7.3 Scope of delivery

-
Smart Visu Server including software
-
Retaining bracket for wall or support rail mounting
-
Operating instructions
-
Power supply unit with plug
o SV-SERVER: EU power supply unit (Euro plug)
o SV-SERVER-INT: Power supply unit, including adapter for BS (United
Legal information
Philips and Hue are registered trademarks of Koninklijke Philips Electronics NV.
This product contains Open Source software components, which are subject to the
conditions of Copyright and/or the license agreements of third parties. The license
information is located on the Smart Visu Server.

7.4 Technical data

Rated voltage:
Power consumption:
Ambient temperature:
Storage/transport temperature:
LAN:
USB:
Dimensions:
Power supply unit with plug:
Primary voltage:
Mains frequency:
Rated current:
Secondary voltage:
Protection class:
Length of connecting cable:
Plug contact:
SV- SERVER / SV-SERVER-INT
Kingdom), EU (Euro plug) and CN (China)
DC 12 V SELV
Typ. 3 W, max. 7 W
–5 ... +45 °C
–25 ... +70 °C
RJ45 socket (10/100 Mbit/s Fast Ethernet) CAT5
USB 2.0 Host
124 x 72 x 31 mm (without retaining unit)
124 x 92 x 40 mm (with retaining unit)
AC 100 ... 240 V ~
50 / 60 Hz
Max. 1 A
DC 12 V SELV
II
1.5 m
SV-SERVER: EU
SV-SERVER-INT: BS,EU,CN
CAUTION
This device contains a battery (CR1632, 0.4 Wh) to back up the saved
data. Do not dispose of discharged batteries with domestic waste. During
transport, comply with the special regulations of the ADR and IATA.
84 / 187
