Summary of Contents for Wacker Neuson VPY70
- Page 1 Operator’s Manual Vibroplate VPY70 5000403286 1118...
- Page 2 Wacker Neuson Machinery (China) Co., Ltd. Any type of reproduction or distribution not authorized by Wacker Neuson Machinery (China) Co., Ltd. represents an infringement of valid copyrights. Violators will be prosecuted.
-
Page 3: Foreword
(China) Co., Ltd. will be referred to as Wacker Neuson. Keep a copy of the Operator’s Manual with the machine at all times. If you are missing any of these documents, please contact Wacker Neuson to order a replacement or visit www.wackerneuson.com. - Page 4 The information contained in this manual is based on machines manufactured up until the time of publication. Wacker Neuson reserves the right to change any portion of this information without notice. The illustrations, parts, and procedures in this manual refer to Wacker Neuson factory-installed components.
-
Page 5: Table Of Contents
VPY70 Table of Contents Foreword Safety Information Signal Words Used in this Manual ............7 Machine Description and Intended Use ..........8 Operating Safety .................. 9 Operator Safety while Using Internal Combustion Engines ....11 Service Safety ..................12 Labels Label Locations .................. - Page 6 Table of Contents VPY70 Maintenance Maintaining the Emission Control System .........21 Periodic Maintenance Schedule ..........21 Servicing the Air Cleaner ..............23 Changing the Engine Oil ..............24 Servicing the Drive Belt ....
-
Page 7: Safety Information
VPY70 Safety Information Safety Information Signal Words Used in this Manual This manual contains DANGER, WARNING, CAUTION, NOTICE, and NOTE signal words which must be followed to reduce the possibility of personal injury, damage to the equipment, or improper service. -
Page 8: Machine Description And Intended Use
VPY70 Safety Information Machine Description and Intended Use The Wacker Neuson vibratory plate offers functionality and performance. The compact design allows for compaction of mixed soils in the narrowest of spaces— even in extremely narrow trenches. This machine is optimally suited for a variety of compaction applications with high speed and simple maneuverability. -
Page 9: Operating Safety
To ensure safe operation of the machine: Do not operate the machine if any safety devices or guards are missing or inoperative. Do not modify or defeat the safety devices. Only use accessories or attachments that are approved by Wacker Neuson. wpm_si000994gb.fm... - Page 10 VPY70 Safety Information Safe When operating this machine: operating Remain aware of the machine’s moving parts. Keep hands, feet, and loose practices clothing away from the machine’s moving parts. When operating this machine: Do not operate a machine in need of repair.
-
Page 11: Operator Safety While Using Internal Combustion Engines
VPY70 Safety Information Operator Safety while Using Internal Combustion Engines WARNING Internal combustion engines present special hazards during operation and fueling. Failure to follow the warnings and safety standards could result in severe injury or death. Read and follow the warning instructions in the engine owner’s manual and the safety guidelines below. -
Page 12: Service Safety
Machine When servicing or maintaining the machine: modifications Use only accessories/attachments that are approved by Wacker Neuson. When servicing or maintaining the machine: Do not defeat safety devices. Do not modify the machine without the express written approval of Wacker Neuson. - Page 13 VPY70 Safety Information Cleaning When cleaning and servicing the machine: Keep the machine clean and free of debris such as leaves, paper, cartons, etc. Keep the labels legible. When cleaning the machine: Do not clean the machine while it is running.
-
Page 14: Labels
VPY70 Labels Labels Label Locations wpm_si000995gb.fm... -
Page 15: Label Meanings
When ordering parts requesting service information, you will always be asked to specify the model number, item number, revision number, and serial number of the unit. Wacker Neuson Logo wpm_si000995gb.fm... -
Page 16: Lifting And Transporting
VPY70 Lifting and Transporting Lifting and Transporting Lifting the This machine is heavy enough to cause injury if proper lifting techniques are not Machine used. Observe the following guidelines when lifting the vibroplate. Do not attempt to lift the machine unassisted. Use appropriate lifting equipment such as slings, chains hooks, ramps or jacks. -
Page 17: Operation
1. Make sure all loose packaging materials have been removed from the machine. 2. Check the machine and its components for damage. If there is visible damage, do not operate the machine! Contact your Wacker Neuson dealer immediately for assistance. -
Page 18: Application
VPY70 Operation Application This plate is designed for compacting loose, granular soils and gravel. It is intended to be used in confined areas and areas next to structures such as walls, curbs, and foundations. This plate is not recommended for compacting cohesive soils with a heavy clay content. -
Page 19: Starting The Machine
VPY70 Operation Starting the Machine Procedure Perform the procedures below to start the machine. 1. Open the fuel valve (a2). 2. Push the engine throttle lever to “RUN” (b2). 3. Pull out the starter handle until you feel strong resistance, then let it return slowly. -
Page 20: Operation
VPY70 Operation Operation Run the engine at full throttle and allow the plate to pull itself along at its normal speed. When operating on an incline, it may be necessary to assist the plate by pushing it forward slightly. When operating downhill, hold the plate back slightly, if it begins to pickup speed. -
Page 21: Maintenance
WACKER NEUSON. The use of service parts that are not equivalent in performance and durability by authorized parts may impair the effectiveness of the emission control system and may have a bearing on the outcome of a warranty. - Page 22 VPY70 Maintenance Machine Maintenance The chart below lists basic machine maintenance. After Daily Every Every Every first before 50 hr 100 hr 300 hr 20 hr starting or 3 mo. or 6 mo. or 1 yr. or 1mo. Check the external hardware...
-
Page 23: Servicing The Air Cleaner
VPY70 Maintenance Servicing the Air Cleaner Background A dirty air filter element can restrict air flowing into the carburetor. To keep the carburetor in good working conditions, service the air filter element periodically. If operating the engine in extremely dusty area, the job should be done more often. -
Page 24: Changing The Engine Oil
VPY70 Maintenance Changing the Engine Oil Procedure Perform th procedure below to change the engine oil. 1. Always check the oil level before starting the engine. Add oil if the level is low (L). 2. To check the oil, remove dipstick (a) and insert it into the oil pan. Do not screw in the dipstick. -
Page 25: Servicing The Drive Belt
VPY70 Maintenance Servicing the Drive Belt Check On new machines or after installing a new belt, check the belt tension after first 20 hours of operation. Check and adjust the belt every 50 hours thereafter. wpm_gr013521 wpm_tx004317gb.fm... -
Page 26: Cleaning The Plate
VPY70 Maintenance Cleaning the Plate Clean the plate after use to remove dirt, stones, and mud caught under the engine console. If the plate is being used in a dusty area, check the engine cylinder cooling fins for heavy dirt accumulation. Keep the engine cylinder fins clean to prevent it from overheating. -
Page 27: Troubleshooting
VPY70 Troubleshooting Troubleshooting Problem Cause Remedy Plate does not • Engine throttle control not • Allow soil to dry before develop full speed. completely open. compacting. Poor compaction. • Throttle control not adjusted • Adjust or replace belt. correctly. •... -
Page 28: Technical Data
VPY70 Technical Data Technical Data Engine Data Engine Power Rating Net power rating per SAE J1349. Actual power output may vary due to conditions of specific use. VPY70 Engine Engine make Yanmar Engine model L48N Maximum rated power kW (hp) 3.1 (4.2) @ 3600 rpm... -
Page 29: Machine Data
VPY70 Technical Data Machine Data VPY70 Plate Weight kg (lbs.) 92 (202.4) Exciter speed 7000 Exciter lubrication Mobil XHP222 wpm_td000683gb.fm... -
Page 30: Dimensions
VPY70 Dimensions Dimensions 1120 (44) 460 (18) 610 (24) wpm_gr008416 wpm_td000683gb.fm...
