in the right hand display during this procedure. Once this has been carried out,
the motor will run as requested.
10. Advance the Speed potentiometer. The value in the right hand display should
increase accordingly, for example
11. Open the RUN FORWARD contact. The display should show a reducing
frequency since the Drive is decelerating, for example
then
rd
Turn the speed potentiometer back to zero.
12. Close the RUN REVERSE contact. The display should show
Fr
13. Advance the Speed potentiometer. The value in the right hand display should
increase accordingly, for example
Fr
The sign LED is lit to show the Drive is running reverse.
14. Open the RUN REVERSE contact. The display should show, for
example
Turn the potentiometer back to zero.
15. If the Drive trips during these tests the display will show, for example
tr
The right hand display will flash with the trip code.
16. To RESET the trip, OPEN and then CLOSE the ENABLE contact or press the
Stop/Reset key. The display should show:
Following a DRIVE TRIP and a RESET via the STOP/RESET key, the RUN
NOTE
FORWARD or RUN REVERSE terminal will need to be OPENED and CLOSED
to allow the Drive to run.
Following a DRIVE TRIP and a RESET via the DRIVE ENABLE terminal, if the
NOTE
RUN FORWARD or RUN REVERSE terminal is already CLOSED, the Drive will
run straight away.
If this test has been carried out as a bench test and the Drive is to be
NOTE
connected to a different motor with different characteristics etc. in the
application, then the motor map parameters should be set to the correct
values for the new motor and another autotune carried out (see parameter 38
for details).
54
Fr
0.0
0.0
31.4
and then
13.7
Fr
OU
25.8
10.3
Fr
0.0
rd
0.0
rd
