Dimmer:
The "Dimmer" function (1) is used for simple dimming of dimmer actuators. A "Brightness
value" (2) group address can be configured for switching or writing a new brightness value.
In the same way, to read the feedback, it is possible to configured the group addresses
"Brightness value feedback" (3).
In addition, the current status of a selectable group address can be polled by defining an
initialisation address (5) on starting the system.
5
1
2
3
4
Figure 88: Parameters of the "Dimmer" function
The function possesses the following individualisation options within the icon library (5).
Auswahl der Symbol-Bibliothek Bedien- und Anzeigeelement
KNX-Funktion
im SV-Control in der SV-Home
Dimmer
Tabelle 37: Darstellung der Funktion „Dimmer"
