Web Page Item
Slow Blink
Fast Blink
Color
Brightness
Red
Green
Blue
Intrusion Sensor Settings
Flash Button LED
Activate Relay
Play Audio Locally
Make call to extension
Dial Out Extension
Dial Out ID
Play recorded audio
Repeat Intrusion Message
Intrusion Sensor Strobe Settings
Blink Strobe on Intrusion Sensor
Scene
ADA Compliant
Operations Guide
Installing the Singlewire InformaCast Indoor Intercom with Keypad
Table 2-21. Sensor Configuration Parameters (continued)
Description
Strobe will blink ON at the specified brightness for one second
then OFF for one second during the duration of the event.
Strobe will blink ON at the specified brightness then OFF five
times per second during the duration of the event.
Select desired color (only one may be chosen).
How bright the strobe will blink when the sensor is triggered. This
is the maximum brightness for "fade" type scenes.
The red LED value for the Sensor.
The green LED value for the Sensor.
The blue LED value for the Sensor.
Use this button to preview the strobe flashing behavior for the
Sensor Strobe Settings.
When selected, the Call button LED will flash until the intrusion
sensor is deactivated (roughly 10 times/second).
When selected, the device's on-board relay will be activated until
the intrusion sensor is deactivated.
When selected, the device will loop an audio file out of the
speaker until the intrusion sensor is deactivated.
When selected, the device will call an extension when the
intrusion sensor is activated. Use the Dial Out Extension field
below to specify the extension the device will call.
Specify the extension the device will call when the intrusion
sensor is activated. Enter up to 64 alphanumeric characters.
An additional Caller identification string added to outbound calls.
Enter up to 64 alphanumeric characters.
When selected, the device will call the Dial Out Extension and
play an audio file (corresponds to Intrusion Sensor Triggered
on the Audiofiles page) to the phone answering the SIP call
when the intrusion sensor is activated.
The number of times to repeat the audio message through the
local speaker or to the remote endpoint. A value of 0 will repeat
forever. Enter a value from 0-65536.
The following strobe settings will only appear if a CyberData
Strobe product is connected to your device. If a CyberData
Strobe product is not connected to your device, you will not
see the strobe settings.
When selected, the Strobe will blink a scene when the intrusion
sensor is triggered.
Select desired scene (only one may be chosen).
Strobe will blink ON at the specified brightness for 150ms then
OFF for 350ms during the duration of the event.
931640A
Configure the Sensor Configuration Parameters
