Glossary

Casters
Two casters are attached to the bottom of the Right and Left Side
Columns to assist in moving the plotter.
Control Panel
The Control Panel controls plotter functions.
Crossbar
A large metal bar that holds the Right and Left Side Columns together to
support the Head unit.
Drive Roll
The Drive Roll moves and "pulls" the paper through the plotter.
Feed Motor Cable
A cable located on the Right Side Column that controls the Feed Motor.
Feed Roll Bar
The Feed Roll Bar holds the Paper Roll and supplies paper to the
plotter. The Mandrels on the Feed Roller are adjustable to
accommodate different paper widths.
Front Cover
The Front Cover must be in the down position for the plotter to function.
When lifted, it provides access to the inkjet cartridges and allows paper
installation.
Front Dancer Bar
This bar is located behind the Paper Take-Up Bar and assists with
paper feeding after printing.
Head Unit
The main plotter unit that contains printing, electrical and electronic
components.
Inkjet Cartridge Holder
This holds the inkjet cartridges, which can range from one to four
cartridges, depending on the model. It is visible and accessible by lifting
the Front Cover.
Right Side Column
This column is to the right side of the plotter.
Left Side Column
This column is to the left side of the plotter.
