Ventilate:
The "Ventilate" function (1) allows the display and control of the status of a KNX ventilation
controller.
In the input field (2), it is possible to specify the group address for controlling the fan and,
in the input field (3), it is possible to enter the group address for the feedback of the
currently set fan step.
One of the two group addresses can be selected for the initialisation (4) of the Smart Visu
Server on its system start.
5
1
2
3
4
Figure 95: Parameters of the "Ventilate" function
The function possesses the following individualisation options within the icon library (5).
Selection of the icon library
Operating and display element
KNX function
in SV-Control
in SV-Home
Ventilate
Table 44: Display of the "Ventilate" function
SV- SERVER / SV-SERVER-INT
123 / 187
