2.3.4 Connecting an Auxiliary RGB Strobe to the Device

1. Connect the strobe cable to the board of the Auxiliary RGB Strobe and the board of the device
Figure 2-11. Connecting the Auxiliary RGB Strobe Kit to the Device
Device Board
Operations Guide
as shown in Figure 2-11. Please see the Auxiliary RGB Strobe Operations Guide for more
information about this product.
