8.4.4.2 Motor
If required, the function type "Motor" can be depicted by one of three KNX functions.
UP/DOWN/STOP:
The "UP/DOWN/STOP " function (1) is the KNX function for simple control of motorised
drives without feedback objects. The motorised drive can be activated by the group
addresses "Long time" (2) and "Short time" (3).
Figure 91: Parameters of the "Up/Down/Stop" function
The function possesses the following individualisation options within the icon library (4).
KNX function Selection of the icon library in SV-Control
UP/DOWN/STOP
Table 40: Display of the "Up/Down/Stop" function
SV- SERVER / SV-SERVER-INT
4
1
2
3
Operating and display element in SV-Home
