Rollershutter/Awning:
The "Rollershutter/Awning" function (1) is the KNX function for control of motorised roller
shutters/awnings with position specification. The motorised drive can be activated by the
group addresses "Long time" (2), "Short time" (3) and "Position specification" (4).
The "Position feedback" (5) group address must be configured for reading the position. In
addition, the current status of a selectable group address can be polled by defining an
initialisation address (6) on starting the system.
Figure 92: Parameters of the "Rollershutter/Awning" function
The function possesses the following individualisation options within the icon library (7).
KNX function Selection of the icon library in SV-Control
Rollershutter/Awning
Table 41: Display of the "Rollershutter/Awning" function
SV- SERVER / SV-SERVER-INT
7
1
2
3
4
5
6
Operating and display element in SV-Home
