current[A] 0900iS7-4 ABS403c UTS400 EBS403c MC-330a 1100iS7-4 ABS603c UTS600 EBS603c MC-400a 1320iS7-4 ABS603c UTS600 EBS603c MC-400a 1600iS7-4 ABS603c UTS600 EBS603c...

  • Page 215: Reactors

    Peripheral Devices 9.1.2 Reactors DC Reactor Specifications The iS7 200 V / 400V 30–75 kW, 400 V/280–375 kW models are not supplied with a built-in DC reactor. Refer to the following specifications tables for different models to choose an appropriate DC reactor for your application. <200V/30–75kW>...
  • Page 216 Installation of an AC reactor is not necessary if a DC reactor is already installed in the inverter. To avoid power loss resulting from the incorrect installation of an AC reactor, contact LSIS Customer Support to ensure that your model type and application requires the installation of an AC reactor.
  • Page 217 Peripheral Devices AC reactor specifications Inverter capacity Heavy duty Normal duty 0015iS7-4 4.81 3.23 0022iS7-4 3.23 2.34 0037iS7-4 2.34 1.22 0055iS7-4 1.22 1.14 0075iS7-4 1.14 0.81 0110iS7-4 0.81 0.61 0150iS7-4 0.61 0.45 0185iS7-4 0.45 0.39 0220iS7-4 0.39 0.287 0300iS7-4 0.287 0.232 0370iS7-4 0.232...

  • Page 218: Dynamic Braking Unit (Dbu) And Resistor

    Peripheral Devices 9.1.3 Dynamic Braking Unit (DBU) and Resistor Dynamic Braking Unit Specifications Reference- Capacity of Terminal UL form Type Voltage Braking unit applied motor arrangement & dimensions 30–37 kW SV370DBU-2U 200 V 45–55 kW SV550DBU-2U Type A 75 kW SV370DBU-2U, 2Set 30–37 kW SV370DBU-4U...
  • Page 219 LSLV2200DBU-4HN, 280–375 kW 2Set Note 1) For model types with a rated capacity of 180 kW and above, contact LSIS Customer Support for detailed information. Note The 0.75–22kW (200 V/400 V) models are provided with a built-in dynamic braking unit.
  • Page 220 Peripheral Devices Group 3 (75 kW DB unit) Group 4 (220 kW DB unit) Terminal Description Ground Terminal Connect to the B2 terminal of a braking resistor. Connect to the B1 terminal of a braking resistor. Connect to the N terminal of an inverter. Connect to the P terminal of an inverter.
  • Page 221 Peripheral Devices Group 6 A frame (37 kW, 74 kW-4) B/C frame (75 kW-2, 90-220 kW) Terminal Description P (+) Connect to the P terminal of an inverter (DC bus). N ( - ) Connect to the N terminal of an inverter (DC bus). Connect to the B1 terminal of an external braking resistor.

  • Page 222: Db Unit Dimensions

    Peripheral Devices DB Unit Terminal Description Connect to the B1 terminal of a DB resistor. Connect to the B2 terminal of a DB resistor. 9.1.4 DB Unit Dimensions Group 1...
  • Page 223 Peripheral Devices Group 2...
  • Page 224 Peripheral Devices Group 3...
  • Page 225 Peripheral Devices Group 4...
  • Page 226 Peripheral Devices Group 5 Motor Voltage Dimensions (mm) Hole position Weight Hole size capacity (φ) [kW] [kg] 1.50 1.55 1.57 1.84 227.4 76.4 215.4 1.53 1.55 1.56 1.85...
  • Page 227 Peripheral Devices Group 6 Motor Hole Voltage Dimensions (mm) Hole position Weight capacity %ED size Frame (φ) [kW] [kg] 3.77 208.5 3.84 3.98 8.26 165.2 8.48 329.5 8.30 8.40 9.40 369.5 9.70...

  • Page 228: Indicators On The Db Unit

    Peripheral Devices 9.1.5 Indicators on the DB unit On a DB unit, there are three LED indicators (one red and two green indicators) that indicate the operating condition of the DB unit. Indicator Color Location Description name Turns on when the main power is supplied to the unit (if a DB Power Middle unit is connected to an inverter, the power indicator is turned...
  • Page 229 Peripheral Devices Inverter Resistance Wattage Wiring DB Unit Model type Type Reference capacity (kW) [ohm] 0.75 TYPE 1 1.25 TYPE 1 1.25 MCRB400W50 TYPE 1 MCRB600W33 TYPE 2 150% MCRM800W20 TYPE 3 6.63 braking torque, MCRM1200W15 15 1200 TYPE 3 6.63 5%ED MCRM2400W10 10...

  • Page 230: Db Resistor Dimensions

    Peripheral Devices Inverter Resistance Wattage Wiring DB Unit Model type Type Reference capacity (kW) [ohm] 15,000 17,000 20,000 25,000 30,000 30,000 40,000 60,000 60,000 If you install multiple DB units in parallel, the combined resistance value must match the • resistance value in the table above.
  • Page 231 Peripheral Devices TYPE 1 (Maximum 400 Watts) TYPE 2 (Maximum 600 Watts)

  • Page 232: Keypad Extension Cable For Remote Control (Optional)

    Peripheral Devices TYPE 3, 4, and 5 9.1.8 Keypad Extension Cable for Remote Control (Optional) Included items Items Keypad bracket Remote cable (2 m/3 m)
  • Page 233 Peripheral Devices Keypad Bracket Dimensions Remote Cable Specifications Model type Part name 64110009 INV, iS7 REMOTE CABLE (2 M) 64110010 INV, iS7 REMOTE CABLE (3 M)
  • Page 234 Peripheral Devices Installing the Remote Cable Refer to the following figure to install the remote cable to extend the keypad cable length. If a “Line Check” message is displayed on the keypad display and the keypad is not operating correctly after installing the remote cable, check the cable connection on both sides. Do not extend the keypad cable using a third-party extension cable.

  • Page 235: Safety Funtion Sto(Safe Torque Off)

    Safety Funtion STO(Safe Torque Off) 10 Safety Funtion STO(Safe Torque Off) The iS7 Inverter series provides resilient safety features via optional safety expansion module. When an emergency arises, it instantly blocks inverter output to protect the operator and reduce the risk. 10.1 Safety Standard Product The performance levels for the safety function are as follows.

  • Page 236: Safety Function Wiring Diagram

    Safety Funtion STO(Safe Torque Off) 10.2.1 Safety Function Wiring Diagram...

  • Page 237: Installing The Safety Board To 0.75-160 Kw Product

    Safety Funtion STO(Safe Torque Off) 10.2.2 Installing the Safety Board to 0.75–160 kW Product Because 0.75-160kW products provide safety purpose product, therefore please use this product with safety option. Safety options are not available for general products. 10.2.3 Installing the Safety Board to 185–375 kW Product Please buy safety option and apply to standard products because there is no safety product for 185-375kW.

  • Page 238: Safety Function Terminal Description

    Safety Funtion STO(Safe Torque Off) 10.2.4 Safety Function Terminal Description 24S – SE (SFT1) 24S – SP (SFT2) SR + SR- Short: Normal operation Short: Normal operation B Contact relay output Open: Safety Trip (output terminal Open: Safety Trip (output blockage) blockage ) 10.2.5 Cable Specification for Signal Terminal Block Wiring Terminal...

  • Page 239: Marine Certification

    Marine classification is that the structure and equipment of the ship has been estimated from the test with the certain standards for certificate issued and given by classification society. SV-IS7 Series is certificated with product testing, process, production equipment and test equipment to install on the shipping.

  • Page 240: Marine Certification Models For Sv-Is7 Products

    Marine Certification 11.4 Marine Certification Models for SV-iS7 Products Type SV0008iS7-2□□□□V SV0015iS7-2□□□□V SV0022iS7-2□□□□V SV0037iS7-2□□□□V SV0055iS7-2□□□□V SV0075iS7-2□□□□V SV0110iS7-2□□□□V 3-Phase SV0150iS7-2□□□□V 200V SV0185iS7-2□□□□V SV0220iS7-2□□□□V SV0300iS7-2□□□□V SV0370iS7-2□□□□V SV0450iS7-2□□□□V SV0550iS7-2□□□□V SV0750iS7-2□□□□V SV0008iS7-4□□□□V SV0015iS7-4□□□□V SV0022iS7-4□□□□V SV0037iS7-4□□□□V SV0055iS7-4□□□□V SV0075IS7-4□□□□V 3-Phase 400V SV0110iS7-4□□□□V SV0150iS7-4□□□□V SV0185iS7-4□□□□V SV0220iS7-4□□□□V SV0300iS7-4□□□□V...
  • Page 241 Marine Certification Type SV0450iS7-4□□□□V SV0550iS7-4□□□□V SV0750iS7-4□□□□V SV0900iS7-4□□□□V SV1100iS7-4□□□□V SV1320iS7-4□□□□V SV1600iS7-4□□□□V SV1850iS7-4□□□□V SV2200iS7-4□□□□V SV2800iS7-4□□□□V SV3150iS7-4□□□□V SV3750iS7-4□□□□V...

  • Page 242: Using A Single Phase Power Source

    12 Using a Single Phase Power Source 12.1 Single Phase Rating The SV-iS7 series inverter is a three-phase variable frequency drive (VFD). When applying single- phase power to a three-phase VFD, there are several limitations that need to be considered.

  • Page 243: Power(Hp), Input Current And Output Current

    Using a Single Phase Power Source <Figure-2 Typical Single-Phase Configuration> 12.2 Power(HP), Input Current and Output Current When using a three-phase VFD with single-phase input, derating the drive’s output current and horsepower will be necessary due to the increase in DC bus ripple voltage and current. In addition, the input current through the remaining two phases on the diode bridge converter will approximately double, creating another derating consideration for the VFD.

  • Page 244: Input Frequency And Voltage Tolerance

    Using a Single Phase Power Source Single-Phase Current Rating (200V/60Hz)* Output Amp Input Amp [kW] [HP] HD [A] ND [A] HD [A] ND [A] 5.5kW 22.1 28.6 7.5kW 28.6 41.2 11kW 44.3 54.7 15kW 55.9 69.7 18.5kW 70.8 82.9 22kW 85.3 116.1 30kW...

  • Page 245: Wiring And Peripheral Device

    Using a Single Phase Power Source 12.4 Wiring and Peripheral Device It is important that input wiring and branch circuit protection be selected based on the drive’s single-phase input current rating indicated in Table 1–2. The single-phase input current after derating differs from the three-phase input indicated on the VFD nameplate.
  • Page 246 Selection FUSE MCCB Choke Contactor [kW] [HP] Output Amp Input Amp HD [A] ND [A] HD [A] ND [A] R,S,T U,V,W [A] [V] [mH] [A] LSIS(UL Type) 0.75kW 1 UTE100/15A MC-9b 1.5kW 2 10.6 UTE100/15A MC-12b 2.2kW 3 11.2 14.9...
  • Page 247 DC Link FUSE MCCB Contactor Choke [kW] [HP] Output Amp Input Amp HD [A] ND [A] HD [A] ND [A] R,S,T U,V,W [A] [V] [mH] [A] LSIS(UL Type) 0.75kW 1 UTE100/15A MC-9b 1.5kW 2 UTE100/15A MC-9b 2.2kW 3 UTE100/15A MC-12b 3.7kW 5...

  • Page 248: Other Considerations

    Using a Single Phase Power Source 12.5 Other Considerations The following lists other precautions that need to be considered when using a three-phase VFD using single-phase power source. Depending on the increased DC ripple, sensorless mode may result in poor performance •...

  • Page 249: Product Warranty

    During the product warranty period, warranty service (free of charge) is provided for product malfunctions caused under normal operating conditions. For warranty service, contact an official LSIS agent or service center. Non-Warranty Service A service fee will be incurred for malfunctions in the following cases: intentional abuse or negligence •...
  • Page 250 Product Warranty acts of nature (fire, flood, earthquake, gas accidents etc.) • modifications or repair by unauthorized persons • missing authentic LSIS rating plates • expired warranty period • Visit Our Website Visit us at http://www.lsis.biz for detailed service information.
  • Page 251 Product Warranty UL Mark The UL mark applies to products in the United States and Canada. This mark indicates that UL has tested and evaluated the products and determined that the products satisfy the UL standards for product safety. If a product received UL certification, this means that all components inside the product had been certified for UL standards as well.

  • Page 252: Index

    Index Index 0.75–22 kW (200 V/400 V) ........60 [ESC] key ..................... 83 185–220 kW (400 V) ..........63 [Mode] key ..................83 280–375 kW (200 V/400 V) ......... 64 [PROG / Ent] key................83 30–75 kW (200 V/400 V) ........61 [UP] key....................
  • Page 253 Index SV3150-3750iS7 (400 V, IP00 Type) ....34 keypad exterior and dimensions (UL Enclosed Type 12, [ESC] key ..............83 [Mode] key ............. 83 IP54 Type) ................... 35 [PROG / Ent] key ........... 83 exterior and dimensions (UL Enclosed Type12, navigating between groups......
  • Page 254 Index 1sec ............... 136 speed unit selection (Hz or Rpm) ........ 127 torque....................56 start at power-on U/V/W terminal ................56 Power-on Run ............. 134 surge killer ..................56 Unipolar ....................73 technical specifications ............... 7 User & Macro mode ..............87 terminal wiring diagram ............

Table of Contents

Save PDF
