Components and operator's controls

7.1

Components

1
2
7
Item Designation
1 Rechargeable battery (optional)
2 Central lifting point
3 Protective cage
4 Rubber-metal buffer
7.2

Operator's controls

1
Item Designation
1 Lock
2 Switching and safety lever
100_0202_cp_0013.fm
3
4
6
5
3
7 Components and operator's controls
Item Designation
5 Exciter
6 Base plate
7 Water tank (optional)
8 Nameplate
2
Item Designation
3 Control handle
