8.4.4.2 Scene
The Smart Visu Server supports the execution and learning of KNX function values. If
required, the function type "Scene" can be depicted by two differentiated KNX functions.
Activate Scene:
The "Activate Scene" function (1) is a Smart Visu Server function for executing KNX
scenes.
The function transmits a scene value (2) to the KNX group address entered in the input
field "Scene group address (1 Byte)" (3). With each KNX scene group address, up to 64
scene values (or scene numbers) (2) can be recalled. The scene value (2) the Smart Visu
Server should transmit when a scene is triggered can be set in the input field (2).
Figure 102: Parameters of the "Activate scene" function
The function possesses the following individualisation options within the icon library (4).
KNX
Selection of the icon library in SV-Control
function
Activate
Scene
Table 51: Display of the "Activate scene" function
SV- SERVER / SV-SERVER-INT
4
3
1
2
Operating and display element in SV-Home
