8.4.4.1 Multimedia
Playlist various:
The "Playlist divers (1)" function is the KNX function for controlling simple multimedia
applications.
The volume can be influenced and confirmed by the group addresses "volume" or "volume
feedback" (2).
In the input fields (3) the function can read ASCII characters of the registered group
addresses (for example, playlist, artist, title). If a text is written to these group addresses,
these are visible in the SV home.
Playback can be influenced and confirmed by the group addresses "Play / Pause" or "Play
/ Pause Confirmation" (4). Furthermore, a further playlist (5) or title (6) can be started.
In addition, by declaring two initialization addresses (7) during system startup, the current
status of the function can be queried.
SV- SERVER / SV-SERVER-INT
8
Figure 100: Function „Playlist Various"
1
2
7
3
4
7
5
6
129 / 187
