1.3 TECHNICAL SPECIFICATIONS
MURELLE EQUIPE
Generators with a heat output kW 46.7
Heat output
Nominal (80-60°C) (Pn max)
Nominal (50-30°C) (Pn max)
Minimum (80-60°C) (Pn min)
Minimum (50-30°C) (Pn min)
Heat input (*)
Nominal (Qn max - Qnw max)
Minimum (Qn min - Qnw min)
Min/max operating yield (80-60°C)
Min/max operating yield (50-30°C)
Operating yield at 30% (40-30°C)
Losses after shutdown to 50°C (EN 15502)
Supply voltage
Adsorbed power consumption (Qn max)
Adsorbed power consumption (Qn min)
Absorbed power
Energy efficiency
Seasonal energy efficiency class of the heating system
Seasonal energy efficiency of the heating system
Sound power of the heating system
Single module temperature regulation
Water content modules
Max operating pressure (PMS)
Max operating temperature (T max)
Exhaust temperature at nominal input (80-60°C)
Exhaust temperature at minimum input (80-60°C)
Exhaust temperature at nominal input (50-30°C)
Exhaust temperature at minimum input (50-30°C)
Minimun/Maximum exhaust capacity
CO at input minimum/nominal (G20)
2
CO at input minimum/nominal (G31)
2
NOx measured (EN 15502-1:2015)
Maximum pressure exhaust manifold output
PIN number
Category
Type
NOx emission class (EN 15502-1:2015)
Weight when empty
Gas and nozzle pressure
Supply pressure (G20)
Supply pressure (G31)
Number of nozzles
Nozzle diameter (G20)
Nozzle diameter (G31)
Consumption at nominal power (G20)
Consumption at minimum power (G20)
Consumption at nominal power (G31)
Consumption at minimum power (G31)
(*) Heat input of the heating system measured using lower heating value (LHV)
6
100 BOX ErP
n°
kW
kW
kW
kW
kW
kW
% 96.1/97.3
% 109.0/106.2
%
W
V-Hz
W 282 (2 x 141)
W
%
dB (A)
°C
l
bar (kPa) 3.5 (343)
°C
°C
°C
°C
°C
g/s 4.2/44.4
%
% 10.0/10.3
mg/kWh
Pa
1312CM5620
B23-B53-B23P-B53P
6 (‹ 56 mg/kWh)
kg
mbar (kPa) 20 (1.96)
mbar (kPa) 37 (3.63)
n°
ø
ø
m /h
3
m /h
3
kg/h
kg/h
150 BOX ErP
2 3
93.4 140.1
102.0 153.0
9.2 9.2
10.5 10.5
96.0 144.0
9.6 9.6
96.1/97.3
109.0/106.2
108.5 108.5
320 480
230-50 230-50
423 (3 x 141)
93 98
IPX4D IPX4D
A A
93 93
--- ---
20/80 20/80
25.5 43.7
3.5 (343)
85 85
68 68
58 58
49 49
42 42
4.2/66.7
9.0/9.3 9.0/9.3
10.0/10.3
20 20
100 100
1312CM5620
II2H3P II2H3P
B23-B53-B23P-B53P
6 (‹ 56 mg/kWh)
233 381
20 (1.96)
37 (3.63)
2 3
8.0 8.0
5.5 5.5
10.30 15.45
1.01 1.01
7.45 11.19
0.75 0.75
