Installation
Install the batteries into the instrument body and connect the camera and flexible tube to the
body. Attach any accessory as needed.
Battery Installation
1.
Remove the battery compartment cover
2.
Insert four new AA batteries into the proper slots in the battery compartment. Proper
battery orientation is indicated on the battery compartment.
3.
Reinstall battery compartment and battery cover .
Note: Do Not Mix Old and New Batteries. Do Not Mix Alkaline, Standard (Carbon‐Zinc), Or
Rechargeable (Nickel Cadmium)
Connect the monitor and flexible tube
Connect the camera tube to the instrument body. Ensure that the keyed ends are properly
aligned. Once aligned, tighten the knurled knob to hold the connection firmly in place.
Installing the accessory tools
The included accessories (mirror, hook and magnet) all attach to the camera in the same
manner. Refer to the diagrams below:
www.ponpe.com
4
BR70-en-GB_V2.1 11/14
