Page 1 This operation manual is intended for users with basic knowledge of electricity and electric devices. * LSLV-S100 is the official name for S100.
Page 2 Safety Information Safety Information Read and follow all safety instructions in this manual precisely to avoid unsafe operating conditions, property damage, personal injury, or death. Safety symbols in this manual Indicates an imminently hazardous situation which, if not avoided, will result in severe injury or death. Indicates a potentially hazardous situation which, if not avoided, could result in injury or death.
Page 3 Safety Information • This equipment must be grounded for safe and proper operation. • Do not supply power to a faulty inverter. If you find that the inverter is faulty, disconnect the power supply and have the inverter professionally repaired. •...
Page 4 Maximum allowed prospective short-circuit current at the input power connection is defined in IEC 60439-1 as 100 kA. Depending on the selected MCCB, the LSLV-S100 Series is suitable for use in circuits capable of delivering a maximum of 100 kA RMS symmetrical amperes at the drive's maximum rated voltage.
Page 5: Table Of Contents
Table of Contents Table of Contents Preparing the Installation ....................1 Product Identification........................1 Part Names ............................3 Installation Considerations ......................4 Selecting and Preparing a Site for Installation ..............5 Cable Selection ..........................8 Installing the Inverter ....................11 Mounting the Inverter ......................13 Cable Wiring ...........................
Page 6 Table of Contents 4.1.1 Keypad as the Source (KeyPad-1 setting) ............66 4.1.2 Keypad as the Source (KeyPad-2 setting) ............67 4.1.3 V1 Terminal as the Source ..................67 4.1.4 Setting a Frequency Reference with Input Voltage (Terminal I2) ..75 4.1.5 Setting a Frequency with TI Pulse Input ............
Page 7 Table of Contents 4.14.1 Manual Torque Boost ..................... 101 4.14.2 Auto Torque Boost-1 ....................102 4.14.3 Auto Torque Boost-2 ....................102 4.15 Output Voltage Setting ......................102 4.16 Start Mode Setting ........................103 4.16.1 Acceleration Start ..................... 103 4.16.2 Start After DC Braking .................... 103 4.17 Stop Mode Setting ........................
Page 8 5.3.1 LS INV 485 Protocol ....................133 5.3.2 Modbus-RTU Protocol ................... 138 Compatible Common Area Parameter................142 S100 Expansion Common Area Parameter ..............145 5.5.1 Monitoring Area Parameter (Read Only) ............145 5.5.2 Control Area Parameter (Read/ Write) ............151 5.5.3...
Page 9 Table of Contents Troubleshooting Other Faults ..................... 237 Maintenance ......................241 Regular Inspection Lists ......................241 8.1.1 Daily Inspections ...................... 241 8.1.2 Annual Inspections ....................242 8.1.3 Bi-annual Inspections .................... 244 Replacing Major Components .................... 244 8.2.1 Exchange Cycle for Major Components ............244 8.2.2 How to Replace the Cooling Fans ..............
Page 10 Table of Contents...
Page 12: Product Identification
To install the inverter correctly and safely, carefully read and follow the instructions. 1.1 Product Identification The S100 Inverter is manufactured in a range of product groups based on drive capacity and power source specifications. Product name and specifications are detailed on the rating plate. The illustration on the next page shows the location of the rating plate.
Page 13: Preparing The Installation
Preparing the Installation...
Page 14: Part Names
Preparing the Installation 1.2 Part Names The illustration below displays part names. Details may vary between product groups. Note The grounding terminal cover of EMC is not existed in the 55-75kW inverters.
Page 15: Installation Considerations
Preparing the Installation 1.3 Installation Considerations Inverters are composed of various precision, electronic devices, and therefore the installation environment can significantly impact the lifespan and reliability of the product. The table below details the ideal operation and installation conditions for the inverter. Items Description Ambient Temperature*...
Page 16: Selecting And Preparing A Site For Installation
Preparing the Installation 1.4 Selecting and Preparing a Site for Installation When selecting an installation location consider the following points: • The inverter must be installed on a wall that can support the inverter’s weight. • The location must be free from vibration. Vibration can adversely affect the operation of the inverter.
Page 17 Preparing the Installation • Ensure sufficient air circulation is provided around the inverter when it is installed. If the inverter is to be installed inside a panel, enclosure, or cabinet rack, carefully consider the position of the inverter’ s cooling fan and the ventilation louver. The cooling fan must be positioned to efficiently transfer the heat generated by the operation of the inverter.
Page 18 Preparing the Installation • If you are installing multiple inverters, of different ratings, provide sufficient clearance to meet the clearance specifications of the larger inverter.
Page 19: Cable Selection
Preparing the Installation 1.5 Cable Selection When you install power and signal cables in the terminal blocks, only use cables that meet the required specification for the safe and reliable operation of the product. Refer to the following information to assist you with cable selection. •...
Page 20 Preparing the Installation Signal (Control) Cable Specifications Recommended wire thickness (AWG) With Crimp Terminal Torque Without Crimp Terminal Electrical Specifications Terminal screw [Nm] Terminal Connectors Connections (Bootlace (Bare wire) Ferrule) P1–P7, CM Output current/voltage: 12 V, 20 mA volume resistance: 1–5 kΩ Maximum input voltage: -12V –...
Page 21 Preparing the Installation...
Page 23: Installing The Inverter
Installing the Inverter 2 Installing the Inverter This chapter describes the physical and electrical installation methods, including mounting and wiring of the product. Refer to the flowchart and basic configuration diagram provided below to understand the procedures and installation methods to be followed to install the product correctly.
Page 24 Installing the Inverter Basic Configuration Diagram The reference diagram below shows a typical system configuration showing the inverter and peripheral devices. Prior to installing the inverter, ensure that the product is suitable for the application (power rating, capacity, etc). Ensure that all of the required peripherals and optional devices (resistor brakes, contactors, noise filters, etc.) are available.
Page 25: Mounting The Inverter
Installing the Inverter 2.1 Mounting the Inverter Mount the inverter on a wall or inside a panel following the procedures provided below. Before installation, ensure that there is sufficient space to meet the clearance specifications, and that there are no obstacles impeding the cooling fan’s air flow. Select a wall or panel suitable to support the installation.
Page 26 Installing the Inverter Mount the inverter on the wall or inside a panel using the two upper bolts, and then fully tighten the mounting bolts. Ensure that the inverter is placed flat on the mounting surface, and that the installation surface can securely support the weight of the inverter.
Page 27 Installing the Inverter • Do not transport the inverter by lifting with the inverter’s covers or plastic surfaces. The inverter may tip over if covers break, causing injuries or damage to the product. Always support the inverter using the metal frames when moving it. •...
Page 28: Cable Wiring
Installing the Inverter 2.2 Cable Wiring Open the front cover, remove the cable guides and control terminal cover, and then install the ground connection as specified. Complete the cable connections by connecting an appropriately rated cable to the terminals on the power and control terminal blocks. Read the following information carefully before carrying out wiring connections to the inverter.
Page 29 Installing the Inverter Step 1 Front Cover, Control Terminal Cover and Cable Guide The front cover, control terminal cover and cable guide must be removed to install cables. Refer to the following procedures to remove the covers and cable guide. The steps to remove these parts may vary depending on the inverter model.
Page 30 Installing the Inverter Step 2 Ground Connection Remove the front cover, cable guide, and the control terminal cover. Then follow the instructions below to install the ground connection for the inverter. Locate the ground terminal and connect an appropriately rated ground cable to the terminals.
Page 31 Installing the Inverter Step 3 Power Terminal Wiring The following illustration shows the terminal layout on the power terminal block. Refer to the detailed descriptions to understand the function and location of each terminal before making wiring connections. Ensure that the cables selected meet or exceed the specifications in 1.5 Cable Selection on page 8 before installing them.
Page 32 Installing the Inverter 30~75kW (3-phase) Power Terminal Labels and Descriptions Terminal Labels Name Description R(L1)/S(L2)/T(L3) AC power input terminal Mains supply AC power connections. P2(+)/N(-) DC link terminal DC voltage terminals. P3(+)/N(-) Brake unit terminals Brake unit wiring connection. 3-phase induction motor wiring U/V/W Motor output terminals connections.
Page 33 Installing the Inverter Note • Do not use 3 core cables to connect a remotely located motor with the inverter. • When you operating Brake resistor, the motor may vibrate under the Flux braking operation. In this case, please turn off the Flux braking(PRT-50). •...
Page 34 Installing the Inverter Step 4 Control Terminal Wiring The illustrations below show the detailed layout of control wiring terminals, and control board switches. Refer to the detailed information provided below and 1.5 Cable Selection on page 8 before installing control terminal wiring and ensure that the cables used meet the required specifications.
Page 35 Installing the Inverter...
Page 36 Installing the Inverter Input Terminal Labels and Descriptions Function Label Name Description Multi-function Multi- P1–P7 Configurable for multi-function input terminals. Input 1-7 function terminal Common Common terminal for analog terminal inputs and configuration Sequence outputs. Used to setup or modify a frequency reference via analog voltage or current input.
Page 37 DC voltage. Output Signal Specifications: • Output frequency: 0–32 kHz • Output voltage: 0–12V When connecting to a pulse between the S100 inverters, Pulse Output • Standard I/O(30~75kW) <-> Multiple I/O(0.4~22kW) : Connect to TO -> TI, CM -> CM •...
Page 38 Installing the Inverter Function Label Name Description (A1 and C1 open connection) The signal is generated while operating. Define and use Multi-functional A2, C2 the multi-functional relay output terminal (Less than relay output terminal AC250 V 5A, Less than DC30 V 5A). Terminal S+/S-/SG Used to send or receive RS-485 signals.
Page 39 Doing so may result in electric shock. Step 5 PNP/NPN Mode Selection The S100 inverter supports both PNP (Source) and NPN (Sink) modes for sequence inputs at the terminal. Select an appropriate mode to suit requirements using the PNP/NPN selection switch (SW1) on the control board.
Page 40 Installing the Inverter NPN Mode (Sink) Select NPN using the PNP/NPN selection switch (SW1). Note that the factory default setting is NPN mode. CM is is the common ground terminal for all analog inputs at the terminal, and P24 is 24V internal source.
Page 41 Step 6 Disabling the EMC Filter for Power Sources with Asymmetrical Grounding S100, 400 V 30–45 kW (3 phase) inverters have EMC filters built-in and activated as a factory default design. An EMC filter prevents electromagnetic interference by reducing radio emissions from the inverter.
Page 42 Installing the Inverter Disabling the Built-in EMC Filter Refer to the figures below to locate the EMC filter on/off terminal and replace the metal bolt with the plastic bolt. If the EMC filter is required in the future, reverse the steps and replace the plastic bolt with the metal bolt to reconnect the EMC filter.
Page 43 Installing the Inverter If the EMC filter is required in the future, reverse the steps and connect the EMC ground cable to the right terminal to enable the EMC filter. Note The terminal on the right is used to ENABLE the EMC filter (factory default). The terminal on the left is used to DISABLE the EMC filter (for power sources with asymmetrical grounding).
Page 44 Installing the Inverter Step 7 Selecting the brake unit Select the brake unit as following: UL form Capacity of applied motor Braking unit 30~37kW SV370DBU-4U UL type 45~55kW SV550DBU-4U (A type) 75kW SV750DBU-4U 30~37kW SV037DBH-4 Non UL type SV075DBH-4 (B type) 45~75kW SV075DB-4 LSLV0370DBU-4HN...
Page 45: Post-Installation Checklist
Installing the Inverter 2.3 Post-Installation Checklist After completing the installation, check the items in the following table to make sure that the inverter has been safely and correctly installed. Items Check Point Ref. Result Is the installation location appropriate? Does the environment meet the inverter’s operating conditions? Installation Does the power source match the inverter’s rated input?
Page 46 Installing the Inverter Items Check Point Ref. Result Are the control terminal screws tightened to their specified p.16 torques? Is the total cable length of all control wiring < 165ft (100m)? p.27 Is the total length of safety wiring < 100ft (30m)? p.27 Are optional cards connected correctly? Is there any debris left inside the inverter?
Page 47: Test Run
Installing the Inverter 2.4 Test Run After the post-installation checklist has been completed, follow the instructions below to test the inverter. Before starting a test drive, check the wiring conditions. Turn on the power supply to the inverter. Ensure that the keypad display light is on. Select the command source (Set the DRV code).
Page 48 Installing the Inverter Note If the forward command (Fx) is on, the motor should rotate counterclockwise when viewed from the load side of the motor. If the motor rotates in the reverse direction, switch the cables at the U and V terminals. Remarque Si la commande avant (Fx) est activée, le moteur doit tourner dans le sens anti-horaire si on le regarde côté...
Page 49: Learning To Perform Basic Operations
Learning to Perform Basic Operations 3 Learning to Perform Basic Operations This chapter describes the keypad layout and functions. It also introduces parameter groups and codes required to perform basic operations. The chapter also outlines the correct operation of the inverter before advancing to more complex applications.
Page 50 Learning to Perform Basic Operations Name Description [MODE] Key Used to switch between modes. [PROG / Ent] Key Used to select, confirm, or save a parameter value. [UP] key Switch between codes or increase or decrease parameter values. [DOWN] key [LEFT] key Switch between groups or move the cursor during parameter [RIGHT] key...
Page 51: About The Display
Learning to Perform Basic Operations 3.1.2 About the Display Monitor mode display Parameter settings display...
Page 52 Learning to Perform Basic Operations Names displayed in monitor mode and parameter settings No. Names displayed in monitor mode No. Names displayed in parameter settings Mode Mode Operating/frequency command Group Multi-functional key settings Multi-functional key settings Inverter operation status Inverter operation status Items displayed in the status window Items displayed in the status window Monitor mode display 1...
Page 53 Learning to Perform Basic Operations Name Display Description Jog frequency command Int 485 frequency command 1 ~9, A~F Multi-step frequency command JOG Key Keypad JOG operation mode Multi- Local/Remote Able to select either local or remote operation functional key Register or delete user group parameters in parameter settings UserGrpSelKey mode...
Page 54: Display Modes
Learning to Perform Basic Operations 3.1.3 Display Modes The S100 inverter uses 5 modes to monitor or configure different functions. The parameters in Parameter mode are divided into smaller groups of relevant functions. Press the [Mode] key to change to Parameter mode.
Page 55 Learning to Perform Basic Operations Table of Display Modes The following table lists the 5 display modes used to control the inverter functions. Mode Name Keypad Display Description Displays the inverter’s operation status information. In this mode, information including the inverter’s frequency Monitor mode reference, operation frequency, output current, and voltage may be monitored.
Page 56 Learning to Perform Basic Operations Parameter Setting Mode The following table lists the functions groups under Parameter mode. Function Group Name Keypad Display Description Configures basic operation parameters. These include Drive ACC/Dec time settings, operation command settings, and functions necessary for operation. Configures basic operation parameters.
Page 57: Learning To Use The Keypad
Learning to Perform Basic Operations 3.2 Learning to Use the Keypad The keypad enables movement between groups and codes. It also enables users to select and configure functions. At code level, you can set parameter values to turn specific functions on or off or decide how the functions will be used.
Page 58 Learning to Perform Basic Operations Mode selection in factory default condition • When the power is turned on, Monitor mode is displayed. • Press the [MODE] key. • Parameter mode • Press the [MODE] key. • Config (CNF) mode • Press the [MODE] key. •...
Page 59 Learning to Perform Basic Operations • Parameter mode • Press the [MODE] key. • Trip mode • Press the [MODE] key. • CNF mode • Press the [MODE] key. • Monitor mode is displayed again.
Page 60: Switching Groups
Learning to Perform Basic Operations 3.2.2 Switching Groups Press the [MODE] key to display a specific mode. Modes displayed change in the following order:...
Page 61 Learning to Perform Basic Operations Switching between Groups in Parameter Display Mode After entering Parameter mode from Monitor mode, press the [ ▶] key to change the display as shown below. Press the [ ◀] key to return to the previous mode. •...
Page 62: Navigating Through The Codes (Functions)
Learning to Perform Basic Operations 3.2.3 Navigating through the Codes (Functions) Code Navigation in Monitor mode In monitor mode, press the [▲], [▼] key to display frequency, the output current, or voltage according to the cursor position. • When the power is turned on, Monitor mode is displayed. •...
Page 63 Learning to Perform Basic Operations • Information about the first item in Monitor mode (Frequency) is displayed. • Information about the first item in Monitor mode (Frequency) disappears and the cursor appears to the left of the first item. Code Navigation in Parameter mode The following examples show you how to move through codes in different function groups (Drive group and Basic group) in Parameter mode.
Page 64: Navigating Directly To Different Codes
Learning to Perform Basic Operations 3.2.4 Navigating Directly to Different Codes Parameter mode and Config mode allow direct jumps to specific codes. The code used for this feature is called the Jump Code. The Jump Code is the first code of each mode. The Jump Code feature is convenient when navigating for a code in a function group that has many codes.
Page 65: Parameter Settings
Parameter settings Parameter settings available in Monitor mode The S100 inverter allows basic parameters to be modified in Monitor mode. The following example shows how to set the frequency. • Make sure that the cursor is at the frequency reference item and that the frequency setting is set to ‘Keypad’...
Page 66 Learning to Perform Basic Operations Parameter settings in other modes and groups The following example shows how to change the frequency in the Drive group. This example can also be applied to other modes and groups. • This is the initial display for Parameter mode. •...
Page 67: Monitoring The Operation
Learning to Perform Basic Operations 3.2.6 Monitoring the Operation How to use Monitor mode There are 3 types of items that may be monitored in Monitor mode. Some items, including frequency, may be modified. Users can select the items to be displayed in Config mode (CNF). •...
Page 68 Learning to Perform Basic Operations Items available for monitoring Mode Number Display Setting Range Initial value Anytime Para Frequency 0: Frequency Monitor Line-1 Speed 0: Frequency Monitor Line-2 Output Current 2:Output Current Output Voltage Output Power WHour Counter DCLink Voltage DI State DO State V1 Monitor[V]...
Page 69 Learning to Perform Basic Operations How to use the status bar On the top-right corner of the display, there is a display item. This item is displayed as long as the inverter is on, regardless of the mode the inverter is operating in. •...
Page 70: Fault Monitoring
Learning to Perform Basic Operations 3.3 Fault Monitoring 3.3.1 Monitoring Faults during Inverter Operation The following example shows how to monitor faults that occurred during inverter operation. • If a fault trip occurs during inverter operation, the inverter enters Trip mode automatically and displays the type of fault trip that occurred.
Page 71: Monitoring Multiple Fault Trips
Learning to Perform Basic Operations 3.3.2 Monitoring Multiple Fault Trips The following example shows how to monitor multiple faults that occur at the same time. • If multiple fault trips occur at the same time, the number of fault trips occurred is displayed on the right side of the fault trip type.
Page 72 Learning to Perform Basic Operations Fault trip history saving and monitoring When fault trips occur, the trip mode saves the content. Up to five fault trips are saved in the history. Trip mode saves when the inverter is reset, and when a Low Voltage fault trip occurs due to power outages.
Page 73: Parameter Initialization
Learning to Perform Basic Operations 3.4 Parameter Initialization The following example demonstrates how to revert all the parameter settings back to the factory default (Parameter Initialization). Parameter initialization may be performed for separate groups in Parameter mode as well. • Monitor mode is displayed. •...
Page 74 Learning to Perform Basic Operations...
Page 75: Learning Basic Features
Learning Basic Features 4 Learning Basic Features This chapter describes the basic features of the S100 inverter. Check the reference page in the table to see the detailed description for each of the advanced features. Basic Tasks Description Ref. Frequency reference source Configures the inverter to allow you to setup or modify p.66...
Page 76 Learning Basic Features Basic Tasks Description Ref. Motor rotation control Configures the inverter to limit a motor’s rotation direction. p.86 Configures the inverter to start operating at power-on. With this configuration, the inverter begins to run and the motor Automatic start-up at accelerates as soon as power is supplied to the inverter.
Page 77 Learning Basic Features Basic Tasks Description Ref. configuration is for loads that require a large amount of starting torque, such as elevators or lifts. Adjusts the output voltage to the motor when the power Output voltage adjustment supply to the inverter differs from the motor’s rated input p.102 voltage.
Page 78: Setting Frequency Reference
Learning Basic Features 4.1 Setting Frequency Reference The S100 inverter provides several methods to setup and modify a frequency reference for an operation. The keypad, analog inputs [for example voltage (V1, V2) and current (I2) signals], or RS- 485 (digital signals from higher-level controllers, such as PC or PLC) can be used. If UserSeqLink is selected, the common area can be linked with user sequence output and can be used as frequency reference.
Page 79: Keypad As The Source (Keypad-2 Setting)
Learning Basic Features 4.1.2 Keypad as the Source (KeyPad-2 setting) You can use the [▲] and [▼] keys to modify a frequency reference. To use this as a second option, set the keypad as the source of the frequency reference, by going to 07 (Frequency reference source) code in the DRV group and change the parameter value to 1 (Keypad-2).
Page 80 Learning Basic Features Group Code Name LCD Display Parameter Setting Setting Range Unit Frequency reference Freq Ref Src 0–12 source 0.00– Frequency at maximum Maximum Freq at 100% Max. analog input frequency Frequency V1 Monitor V1 input monitor 0.00 0.00–12.00 V1 polarity options V1 Polarity Unipolar...
Page 81 Learning Basic Features 0–10 V Input Voltage Setting Details Code Description Configures the frequency reference at the maximum input voltage when a potentiometer is connected to the control terminal block. A frequency set with code IN-01 becomes the maximum frequency only if the value set in code IN-11 (or IN-15) is 100(%).
Page 82 Learning Basic Features Code Description [Volt x1–IN-11 V1 Perc y2] Inverts the direction of rotation. Set this code to 1 (Yes) if you need the motor to IN-16 V1 Inverting run in the opposite direction from the current rotation. Quantizing may be used when the noise level is high in the analog input (V1 terminal) signal.
Page 83 Learning Basic Features Code Description [V1 Quantizing]...
Page 84 Learning Basic Features 4.1.3.2 Setting a Frequency Reference for -10–10 V Input Set the 07 (Frequency reference source) code in the DRV group to 2 (V1), and then set code 06 (V1 Polarity) to 1 (bipolar) in the Input Terminal group (IN). Use the output voltage from an external source to provide input to V1.
Page 85 Learning Basic Features Rotational Directions for Different Voltage Inputs Input voltage Command / Voltage Input 0–10 V -10–0 V Forward Reverse Reverse Forward -10–10 V Voltage Input Setting Details Code Description Sets the gradient level and off-set value of the output frequency in relation to the input voltage.
Page 86 Learning Basic Features 4.1.3.3 Setting a Reference Frequency using Input Current (I2) You can set and modify a frequency reference using input current at the I2 terminal after selecting current input at SW 2. Set the 07 (Frequency reference source) code in the DRV group to 5 (I2) and apply 4–20 mA input current to I2.
Page 87: Setting A Frequency Reference With Input Voltage (Terminal I2)
Learning Basic Features Code Description [Gradient and off-set configuration based on output frequency] 4.1.4 Setting a Frequency Reference with Input Voltage (Terminal I2) Set and modify a frequency reference using input voltage at I2 (V2) terminal by setting SW2 to V2. Set the Frq (Frequency reference source) code in the DRV group to 4 (V2) and apply 0–12V input voltage to I2 (=V2, Analog current/voltage input terminal).
Page 88: Setting A Frequency With Ti Pulse Input
Learning Basic Features 4.1.5 Setting a Frequency with TI Pulse Input Set a frequency reference by setting the 07 (Frequency reference source) code in the DRV group to 12 (Pulse) and providing 0–32.00 kHz pulse frequency to TI. Group Code Name LCD Display Parameter Setting Setting Range Unit...
Page 89: Setting A Frequency Reference Via Rs-485 Communication
Learning Basic Features Code Description IN-97 TI Inverting– Identical to IN-16–17 (refer to IN-16 V1 Inverting/IN-17. V1 Quantizing on page 69). IN-98 TI Quantizing 4.1.6 Setting a Frequency Reference via RS-485 Communication Control the inverter with upper-level controllers, such as PCs or PLCs, via RS-485 communication. Set the 07 (Frequency reference source) code in the DRV group to 6 (Int 485) and use the RS-485 signal input terminals (S+/S-/SG) for communication.
Page 90: Frequency Hold By Analog Input
Learning Basic Features 4.2 Frequency Hold by Analog Input If you set a frequency reference via analog input at the control terminal block, you can hold the operation frequency of the inverter by assigning a multi-function input as the analog frequency hold terminal.
Page 91: Setting Multi-Step Frequency
Learning Basic Features 4.4 Setting Multi-step Frequency Multi-step operations can be carried out by assigning different speeds (or frequencies) to the Px terminals. Step 0 uses the frequency reference source set with the 07 code in the DRV group. Px terminal parameter values 7 (Speed-L), 8 (Speed-M) and 9 (Speed-H) are recognized as binary commands and work in combination with Fx or Rx run commands.
Page 92 Learning Basic Features Code Description [An example of a multi-step operation] Speed Fx/Rx                     Set a time interval for the inverter to check for additional terminal block inputs after receiving an input signal.
Page 93: Command Source Configuration
Learning Basic Features 4.5 Command Source Configuration Various devices can be selected as command input devices for theS100 inverter. Input devices available to select include keypad, multi-function input terminal, RS-485 communication and field bus adapter. If UserSeqLink is selected, the common area can be linked with user sequence output and can be used as command.
Page 94: Terminal Block As A Command Input Device (Run And Rotation Direction Commands)
Learning Basic Features Fwd/Rev Command by Multi-function Terminal – Setting Details Code Description DRV-06 Set to 1(Fx/Rx-1). Cmd Source Assign a terminal for forward (Fx) operation. IN-65–71 Px Define Assign a terminal for reverse (Rx) operation. 4.5.3 Terminal Block as a Command Input Device (Run and Rotation Direction Commands) Multi-function terminals can be selected as a command input device.
Page 95: Communication As A Command Input Device
Learning Basic Features Run Command and Fwd/ Rev Change Command Using Multi-function Terminal – Setting Details Code Description DRV-06 Set to 2 (Fx/Rx-2). Cmd Source Assign a terminal for run command (Fx). IN-65–71 Px Define Assign a terminal for changing rotation direction (Rx). 4.5.4 RS-485 Communication as a Command Input Device Internal RS-485 communication can be selected as a command input device by setting the 06...
Page 96: Local/Remote Mode Switching
Learning Basic Features 4.6 Local/Remote Mode Switching Local/remote switching is useful for checking the operation of an inverter or to perform an inspection while retaining all parameter values. Also, in an emergency, it can also be used to override control and operate the system manually using the keypad. The [ESC] key is a programmable key that can be configured to carry out multiple functions.
Page 97 Learning Basic Features Note Local/Remote Operation • Full control of the inverter is available with the keypad during local operation (local operation). • During local operation, jog commands will only work if one of the P1–P7 multi-function terminals (codes IN-65–71) is set to 13 (RUN Enable) and the relevant terminal is turned on. •...
Page 98: Forward Or Reverse Run Prevention
Learning Basic Features 4.7 Forward or Reverse Run Prevention The rotation direction of motors can be configured to prevent motors to only run in one direction. Pressing the [REV] key on the LCD keypad when direction prevention is configured, will cause the motor to decelerate to 0 Hz and stop.
Page 99: Power-On Run
Learning Basic Features 4.8 Power-on Run A power-on command can be setup to start an inverter operation after powering up, based on terminal block operation commands (if they have been configured). To enable power-on run set the drv (command source) code to 1(Fx/Rx-1) or 2 (Fx/Rx-2) in the DRV group. Group Code Name LCD Display Parameter Setting...
Page 100: Reset And Restart
Learning Basic Features 4.9 Reset and Restart Reset and restart operations can be setup for inverter operation following a fault trip, based on the terminal block operation command (if it is configured). When a fault trip occurs, the inverter cuts off the output and the motor will free-run.
Page 101: Setting Acceleration And Deceleration Times
Learning Basic Features 4.10 Setting Acceleration and Deceleration Times 4.10.1 Acc/Dec Time Based on Maximum Frequency Acc/Dec time values can be set based on maximum frequency, not on inverter operation frequency. To set Acc/Dec time values based on maximum frequency, set BAS- 08 (Acc/Dec reference) in the Basic group to 0 (Max Freq).
Page 102: Acc/Dec Time Based On Operation Frequency
Learning Basic Features Code Description Use the time scale for all time-related values. It is particularly useful when a more accurate Acc/Dec times are required because of load characteristics, or when the maximum time range needs to be extended. BAS-09 Time scale Configuration Description 0.01sec...
Page 103: Multi-Step Acc/Dec Time Configuration
Learning Basic Features Acc/Dec Time Based on Operation Frequency – Setting Details Code Description Set the parameter value to 1 (Delta Freq) to set Acc/Dec times based on Maximum frequency. Configuration Description Max Freq Set the Acc/Dec time based on Maximum frequency.
Page 104 Learning Basic Features Acc/Dec Time Setup via Multi-function Terminals – Setting Details Code Description BAS- 70–82 Acc Time Set multi-step acceleration time1–7. 1–7 BAS-71–83 Dec Time 1– Set multi-step deceleration time1–7. Choose and configure the terminals to use for multi-step Acc/Dec time inputs.
Page 105: Configuring Acc/Dec Time Switch Frequency
Learning Basic Features 4.10.4 Configuring Acc/Dec Time Switch Frequency You can switch between two different sets of Acc/Dec times (Acc/Dec gradients) by configuring the switch frequency without configuring the multi-function terminals. Group Code Name LCD Display Parameter Setting Setting Range Unit Acceleration time Acc Time 10.0...
Page 106: Acc/Dec Pattern Configuration
Learning Basic Features 4.11 Acc/Dec Pattern Configuration Acc/Dec gradient level patterns can be configured to enhance and smooth the inverter’s acceleration and deceleration curves. Linear pattern features a linear increase or decrease to the output frequency, at a fixed rate. For an S-curve pattern a smoother and more gradual increase or decrease of output frequency, ideal for lift-type loads or elevator doors, etc.
Page 107 Learning Basic Features [Acceleration / deceleration pattern configuration] [Acceleration / deceleration S-curve parrten configuration]...
Page 108: Stopping The Acc/Dec Operation
Learning Basic Features Note The Actual Acc/Dec time during an S-curve application Actual acceleration time = user-configured acceleration time + user-configured acceleration time x starting gradient level/2 + user-configured acceleration time x ending gradient level/2. Actual deceleration time = user-configured deceleration time + user-configured deceleration time x starting gradient level/2 + user-configured deceleration time x ending gradient level/2.
Page 109: V/F(Voltage/Frequency) Control
Learning Basic Features 4.13 V/F(Voltage/Frequency) Control Configure the inverter’s output voltages, gradient levels and output patterns to achieve a target output frequency with V/F control. The amount of of torque boost used during low frequency operations can also be adjusted. 4.13.1 Linear V/F Pattern Operation A linear V/F pattern configures the inverter to increase or decrease the output voltage at a fixed rate for different operation frequencies based on V/F characteristics.
Page 110: Square Reduction V/F Pattern Operation
Learning Basic Features 4.13.2 Square Reduction V/F pattern Operation Square reduction V/F pattern is ideal for loads such as fans and pumps. It provides non-linear acceleration and deceleration patterns to sustain torque throughout the whole frequency range. Group Code Name LCD Display Parameter Setting Setting Range Unit...
Page 111: User V/F Pattern Operation
Learning Basic Features 4.13.3 User V/F Pattern Operation The S100 inverter allows the configuration of user-defined V/F patterns to suit the load characteristics of special motors. Group Code Name LCD Display Parameter Setting Setting Range Unit V/F pattern V/F Pattern User V/F 0–3...
Page 112 Learning Basic Features User V/F pattern Setting Details Code Description Set the parameter values to assign arbitrary frequencies (User Freq 1–4) for start BAS-41 User Freq 1– and maximum frequencies. Voltages can also be set to correspond with each BAS-48 User Volt 4 frequency, and for each user voltage (User Volt 1–4).
Page 113: Torque Boost
Learning Basic Features 4.14 Torque Boost 4.14.1 Manual Torque Boost Manual torque boost enables users to adjust output voltage during low speed operation or motor start. Increase low speed torque or improve motor starting properties by manually increasing output voltage. Configure manual torque boost while running loads that require high starting torque, such as lift-type loads.
Page 114: Auto Torque Boost-1
Learning Basic Features 4.14.2 Auto Torque Boost-1 Auto torque boost enables the inverter to automatically calculate the amount of output voltage required for torque boost based on the entered motor parameters. Because auto torque boost requires motor-related parameters such as stator resistance, inductance, and no-load current, auto tuning (BAS-20) has to be performed before auto torque boost can be configured.
Page 115: Start Mode Setting
Learning Basic Features 4.16 Start Mode Setting Select the start mode to use when the operation command is input with the motor in the stopped condition. 4.16.1 Acceleration Start Acceleration start is a general acceleration mode. If there are no extra settings applied, the motor accelerates directly to the frequency reference when the command is input.
Page 116: Stop Mode Setting
Learning Basic Features The amount of DC braking required is based on the motor’s rated current. Do not use DC braking resistance values that can cause current draw to exceed the rated current of the inverter. If the DC braking resistance is too high or brake time is too long, the motor may overheat or be damaged. 4.17 Stop Mode Setting Select a stop mode to stop the inverter operation.
Page 117: Stop After Dc Braking
Learning Basic Features 4.17.2 Stop After DC Braking When the operation frequency reaches the set value during deceleration (DC braking frequency), the inverter stops the motor by supplying DC power to the motor. With a stop command input, the inverter begins decelerating the motor. When the frequency reaches the DC braking frequency set at ADV-17, the inverter supplies DC voltage to the motor and stops it.
Page 118: Free Run Stop
Learning Basic Features • Note that the motor can overheat or be damaged if excessive amount of DC braking is applied to the motor, or DC braking time is set too long. • DC braking is configured based on the motor’s rated current. To prevent overheating or damaging motors, do not set the current value higher than the inverter’s rated current.
Page 119: Power Braking
Learning Basic Features 4.17.4 Power Braking When the inverter’s DC voltage rises above a specified level due to motor regenerated energy, a control is made to either adjust the deceleration gradient level or reaccelerate the motor in order to reduce the regenerated energy. Power braking can be used when short deceleration times are needed without brake resistors, or when optimum deceleration is needed without causing an over voltage fault trip.
Page 120: Frequency Limit
Learning Basic Features 4.18 Frequency Limit Operation frequency can be limited by setting maximum frequency, start frequency, upper limit frequency and lower limit frequency. 4.18.1 Frequency Limit Using Maximum Frequency and Start Frequency Group Code Name LCD Display Parameter Setting Setting Range Unit Start frequency Start Freq...
Page 121 Learning Basic Features Frequency Limit Using Upper and Lower Limit Frequencies - Setting Details Code Description The initial setting is 0 (No). Changing the setting to 1 (Yes) allows the setting of frequencies between the lower limit frequency (ADV-25) and the upper limit ADV-24 Freq Limit frequency (ADV-26).
Page 122: Frequency Jump
Learning Basic Features 4.18.3 Frequency Jump Use frequency jump to avoid mechanical resonance frequencies. Jump through frequency bands when a motor accelerates and decelerates. Operation frequencies cannot be set within the pre-set frequency jump band. When a frequency setting is increased, while the frequency parameter setting value (voltage, current, RS-485 communication, keypad setting, etc.) is within a jump frequency band , the frequency will be maintained at the lower limit value of the frequency band.
Page 123: Nd Operation Mode Setting
Learning Basic Features 4.19 2 Operation Mode Setting Apply two types of operation modes and switch between them as required. For both the first and second command source, set the frequency after shifting operation commands to the multi- function input terminal. Mode swiching can be used to stop remote control during an operation using the communication option and to switch operation mode to operate via the local panel, or to operate the inverter from another remote control location.
Page 124: Multi-Function Input Terminal Control
Learning Basic Features 4.20 Multi-function Input Terminal Control Filter time constants and the type of multi-function input terminals can be configured to improve the response of input terminals Group Code Name LCD Display Parameter Setting Setting Range Unit Multi-function input 0–10000 DI On Delay terminal On filter...
Page 125: P2P Setting
Learning Basic Features Code Description Display the configuration of each contact. When a segment is configured as A terminal using DRV-87, the On condition is indicated by the top segment turning on. The Off condition is indicated when the bottom segment is turned on. When contacts are configured as B terminals, the segment lights behave conversely.
Page 126: Multi-Keypad Setting
Learning Basic Features P2P Setting Details Code Description COM-95 Int 485 Func Set master inverter to 1(P2P Master), slave inverter to 2(P2P Slave). USS-80–82 P2P Input Data Input data sent from the slave inverter. USS-85, 88 P2P Output Data Output data transmitted to the slave inverter. •...
Page 127: User Sequence Setting
Learning Basic Features Multi-keypad Setting Details Code Description Prevents conflict by designating a unique identification value to an inverter. COM-01 Int485 St ID Values can be selected from numbers between 3–99. COM-95 Int 485 Func Set the value to 3 (KPD-Ready) for both master and slave inverter CNF-03 Multi KPD ID Select an inverter to monitor from the group of inverters.
Page 128 Learning Basic Features Group Code Name LCD Display Parameter Setting Setting Range Unit Digital input P2P In D –12,000 Analog output P2P Out AO1 0–0x7F Digital output P2P Out DO 0–0x03 0–28 User function 1 User Func1 User function input 1-A User Input 1-A 0–0xFFFF User function input 1-B...
Page 129 Learning Basic Features Group Code Name LCD Display Parameter Setting Setting Range Unit 0–0xFFFF User function input 7-B User Input 7-B User function input 7-C User Input 7-C 0–0xFFFF User function output 7 User Output 7 -32767–32767 - User function 8 User Func8 0–28 User function input 8-A...
Page 130 Learning Basic Features Group Code Name LCD Display Parameter Setting Setting Range Unit 0–0xFFFF User function input14-B User Input 14-B User function input 14-C User Input 14-C 0–0xFFFF User function output14 User Output 14 -32767–32767 - User function 15 User Func15 0–28 User function input 15-A User Input 15-A...
Page 131 Learning Basic Features Code Description USS-31–60 Void Para1– Set 30 void parameters. Use when constant (Const) parameter input is needed in the user function block. Set user defined functions for the 18 function blocks. If the function block setting is invalid, the output of the User Output@ is -1. USF-01–90 All the outputs from the User Output@ are read only, and can be used with the user output link@ (Link UserOut@) of the USS group.
Page 132 Learning Basic Features User Function Operation Condition Number Type Description No Operation. Addition operation, (A + B) + C If the C parameter is 0x0000, it will be recognized as 0. Subtraction operation, (A - B) – C If the C parameter is 0x0000, it will be recognized as 0. Addition andsubtraction compound operation, (A + B) –...
Page 133 Learning Basic Features Number Type Description Sets a limit for the A parameter. If input to A is between B and C, output the input to A. LIMIT If input to A is larger than B, output B. If input of A is smaller than C, output B parameter must be greater than or equal to the C parameter.
Page 134 Learning Basic Features Number Type Description Upcounts the pulses and then output the value- UPCOUNT(A, B, C). After receiving a trigger input (A), outputs are upcounted by C conditions. If the B inputs is 1, do not operate and display 0. If the B inputs is 0, operate. If the C parameter is 0, upcount when the input at A changes from 0 to 1.
Page 135: Fire Mode Operation
Learning Basic Features 4.24 Fire Mode Operation This function is used to allow the inverter to ignore minor faults during emergency situations, such as fire, and provides continuous operation to fire pumps. When turned on, Fire mode forces the inverter to ignore all minor fault trips and repeat a Reset and Restart for major fault trips, regardless of the restart trial count limit.
Page 136 Learning Basic Features Fire Mode Function Setting Details Code Description Details The frequency set at ADV-81 (Fire mode frequency) is used for the ADV-81 Fire Fire mode inverter operation in Fire mode. The Fire mode frequency takes Mode frequency priority over the Jog frequency, Multi-step frequencies, and the frequency reference keypad input frequency.
Page 137: Communication Features
5.1 Communication Standards Following the RS-485 communication standards, S100 products exchange data with a PLC and computer. The RS-485 communication standards support the Multi-drop Link System and offer an interface that is strongly resistant to noise. Please refer to the following table for details about the communication standards.
Page 138: Communication System Configuration
RS-485 Communication Features 5.2 Communication System Configuration In an RS-485 communication system, the PLC or computer is the master device and the inverter is the slave device. When using a computer as the master, the RS-232 converter must be integrated with the computer, so that it can communicate with the inverter through the RS-232/RS-485 converter.
Page 139: Setting Communication Parameters
RS-485 Communication Features 5.2.2 Setting Communication Parameters Before proceeding with setting communication configurations, make sure that the communication lines are connected properly. Turn on the inverter and set the communication parameters. Group Code Name LCD Display Parameter Setting Setting range Unit Built-in communication Int485 St ID...
Page 140: Setting Operation Command And Frequency
RS-485 Communication Features Code Description D8/PN/S2 8-bit data / no parity check / 2 stop bits D8/PE/S1 8-bit data / even parity / 1 stop bit D8/PO/S1 8-bit data / odd parity / 1 stop bit Set the response time for the slave (inverter) to react to the request from the master.
Page 141: Command Loss Protective Operation
RS-485 Communication Features 5.2.4 Command Loss Protective Operation Configure the command loss decision standards and protective operations run when a communication problem lasts for a specified period of time. Command Loss Protective Operation Setting Details Code Description Select the operation to run when a communication error has occurred and lasted exceeding the time set at PRT- 13.
Page 142: Setting Virtual Multi-Function Input
RS-485 Communication Features 5.2.5 Setting Virtual Multi-Function Input Multi-function input can be controlled using a communication address (0h0385). Set codes COM- 70–77 to the functions to operate, and then set the BIT relevant to the function to 1 at 0h0322 to operate it.
Page 143: Saving Parameters Defined By Communication
0h0300-0h037F Inverter monitoring area 0h0380-0h03DF Inverter control area 0h03E0-0h03FF Inverter memory control area 0h0400-0h0FFF Reserved 0h1100 DRV Group 0h1200 BAS Group S100 communication 0h1300 ADV Group common area 0h1400 CON Group 0h1500 IN Group 0h1600 OUT Group 0h1700 COM Group...
Page 144: Parameter Group For Data Transmission
RS-485 Communication Features 5.2.8 Parameter Group for Data Transmission By defining a parameter group for data transmission, the communication addresses registered in the communication function group (COM) can be used in communication. Parameter group for data transmission may be defined to transmit multiple parameters at once, into the communication frame.
Page 145: Communication Protocol
RS-485 Communication Features 5.3 Communication Protocol The built-in RS-485 communication supports LS INV 485 and Modbus-RTU protocols. 5.3.1 LS INV 485 Protocol The slave device (inverter) responds to read and write requests from the master device (PLC or PC). Request Station ID Data 1 byte...
Page 146 RS-485 Communication Features • Transmission/reception buffer size: Transmission=39 bytes, Reception=44 bytes • Monitor registration buffer: 8 Words • SUM: Checks communication errors via sum. SUM=a total of the lower 8 bits values for station ID, command and data (Station ID+CMD+Data) in ASCII-HEX. For example, a command to read 1 address from address 3000: SUM=‘0’+‘1’+’R’+‘3’+‘0’+‘0’+‘0’+’1’...
Page 147 RS-485 Communication Features Read Error Response Station ID Error code ‘01’-‘FA’ ‘R’ ‘**’ ‘XX’ 1 byte 2 bytes 1 byte 2 bytes 2 bytes 1 byte Total bytes=9 5.3.1.2 Detailed Write Protocol Write Request: Writes successive n words to address XXXX. Number of Station ID CMD Address...
Page 148 RS-485 Communication Features 5.3.1.3 Monitor Registration Detailed Protocol Monitor registration request is made to designate the type of data that requires continuous monitoring and periodic updating. Monitor Registration Request: Registration requests for n addresses (where n refers to the number of addresses. The addresses do not have to be contiguous.) Number of Station ID Address...
Page 149 RS-485 Communication Features Monitor Registration Execution Error Response Station ID Error Code ‘01’-‘FA’ ‘Y’ ‘**’ ‘XX’ 1 byte 2 bytes 1 byte 2 bytes 2 bytes 1 byte Total bytes=9 5.3.1.4 Error Code Code Abbreviation Description The requested function cannot be performed by a slave ILLEGAL FUNCTION because the corresponding function does not exist.
Page 150: Modbus-Rtu Protocol
RS-485 Communication Features Character Character Character space " & < > 5.3.2 Modbus-RTU Protocol 5.3.2.1 Function Code and Protocol (unit: byte) In the following section, station ID is the value set at COM-01 (Int485 St ID), and starting address is the communication address.
Page 151 RS-485 Communication Features Function Code #03: Read Holding Register Query Field Name Response Field Name Station ID Station ID Function(0x03) Function (0x03) Starting Address Hi Byte Count Starting Address Lo Data Hi # of Points Hi Data Lo # of Points Lo …...
Page 152 RS-485 Communication Features Function Code #06: Preset Single Register Query Field Name Response Field Name Station ID Station ID Function (0x06) Function (0x06) Starting Address Hi Register Address Hi Register Address Lo Register Address Lo Preset Data Hi Preset Data Hi Preset Data Lo Preset Data Lo CRC Lo...
Page 153 RS-485 Communication Features Exception Code Code 01: ILLEGAL FUNCTION 02: ILLEGAL DATA ADRESS 03: ILLEGAL DATA VALUE 06: SLAVE DEVICE BUSY Response Field Name Station ID Function* Exception Code CRC Lo CRC Hi * The function value uses the top level bit for all query values. Example of Modbus-RTU Communication in Use When the Acc time (Communication address 0x1103) is changed to 5.0 sec and the Dec time (Communication address 0x1104) is changed to 10.0 sec.
Page 154: Compatible Common Area Parameter
Comm. Address Parameter Scale Unit Assigned Content by Bit 0h0000 Inverter model 6: S100 0: 0.75 kW, 1: 1.5 kW, 2: 2.2 kW 3: 3.7 kW, 4: 5.5 kW, 5: 7.5 kW 6: 11 kW, 7: 15 kW, 8: 18.5 kW...
Page 155 RS-485 Communication Features Comm. Address Parameter Scale Unit Assigned Content by Bit 0h0008 Deceleration time 0h0009 Output current 0h000A Output frequency 0.01 0h000B Output voltage 0h000C DC link voltage 0h000D Output power 0: Remote, 1: Keypad Local 1: Frequency command source by communication (built-in, option) 1: Operation command...
Page 156 RS-485 Communication Features Comm. Address Parameter Scale Unit Assigned Content by Bit Latch Type trip B15- Reserved Input terminal 0h0010 information Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Output terminal 0h0011 information Reserved Reserved Reserved Reserved Reserved Reserved Relay 1 0h0012 0.01 V1 input voltage...
Page 157: S100 Expansion Common Area Parameter
RS-485 Communication Features 5.5 S100 Expansion Common Area Parameter 5.5.1 Monitoring Area Parameter (Read Only) Comm. Address Parameter Scale Unit Assigned content by bit 0h0300 Inverter model S100: 0006h 0.4 kW: 1900h, 0.75 kW: 3200h 1.1 kW: 4011h, 1.5 kW: 4015h 2.2 kW: 4022h, 3.0 kW: 4030h...
Page 158 RS-485 Communication Features Comm. Address Parameter Scale Unit Assigned content by bit 2: Accelerating 3: Operating at constant rate 4: Decelerating 5: Decelerating to stop 6: H/W OCS 7: S/W OCS 8: Dwell operating 0: Stopped 1: Operating in forward direction 2: Operating in reverse direction 3: DC operating (0 speed control) Operation command source...
Page 159 RS-485 Communication Features Comm. Address Parameter Scale Unit Assigned content by bit 0h0315 DC Link voltage 0h0316 Output power 0h0317 Output torque 0h0318 PID reference 0h0319 PID feedback Display the Displays the number of poles for the first 0h031A number of poles motor for the 1 motor...
Page 160 RS-485 Communication Features Comm. Address Parameter Scale Unit Assigned content by bit Virtual DI 3(COM-72) Virtual DI 2(COM-71) Virtual DI 1(COM-70) Display the 0h0323 0: 1st motor/1: 2nd motor selected motor 0h0324 0.01 Analog input V1 (I/O board) 0h0325 Reserved 0.01 0h0326 0.01...
Page 161 RS-485 Communication Features Comm. Address Parameter Scale Unit Assigned content by bit External brake trip Bad contact at basic I/O board Pre PID Fail Error while writing parameter Reserved FAN Trip Reserved Reserved Reserved Reserved Reserved Reserved Reserved Level type trip 0h0332 Reserved information...
Page 162 RS-485 Communication Features Comm. Address Parameter Scale Unit Assigned content by bit Underload Overload 0h0335 -0h033F Reserved Total number of days the inverter has been 0h0340 On Time date powered on Total number of minutes excluding the total 0h0341 On Time minute number of On Time days Total number of days the inverter has driven 0h0342...
Page 163: Control Area Parameter (Read/ Write)
RS-485 Communication Features 5.5.2 Control Area Parameter (Read/ Write) Comm. Address Parameter Scale Unit Assigned Content by Bit Frequency 0h0380 0.01 Command frequency setting command 0h0381 RPM command 1 Command rpm setting Reserved Reserved Reserved Reserved 0  1: Free-run stop Operation 0 ...
Page 164 RS-485 Communication Features Comm. Address Parameter Scale Unit Assigned Content by Bit Relay 4 (Ext I/O, OUT-31: None) Relay 3 (Ext I/O, OUT-31: None) Relay 2 (30~75kW, OUT-31: None) Q1 (0.4~75kW, OUT-33: None) Relay 1(0.4~75kW, OUT-31: None) 0h0387 Reserved Reserved 0h0388 PID reference PID reference command...
Page 165: Inverter Memory Control Area Parameter (Read And Write)
RS-485 Communication Features 5.5.3 Inverter Memory Control Area Parameter (Read and Write) Comm. Changeable Parameter Scale Unit Function Address During Operation 0h03E0 Save parameters - 0: No, 1:Yes Monitor mode 0h03E1 0: No, 1:Yes initialization 0: No, 1: All Grp, 2: DRV Grp 3: BAS Grp, 4: ADV Grp, 5: CON 6: IN Grp, 7: OUT Grp, 8: COM Parameter...
Page 166 RS-485 Communication Features Note • When setting parameters in the inverter memory control area, the values are reflected to the inverter operation and saved. Parameters set in other areas via communication are reflected to the inverter operation, but are not saved. All set values are cleared following an inverter power cycle and revert back to its previous values.
Page 167: Table Of Functions
Table of Functions 6 Table of Functions This chapter lists all the function settings for S100 series inverter. Set the parameters required according to the following references. If a set value input is out of range, the following messages will be displayed on the keyboard. In these cases, the inverter will not operate with the [ENT] key.
Page 168 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address value Int 485 Field Bus UserSeqLi 12 Pulse Keypad-1 Keypad-2 Torque 0h1108 Reference Trq Ref Scr Keypad-1 Int485 Setting Fieldbus UserSeqLi 12 Pulse Slip Compen 0h1109 Control mode Control Mode 0: V/F...
Page 169 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address value 10: 7.5 kW, 11: 11.0 kW 12: 15.0 kW, 13: 18.5 kW 14: 22.0 kW 15: 30.0 kW 16:37 kW 17:45.0 kW 18:55.0 kW 19:75 kW 20:90 kW Manual...
Page 170 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address value Hz Display Select speed 0:Hz 0h1115 Hz/Rpm Sel I/P p.78 unit Display Display (+) Torque 0h1116 (+) Trq Gain 50.0–150.0[%] 100[%] Gain 0h1117 (-)Torque Gain (-) Trq Gain 50.0–150.0[%] 80.0[%] (-)Torque...
Page 171 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address value Currently out of order Select run direction output current2 Motor RPM2 Inverter DC voltage2 User select signal2 (DRV-81) Monitors user selected code Output voltage(V) Select monitor 0h1151...
Page 172: Basic Function Group (Par→Bas)
Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address value APP Grp 12 PRT Grp 13 M2 Grp Password 0h115E I/P - registration Parameter lock 0h115F I/P - settings Software 0h1161 I/P - version Display I/O 0h1162...
Page 173 Table of Functions Comm. Initial Property Code Name LCD Display Setting Range V/F SL Ref. Address Value Mx[G*2(A- 50%) M/[G*2(A- 50%)] M+M*G*2(A- 50%) Auxiliary Aux Ref Gain -200.0-200.0(%) 0h1203 100.0 I/P - command gain Keypad Fx/Rx-1 2nd command 0h1204 Cmd 2nd Src Fx/Rx-2 I/P p.111 source...
Page 174 Table of Functions Comm. Initial Property Code Name LCD Display Setting Range V/F SL Ref. Address Value Rated slip motor 0h120C Rated Slip 0-3000(Rpm) speed setting Motor rated 0h120D Rated Curr 1.0-1000.0(A) I/P - current Motor noload Noload Curr 0.0-1000.0(A) 0h120E current Motor rated...
Page 175 Table of Functions Comm. Initial Property Code Name LCD Display Setting Range V/F SL Ref. Address Value D-axis Ld (PM) Settings vary inductance depending on Q-axis Lq (PM) the motor inductance specifications. Flux reference PM Flux Ref 0.147 Regeneration Ls Regen inductance 70 ~ 100[%] Scale...
Page 176 Table of Functions Comm. Initial Property Code Name LCD Display Setting Range V/F SL Ref. Address Value Multi-step 0.00-Maximum 0h1234 speed Step Freq-3 30.00 I/P p.79 frequency(Hz) frequency3 Multi-step 0.00-Maximum 0h1235 speed Step Freq-4 40.00 I/P p.79 frequency(Hz) frequency4 Multi-step 0.00-Maximum 0h1236 speed...
Page 177: Advanced Function Group (Par→Adv)
Table of Functions Comm. Initial Property Code Name LCD Display Setting Range V/F SL Ref. Address Value Multi-step 0h124E acceleration Acc Time-5 0.0-600.0(s) 40.0 I/P p.91 time5 Multi-step 0h124F deceleration Dec Time-5 0.0-600.0(s) 40.0 I/P p.91 time5 Multi-step 0h1250 acceleration Acc Time-6 0.0-600.0(s) 30.0...
Page 178 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value S-curve 0h1304 acceleration end Acc S End 1-100(%) I/P p.94 point gradient S-curve deceleration 0h1305 Dec S Start 1-100(%) I/P p.94 start point gradient S-curve deceleration...
Page 179 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value DC braking DC-Brake Start frequency- 0h1311 5.00 I/P p.104 frequency Freq 60 Hz Start frequency- Dwell frequency Acc Dwell 0h1314 Maximum 5.00 I/P - on acceleration Freq frequency(Hz)
Page 180 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value Jump frequency Jump frequency lower limit3- Jump Hi 3 0h1321 35.00 I/P p.110 Maximum upper limit3 frequency(Hz) Brake release 0h1329 BR Rls Curr 0.0-180.0(%) 50.0 I/P -...
Page 181 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value None Output contact On/Off Ctrl 0:Non 0h1342 On/Off control I/P - options Pulse Output contact Output contact 0h1343 On-Ctrl Level 90.00 I/P - On level off level- 100.00% -100.00-output...
Page 182 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value Regeneration RegenAvd 0h134E evasion for 20-30000(ms) Igain press I gain 200V: 390[V] ~400[V] DB Unit turn on DB Turn On 0h134F I/P - voltage level 400V: 780[V]...
Page 183: Control Function Group (Par→Con)
Table of Functions 6.4 Control Function group (PAR→CON) In the following table, the data shaded in grey will be displayed when a related code has been selected. SL: Sensorless vector control (DRV-09) , I – IM Sensorless, P – PM Sensorless *O/X: Write-enabled during operation Comm.
Page 184 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value Continued 0h140B operation Hold Time 0.00-60.00(s) 0.00 duration PM S/L speed ASR P Gain 0h140D controller 0~5000 proportion al gain1 PM S/L speed ASR P Gain 0h140F controller...
Page 185 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value controller proportion al gain2 Sensorless speed ASR-SL I 0h1418 controller 1.0-1000.0(%) Gain2 integral gain2 Sensorless speed ASR-SL I 0h1419 controller 10-9999(ms) Gain0 integral gain0 Flux estimator...
Page 186 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value PM D-axis back-EMF PM EdGain 0~300.0[%] 100.0 0h1421 estimation Perc gain [%] PM Q-axis back-EMF PM EqGain 0h1422 0~300.0[%] 100.0 estimation Perc gain [%] Initial pole position PD Repeat...
Page 187 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value Speed PM SpdEst 0~32000 estimator I 0h142C Ki 2 gain2 Speed estimator feed PM Flux 0~100[%] 30.0 0h142D forward FF % high speed rate [%] Initial pole None...
Page 188 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value Positive- direction regenerati 0h1437 0.0-200.0(%) I/P - –Trq Lmt torque limit Negative- direction regenerati REV +Trq 0.0-200.0(%) 0h1438 I/P - torque limit Negative- direction REV –Trq reverse...
Page 189 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value Flying Start-2 Flying Start- 0000- 1111 Selection of speed search 0001 acceleration When starting Speed 0010 initialization search Speed after fault trip 0000 0h1447 I/P - operation...
Page 190 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value Output blocking SS Block 0h144B time before 0.0-60.0(s) I/P - Time speed search Speed search Spd Est 0h144C 50-150(%) Estimator Gain gain Energy buffering KEB Select KEB-1...
Page 191 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value Flux estimator Flux P 0h1456 0-100 proportion Gain2 al gain2 Flux estimator Flux P 0h1457 0-500 proportion Gain3 al gain3 Flux estimator 0h1458 Flux I Gain1 0-200 integral gain1...
Page 192: Input Terminal Block Function Group (Par→In)
Table of Functions 6.5 Input Terminal Block Function group (PAR→IN) In the following table, the data shaded in grey will be displayed when a related code has been selected. SL: Sensorless vector control (DRV-09) , I – IM Sensorless, P – PM Sensorless *O/X: Write-enabled during operation Comm.
Page 193 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value V1 Maximum 0h150E V1 –Volt x2’ -12.00- 0.00(V) -10.00 I/P p.72 input voltage V1 output at 0h150F Maximum V1 –Perc y2’ -100.00-0.00(%) -100.00 O I/P p.72 voltage (%) V1 rotation...
Page 194 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value I2 minimum 0h1535 I2 Curr x1 0.00-20.00(mA) 4.00 I/P p.74 input current I2 output at 0h1536 Minimum I2 Perc y1 0.00-100.00(%) 0.00 I/P p.74 current (%) I2 maximum 0h1537...
Page 195 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value 14 3-Wire 15 2nd Source p.111 16 Exchange 17 Up 18 Down 20 U/D Clear 21 Analog Hold p.78 22 I-Term Clear 23 PID Openloop 24 P Gain2 25 XCEL Stop p.96...
Page 196 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value Pulse input Pulse Monitor 0h155B amount 0.00-50.00(kHz) 0.00 I/P p.76 (kHz) display TI input filter 0h155C TI Filter 0-9999(ms) I/P p.76 time constant TI Minimum 0h155D TI Pls x1...
Page 197: Output Terminal Block Function Group (Par→Out)
Table of Functions 6.6 Output Terminal Block Function group (PAR→OUT) In the following table, the data shaded in grey will be displayed when a related code has been selected. SL: Sensorless vector control (DRV-09), I – IM Sensorless, P – PM Sensorless *O/X: Write-enabled during operation Comm.
Page 198 Table of Functions Comm. Initial Code Name Setting Range Property* V/F SL Ref. Address Display Value Iqse Target Freq Ramp Freq Speed Fdb PID Ref Value PID Fdb Value PID Output Constant Analog output 0h1608 AO2 Gain -1000.0~1000.0(%) 100.0 I/P - 2 gain Analog output 0h1609...
Page 199 Table of Functions Comm. Initial Code Name Setting Range Property* V/F SL Ref. Address Display Value Steady Inverter Line Comm Line Speed Search Ready Timer Out Trip DB Warn%ED On/Off Control BR Control CAP. Exchange Fan Exchange Fire Mode KEB Operating None FDT-1 FDT-2...
Page 200 Table of Functions Comm. Initial Code Name Setting Range Property* V/F SL Ref. Address Display Value Fan Exchange Fire Mode KEB Operating None FDT-1 FDT-2 FDT-3 FDT-4 Over Load Under Load Fan Warning Stall Over Voltage Low Voltage Over Heat Lost Command Multi-function Stop...
Page 201 Table of Functions Comm. Initial Code Name Setting Range Property* V/F SL Ref. Address Display Value Multi-function Q1, Relay1 output A contact (NO) 0h1634 I/P - contact NC/NO Sel B contact (NC) selection Fault output TripOut 0h1635 0.00-100.00(s) 0.00 I/P - On delay OnDly Fault output...
Page 202: Communication Function Group (Par→Com)
Table of Functions 6.7 Communication Function group (PAR→COM) In the following table, the data shaded in grey will be displayed when a related code has been selected. SL: Sensorless vector control (DRV-09) , I – IM Sensorless, P – PM Sensorless *O/X: Write-enabled during operation Comm.
Page 203 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value Communication FieldBus 0h1709 option LED I/P - status Number of ParaStatus 0h171E output I/P p.132 parameters Output Para Stauts- 0h171F Communication 0000-FFFF Hex 000A I/P p.132 address1...
Page 204 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value Input Para 0h1736 Communication 0000-FFFF Hex 0000 I/P p.132 Control-4 address4 Input Para 0h1737 Communication 0000-FFFF Hex 0000 I/P p.132 Control-5 address5 Input Para 0h1738 Communication...
Page 205 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value 13 RUN Enable 14 3-Wire 15 2nd Source 16 Exchange 17 Up 18 Down 20 U/D Clear 21 Analog Hold 22 I-Term Clear Openloop 24 P Gain2 25 XCEL Stop...
Page 206: Application Function Group (Par→App)
Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value Disable All P2P Master Int 485 0h1760 communication Disable I/P p.113 P2P Slave Func selection M-KPD Ready Multi- function DO setting P2P DO Sel setting 0:No I/P p.113...
Page 207 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value Keypad PID reference 0h1814 I/P - Int 485 source Ref Source Keypad FieldBus UserSeqLi 11 Pulse PID feedback Int 485 0h1815 0:V1 I/P - source F/B Source FieldBus...
Page 208 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value 0h1820 PID output scale PID Out Scale 0.1-1000.0(%) 100.0 I/P - PID controller 0.00- 0h1822 motion Pre-PID Freq Maximum 0.00 I/P - frequency frequency(Hz) PID controller Pre-PID Exit...
Page 209: Protection Function Group (Par→Prt)
Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value PID 2nd 0h182D proportional PID P2-Gain 0.0-1000.0(%) 100.0 I/P - gain 6.9 Protection Function group (PAR→PRT) In the following table, the data shaded in grey will be displayed when a related code has been selected.
Page 210 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value Automatic 0h1B0A restart Retry Delay 0.0-60.0(s) I/P - delay time None Free-Run Motion Lost Cmd 0h1B0C at speed 0:None I/P - Mode Hold Input command loss Hold Output Lost Preset...
Page 211 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value Underload UL Warn 0h1B1A 0.0-600.0(s) 10.0 I/P - warning time Time None Underload fault 0h1B1B UL Trip Sel Free-Run 0:None I/P - selection Underload fault 0h1B1C UL Trip Time 0.0-600.0(s)
Page 212 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value At constant speed deceleration FluxBraking Start frequency- 0h1B33 Stall frequency1 Stall Freq 1 Stall 60.00 frequency2(Hz) 0h1B34 Stall level1 Stall Level 1 30-250(%) Stall frequency1- 0h1B35 Stall frequency2 Stall Freq 2 Stall...
Page 213 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value DB resistor 0h1B42 0-30(%) I/P - warning level Warn %ED Speed deviation Speed Dev 0h1B22 0:No trip Trip Speed deviation Speed Dev 0h1B23 1~20 band Band...
Page 214: 2Nd Motor Function Group (Par→M2)
Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value 0h1B5F Fault history 5 Fault history 0h1B60 0:No deletion 6.10 2nd Motor Function group (PAR→M2) The 2nd Motor function group will be displayed if any of IN-65-71 is set to 26 (2nd MOTOR). In the following table, the data shaded in grey will be displayed when a related code has been selected.
Page 215 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value M2-Base 30.00- 0h1C07 Base frequency 60.00 Freq 400.00(Hz) 0 V/F Slip M2-Ctrl 0h1C08 Control mode Compen 0:V/F Mode Sensorless Number of M2-Pole 0h1C0A 2-48 motor poles M2-Rated...
Page 216: User Sequence Group (Uss)
Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value Electronic thermal M2-ETH 0h1C1E 50-150(%) continuous Cont rating Rotation count Load Spd 0h1C28 0~6000.0[%] 100.0 speed gain Gain x 0.1 Rotation count Load Spd 0h1C29 x 0.01 0: x 1...
Page 217 Table of Functions Comm. Setting Initial Code Name LCD Display Property* V/F SL Ref. Address Range Value Output address 0h1D0E Link UserOut4 0-0xFFFF I/P p.115 link4 Output address 0h1D0F Link UserOut5 0-0xFFFF I/P p.115 link5 Output address 0h1D10 Link UserOut6 0-0xFFFF I/P p.115 link6 Output address...
Page 218 Table of Functions Comm. Setting Initial Code Name LCD Display Property* V/F SL Ref. Address Range Value Input constant 0h1D26 Void Para8 -9999-9999 I/P p.115 setting8 Input constant 0h1D27 Void Para9 -9999-9999 I/P p.115 setting9 Input constant 0h1D28 Void Para10 -9999-9999 I/P p.115 setting10...
Page 219: User Sequence Function Group(Usf)
Table of Functions Comm. Setting Initial Code Name LCD Display Property* V/F SL Ref. Address Range Value Input constant 0h1D3C Void Para30 -9999-9999 I/P p.115 setting30 0h1D50S Analog input 1 P2P In V1 0-12,000 I/P p.115 -12,000- 0h1D51 Analog input2 P2P In I2 I/P p.115 12,000...
Page 220 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value 16 AND 17 OR 18 XOR 19 ANDOR 20 SWITCH 21 BITTEST 22 BITSET 23 BITCLEAR 24 LOWPASSFILTER 25 PI_CONTORL 26 PI_PROCESS 27 UPCOUNT 28 DOWNCOUNT User function User Input1-...
Page 221 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value 14 TIMER 15 LIMIT 16 AND 17 OR 18 XOR 19 ANDOR 20 SWITCH 21 BITTEST 22 BITSET 23 BITCLEAR 24 LOWPASSFILTER 25 PI_CONTORL 26 PI_PROCESS 27 UPCOUNT 28 DOWNCOUNT...
Page 222 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value COMPARE- NEQUAL 14 TIMER 15 LIMIT 16 AND 17 OR 18 XOR 19 ANDOR 20 SWITCH 21 BITTEST 22 BITSET 23 BITCLEAR 24 LOWPASSFILTER 25 PI_CONTORL 26 PI_PROCESS 27 UPCOUNT...
Page 223 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value COMPARE- EQUAL COMPARE- NEQUAL 14 TIMER 15 LIMIT 16 AND 17 OR 18 XOR 19 ANDOR 20 SWITCH 21 BITTEST 22 BITSET 23 BITCLEAR 24 LOWPASSFILTER 25 PI_CONTORL 26 PI_PROCESS...
Page 224 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value COMPARE- EQUAL COMPARE- NEQUAL 14 TIMER 15 LIMIT 16 AND 17 OR 18 XOR 19 ANDOR 20 SWITCH 21 BITTEST 22 BITSET 23 BITCLEAR 24 LOWPASSFILTER 25 PI_CONTORL 26 PI_PROCESS...
Page 225 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value 10 COMPARE-GT 11 COMPARE-GEQ COMPARE- EQUAL COMPARE- NEQUAL 14 TIMER 15 LIMIT 16 AND 17 OR 18 XOR 19 ANDOR 20 SWITCH 21 BITTEST 22 BITSET 23 BITCLEAR 24 LOWPASSFILTER...
Page 226 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value 7 NEGATE 8 MPYDIV 9 REMAINDER 10 COMPARE-GT 11 COMPARE-GEQ COMPARE- EQUAL 13 COMPARE- 14 TIMER 15 LIMIT 16 AND 17 OR 18 XOR 19 ANDOR 20 SWITCH 21 BITTEST...
Page 227 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value 5 MAX 6 ABS 7 NEGATE 8 MPYDIV 9 REMAINDER 10 COMPARE-GT 11 COMPARE-GEQ COMPARE- EQUAL COMPARE- NEQUAL 14 TIMER 15 LIMIT 16 AND 17 OR 18 XOR 19 ANDOR...
Page 228 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value 3 ADDSUB 4 MIN 5 MAX 6 ABS 7 NEGATE 8 MPYDIV 9 REMAINDER 10 COMPARE-GT 11 COMPARE-GEQ COMPARE- EQUAL COMPARE- NEQUAL 14 TIMER 15 LIMIT 16 AND 17 OR...
Page 229 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value 0 NOP 1 ADD 2 SUB 3 ADDSUB 4 MIN 5 MAX 6 ABS 7 NEGATE 8 MPYDIV 9 REMAINDER 10 COMPARE-GT 11 COMPARE-GEQ COMPARE- EQUAL COMPARE-...
Page 230 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value User function User 0h1E32 -32767-32767 I/P p.115 output10 Output10 0 NOP 1 ADD 2 SUB 3 ADDSUB 4 MIN 5 MAX 6 ABS 7 NEGATE 8 MPYDIV 9 REMAINDER...
Page 231 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value User function User 0h1E36 0-0xFFFF I/P p.115 input11-C Input11-C User function User 0h1E37 -32767-32767 I/P p.115 output11 Output11 0 NOP 1 ADD 2 SUB 3 ADDSUB 4 MIN 5 MAX...
Page 232 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value User function User 0h1E3A 0-0xFFFF I/P p.115 input12-B Input12-B User function User 0h1E3B 0-0xFFFF I/P p.115 input12-C Input12-C User function User 0h1E3C -32767-32767 I/P p.115 output12 Output12...
Page 233 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value User function User 0h1E3E 0-0xFFFF I/P p.115 input13-A Input13-A User function User 0h1E3F 0-0xFFFF I/P p.115 input13-B Input13-B User function User 0h1E40 0-0xFFFF I/P p.115 input13-C Input13-C...
Page 234 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value 27 UPCOUNT 28 DOWNCOUNT User function User 0h1E43 0-0xFFFF I/P p.115 input14-A Input14-A User function User 0h1E44 0-0xFFFF I/P p.115 input14-B Input14-B User function User 0h1E45 0-0xFFFF...
Page 235 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value 25 PI_CONTORL 26 PI_PROCESS 27 UPCOUNT 28 DOWNCOUNT User function User 0h1E48 0-0xFFFF I/P p.115 input15-A Input15-A User function User 0h1E49 0-0xFFFF I/P p.115 input15-B Input15-B User function...
Page 236 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value 23 BITCLEAR 24 LOWPASSFILTER 25 PI_CONTORL 26 PI_PROCESS 27 UPCOUNT 28 DOWNCOUNT User function User 0h1E4D 0-0xFFFF I/P p.115 input16-A Input16-A User function User 0h1E4E 0-0xFFFF...
Page 237 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value 21 BITTEST 22 BITSET 23 BITCLEAR 24 LOWPASSFILTER 25 PI_CONTORL 26 PI_PROCESS 27 UPCOUNT 28 DOWNCOUNT User function User 0h1E52 0-0xFFFF I/P p.115 input17-A Input17-A User function...
Page 238 Table of Functions Comm. Initial Code Name LCD Display Setting Range Property* V/F SL Ref. Address Value 19 ANDOR 20 SWITCH 21 BITTEST 22 BITSET 23 BITCLEAR 24 LOWPASSFILTER 25 PI_CONTORL 26 PI_PROCESS 27 UPCOUNT 28 DOWNCOUNT User function User 0h1E57 0-0xFFFF I/P p.115...
Page 239: Groups For Lcd Keypad Only
Table of Functions 6.13 Groups for LCD Keypad Only 6.13.1 Trip Mode (TRP Last-x) Code Name LCD Display Setting Range Initial Value Ref. Trip type display Trip Name(x) Frequency reference at trip Output Freq Output current at trip Output Current Acceleration/Deceleration Inverter State state at trip...
Page 240 Table of Functions Code Name LCD Display Setting Range Initial Value Ref. Status window display Anytime Para 0 Frequency 0: Frequency item Monitor mode display Monitor Line-1 1 Speed 0: Frequency item1 Monitor mode display 2:Output Monitor Line-2 2 Output Current item2 Current 3 Output Voltage...
Page 241 Table of Functions Code Name LCD Display Setting Range Initial Value Ref. 7 OUT Grp 8 COM Grp 9 APP Grp 11 APO Grp 12 PRT Grp 13 M2 Grp 0 View All Display changed Changed Para 0:View All Parameter 1 View Changed 0 None 1 JOG Key...
Page 242 Table of Functions Code Name LCD Display Setting Range Initial Value Ref. 0 No Power consumption WHCount Reset 0:No initialization 1 Yes Accumulated inverter Year/month/day On-time motion time hour:minute Accumulated inverter Year/month/day Run-time operation time hour:minute 0 No 0:No Accumulated inverter operation time Time Reset 1 Yes...
Page 243: Troubleshooting
This chapter explains how to troubleshoot a problem when inverter protective functions, fault trips, warning signals, or a fault occurs. If the inverter does not work normally after following the suggested troubleshooting steps, please contact the LSIS customer service center. 7.1 Trips and Warnings When the inverter detects a fault, it stops the operation (trips) or sends out a warning signal.
Page 244 Operates when PRT-31 is set to 1. * S100 inverters rated for 4.0 kW or less do not support the ground fault trip (GFT) feature. Therefore, an over current trip (OCT) or over voltage trip (OVT) may occur when there is a low- resistance ground fault.
Page 245 Troubleshooting LCD Display Type Description Displayed when an error is detected in the temperature sensor of the NTC Open Latch Insulated Gate Bipolar Transistor (IGBT). Displayed when an error is detected in the cooling fan. Set PRT-79 to 0 to Fan Trip Latch activate fan trip (for models below 22 kW capacity).
Page 246: Warning Messages
Troubleshooting 7.1.2 Warning Messages LCD Display Description Displayed when the motor is overloaded. Operates when PRT-17 is set to 1. To operate, Over Load select 5. Set the digital output terminal or relay (OUT-31 or OUT-33) to 5 (Over Load) to receive overload warning output signals.
Page 247: Troubleshooting Fault Trips
Troubleshooting 7.2 Troubleshooting Fault Trips When a fault trip or warning occurs due to a protection function, refer to the following table for possible causes and remedies. Type Cause Remedy The load is greater than the motor’s rated Ensure that the motor and inverter have capacity.
Page 248 Check the input wiring. Open Replace the DC link capacitor. Contact The DC link capacitor needs to be replaced. the retailer or the LSIS customer service center. The load is greater than the rated motor Replace the motor and inverter with capacity.
Page 249: Troubleshooting Other Faults
Troubleshooting 7.3 Troubleshooting Other Faults When a fault other than those identified as fault trips or warnings occurs, refer to the following table for possible causes and remedies. Type Cause Remedy The inverter is in operation (driving Stop the inverter to change to program mode).
Page 250 Troubleshooting Type Cause Remedy Determine if the cable on the output The wiring for the motor output cable is side is wired correctly to the phase The motor incorrect. (U/V/W) of the motor. rotates in the The signal connection between the opposite control circuit terminal (forward/reverse direction to the...
Page 251 Troubleshooting Type Cause Remedy properties and the inverter parameter are incorrect. The stall prevention level during Change the stall prevention level. acceleration is low. The stall prevention level during Change the stall prevention level. operation is low. Change to vector control operation mode.
Page 252 Troubleshooting Type Cause Remedy Check the capacity of the earth leakage breaker and make the appropriate connection, based on the rated current of the inverter. Lower the carrier frequency. Make the cable length between the inverter and the motor as short as possible.
Page 253: Maintenance
Maintenance 8 Maintenance This chapter explains how to replace the cooling fan, the regular inspections to complete, and how to store and dispose of the product. An inverter is vulnerable to environmental conditions and faults also occur due to component wear and tear. To prevent breakdowns, please follow the maintenance recommendations in this section.
Page 254: Annual Inspections
Maintenance Inspection Inspection Inspection Judgment Inspection Inspection details area item method standard equipment Turn off the system and Is there any Cooling check Fan rotates Cooling fan abnormal vibration system operation by smoothly or noise? rotating the fan manually. Check and Check the Voltmeter, Measuring...
Page 255 Maintenance Inspection Inspection Inspection Judgment Inspection Inspection item area details method standard equipment Is there any damage to cable insulation? Is there any Visual Terminal block damage? inspection abnormality Measure Rated Smoothing Measure with electrostatic capacity over Capacity meter capacity meter. condenser capacity.
Page 256: Bi-Annual Inspections
Maintenance 8.1.3 Bi-annual Inspections Inspection Inspection Inspection Inspection Judgment Inspection area item details method standard equipment Megger test Disconnect the (between the cables for Insulation Must be Motor input, output terminals U/V/ DC 500 V Megger resistance above 5 MΩ and earth W and test the terminals).
Page 257: How To Replace The Cooling Fans
Maintenance 8.2.2 How to Replace the Cooling Fans Turn off the power when replacing cooling fans. Replace the cooling fans following the steps below: Refer to the illustration and remove the 4 bolts securing the fan bracket. Remove the fan bracket and disconnect the fan connector. Connect the new fan’...
Page 258: Storage And Disposal
Maintenance 8.3 Storage and Disposal 8.3.1 Storage If you are not using the product for an extended period, store it in the following way: • Store the product in the same environmental conditions as specified for operation (refer to 1.3 Installation Considerations on page 4).
Page 259: Technical Specification
(Non EMC Filter type) (55/25) (75/34) (75/34) *S100 inverters rated at 30 kW or more do not support I/O extensions or IP66 certification. *The 55-75 kW inverters do not have built-in EMC since they satisfy EMC standards even without it.
Page 260 Technical Specification Note Precautions for 1–phase input to 3-phase drive • Please connect single-phase input to R(L1) and T(L3). • AC or DC reactor is necessary to reduce DC ripple. Please select built-in reactor type for 30~75kW. For 0.4~22kW, external AC or DC reactor should be installed. •...
Page 261: Product Specification Details
Technical Specification 9.2 Product Specification Details Items Description Control method V/F control, slip compensation, sensorless vector Frequency settings Digital command: 0.01 Hz power resolution Analog command: 0.06 Hz (60 Hz standard) Frequency accuracy 1% of maximum output frequency Control V/F pattern Linear, square reduction, user V/F Heavy load rated current: 150% 1 min, normal load rated current: Overload capacity...
Page 262 Technical Specification Items Description collector terminal Multi function Less than (N.O., N.C.) AC250 V 1A, relay Less than DC 30 V, 1A terminal Analog 0-12Vdc (0-24 mA): Select frequency, output current, output output voltage, DC terminal voltage and others Pulse train Maximum 32 kHz, 10-12V •...
Page 263: External Dimensions (Ip 20 Type)
Technical Specification Items Description -20°C-65°C (-4–149°F) Storage temperature. Prevent contact with corrosive gases, inflammable gases, oil Surrounding stains, dust, and other pollutants (Pollution Degree 3 environment Environment). Operation No higher than 3280ft (1,000m). Less than9.8 m/sec (0.6G). altitude/oscillation Pressure 70-106 kPa 9.3 External Dimensions (IP 20 Type) 30 kW (3-Phase)
Page 264 Technical Specification 37–45 kW (3-Phase) 55–75 kW (3-Phase)
Page 265: Peripheral Devices
0550S100-4 524.5 (21.7) (12.2) 0750S100-4 Units: mm (inches) 9.4 Peripheral Devices Compatible Circuit Breaker, Leakage Breaker and Magnetic Contactor Models (manufactured by LSIS) Circuit Breaker Leakage Breaker Magnetic Contactor Product(kW) Model Current (A) Model Current (A) Model Current (A) Model...
Page 266: Terminal Screw Specification
Technical Specification Only use Class H or RK5, UL listed input fuses and UL listed circuit breakers. See the table above for the voltage and current ratings for fuses and circuit breakers. Utiliser UNIQUEMENT des fusibles d’entrée homologués de Classe H ou RK5 UL et des disjoncteurs UL. Se reporter au tableau ci-dessus pour la tension et le courant nominal des fusibless et des disjoncteurs.
Page 267: Dynamic Braking Unit(Dbu) And Resistors
LSLV0750DBU-4LN Note • It is not necessary to use option type dynamic braking unit for S100 below 22kW capacity because basically the dynamic braking unit is built in. • You must refer to dynamic braking unit manual for usage recommended dynamic braking unit in the table above due to changeable table.
Page 268 Technical Specification Group 3: Terminals Functions Ground Terminal Terminal for connection with B2 of DBU Terminal for connection with B1 of DBU Terminal for connection with N of Inverter Terminal for connection with P1 of Inverter Group 4,5: P(+) N(-) Terminals Functions P(+)
Page 269: Dimensions
Technical Specification 9.7.3 Dimensions Group1 Group 2 ynamic raking Dynamic RESE POWE WIRING (P2)     166.2 Group 3 Group 5 WIRING (P2)
Page 270 Technical Specification Hole position for Capacity of Dimension (mm) Voltage Weight Hole size for installation (mm) applied (kg) installation(φ) motor(kW) 30~37 1.56 227.4 76.4 215.4 45~75 1.85 Group 4 Hole position for Capacity of Dimension (mm) Voltage Weight Hole size for installation (mm) applied (kg)
Page 271: Display Functions
Technical Specification 9.7.4 Display Functions DB Resistors connect with B1, B2 of DB Unit. DBU has 3 LEDs. Red LED which is located in middle displays supplying main power, one Green LED which is right side displays under breaking and another green LED which is left side displays Over Heat Trip(OHT).
Page 272: Continuous Rated Current Derating
Technical Specification 9.8 Continuous Rated Current Derating Derating by Carrier Frequency The continuous rated current of the inverter is limited based on the carrier frequency. Refer to the following graph. Item Unit 30 kW 37 kW 45 kW 55 kW 75 kW s, ND [kHz]...
Page 273: Heat Emmission
Technical Specification Derating by Ambient Temperature and Installation Type The constant-rated current of the inverter is limited based on the ambient temperature and installation type. Refer to the following graph. 9.9 Heat Emmission The following graph shows the inverters’ heat emission characteristics (by product capacity). Heat emission data is based on operations with default carrier frequencysettings, under normal operating conditions.
Page 274: Product Warranty
Warranty Service Information During the product warranty period, warranty service (free of charge) is provided for product malfunctions caused under normal operating conditions. For warranty service, contact an official LSIS agent or service center.
Page 275 • power supply problems or from other appliances being connected to the product • acts of nature (fire, flood, earthquake, gas accidents etc.) • modifications or repair by unauthorized persons • missing authentic LSIS rating plates • expired warranty period Visit Our Website http://www.lsis.com for detailed service information.
Page 279 UL mark The UL mark applies to products in the United States and Canada. This mark indicates that UL has tested and evaluated the products and determined that the products satisfy the UL standards for product safety. If a product received UL certification, this means that all components inside the product had been certified for UL standards as well.
Page 280: Revision History
Manual Revision History Revision History Date Edition Changes 2014.02 First Release 2014.11 Edition S/W Version up(V2.0) 2015.06 Edition S/W Version up(V2.3) 2016.09 Edition S/W Version up(V2.5)
Page 281: Index
Index Index Delta Freq ..................89 Max Freq ..................89 Acc/Dec reference frequency ..........89 [DOWN] key ..................38 Ramp T Mode................89 [ESC] key ..................... 38 Acc/Dec stop ................... 96 [HAND] key ..................38 Acc/Dec time ................... 89 [LEFT] key.................... 38 Acc/Dec time switch frequency .........93 [MODE] key ..................
Page 282 Index BAS(Basic function group) ..........160 communication ................125 command loss protective operation ......129 basic configuration diagram ..........12 communication address ............. 138 Basic group ..Refer to BAS (Basic function group) communication line connection........126 basic operation ................37 communication parameters..........
Page 283 Index filter time constant ..............68 Ｅ filter time constant number ..........112 earth leakage breaker............239 free run stop ................. 106 EG terminal ..................25 frequency jump ................110 EMC filter .................... 29 frequency limit ................108 asymmetric power source ............29 frequency jump ...............
Page 284 Index [MULTI] key ..................38 ID(illegal data value) ............... 137 [OFF] key ..................38 IF(illegal function) ..............137 [PROG / Ent] key................38 In Phase Open ................232 [STOP/RESET] key ..............38 configuration mode ..............43 IN(Input Terminal Block Function group) ....180 cursor keys ..................38 input terminal .................
Page 285 Index multi-keypad ................. 114 Ｍ master parameter ..............114 setting ................... 114 M2(2nd Motor Function group) ........202 multi-step frequency ..............79 magnetic contactor ............21, 253 setting ....................79 maintenance ................. 241 Speed-L/Speed-M/Speed-H ..........79 manual torque boost ............. 101 Master ....................126 Ｎ...
Page 286 R/S/T terminals ................20 S+/S-/SG terminal ............... 26 start at power-on Power-on Run ....... Refer to S100 expansion common area parameter Preinsulated Crimp Terminal ..........26 control area parameter(Read/Write) ......151 protocol .................... 133 memory control area parameter(Read/Write) ..153 LS INV 485 protocol ...............
Page 287 Index SC terminal ..................24 terminal ..................... 112 A terminal..................112 screw specification B terminal ..................112 control circuit terminal screw ........... 254 terminal for frequency reference setting ..Refer to input/output terminal screw ..........254 screw size ..................254 VR terminal screw torque ................
Page 288 Index void parameter ............. 115, 119 voltage drop ..................21 user V/F pattern Operation ..........99 voltage/current output terminal ....Refer to AO USF ....................... 207 terminal using the keypad................45 VR terminal ................24, 67 navigating through the codes (functions) ....50 parameter settings ..............53 Ｗ...

This manual is also suitable for:

Lslv-s100

LSIS S100 Manual

1 Preparing the Installation

2 Installing the Inverter

3 Learning to Perform Basic Operations

4 Learning Basic Features

5 Communication Features

6 Table of Functions

7 Troubleshooting

8 Maintenance

9 Technical Specification

Product Warranty

Index

Quick Links

Troubleshooting

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LSIS S100

Summary of Contents for LSIS S100

This manual is also suitable for:

Table of Contents
