Appendix

Supplies
To order Supplies, call 1.800.321.2448 or visit
https://www.gerberscientific.net/GT/eCommerce/login.aspx
online order.
Commonly used supplies and corresponding part numbers are listed
below.
HP 45 Inkjet Cartridge
Mandrel
Paper take-up bar
Table 2. Supplies and part numbers

Troubleshooting

Error message
Exceed plot
width
Invalid X ink jet
cartridge
Edge exceeds
printing range
Paper low
________________________________________________
Item
Possible cause
Marker
parameters
exceed plotter
width and length
1. No ink jet
cartridge in the
ink jet cartridge
holder.
2. Ink jet
cartridge is out of
ink or damaged.
Plot paper is too
narrow or
marker file is too
wide
The paper
quantity is low
Table 3. Troubleshooting
46
to place an
Part Number
558500006
94714000
94541000
Solution
Check if the width of the
plot file exceeds the range
of plotter setting.
Replace the ink jet
cartridge.
1. Change plotter paper to
proper size.
2. Modify the marker file.
3. Restart the plotter after
completing steps 1 or 2.
Refill paper
