Operation Mode:
The "Operation Mode" function (1) can be used to influence a KNX climate control system
by setting an operating mode.
The group address for operating mode switch-over can be entered in the input field (2), in
order to show the corresponding feedback address in the input field (3). You can select an
initialisation address for the operating mode in the drop-down menu (4).
Using the input fields (5 to 8), it is possible to assign an individual display name for the four
KNX operating modes. Depending on the controller model and manufacturer, there may be
differences in the order of the operating modes (please consult the documentation of the
controller you are using). You can set the order individually using the number fields (5 to 8)
to use the Smart Visu Server for your climate controller.
Figure 96: Parameters of the "Operating Mode" function
The function possesses the following individualisation options within the icon library (9).
KNX function Selection of the icon library in SV-Control
Operation Mode
SV- SERVER / SV-SERVER-INT
9
Table 45: Display of the "Operation Mode" function
1
2
3
4
5
6
7
8
Operating and display element in SV-Home
