Control Techniques Commander SE Series User Manual page 56

calculation may calculate the number of motor poles incorrectly. This would cause an
incorrect slip compensation to be applied and the rpm speed indication would be
incorrect. Therefore, the correct number of motor poles should be programmed
manually.
No. Function Type
Serial RW
41
mode
Used to select the mode of operation of the serial port
AnSI ANSI EIA485 2 wire half duplex serial communications
rtu Modbus RTU protocol
FbUS Fieldbus protocol
When parameter 41 is set to FbUS, it's associated hidden parameters appear
NOTE
- Parameters 45, 46 and 47. Also parameter 42, baud rate, is automatically set
to 19.2.
No. Function Type
42 Baud rate RW
Used to select the comms port baud rate
2.4 2400 baud
4.8 4800 baud
No. Function Type
43 Serial RW
address
Used to define the unique address for the Drive for the serial interface. Any number in
the permitted range 0.0 to 24.7 which has a zero in it should not be used as these are
used in addressing groups of Drives.
No. Function Type
Software RO
44
version
Indicates the version of software fitted to the Drive.
The following three parameters are hidden and only appear when parameter 41 Serial
Mode, is set to Fbus.
No. Function Type
45 Fieldbus RW
Node
Address
No. Function Type
46 Fieldbus RW
Baud rate
No. Function Type
47 Fieldbus RW
Diagnostics
52
Limitations Range
T, R AnSI, rtu, FbUS
Limitations Range
T 2.4, 4.8, 9.6, 19.2.
9.6 9600 baud
19.2 19200 baud
Limitations Range
U 0.0 - 24.7
Limitations Range
U 1.00 - 99.99
Limitations Range
U 0 - 255
Limitations Range
U 0 - 9
Limitations Range
B -9999 - +9999
Units Defaults
AnSI EUR
AnSI USA
Units Defaults
4.8 EUR
4.8 USA
Units Defaults
1.1 EUR
1.1 USA
Units Defaults
- EUR
- USA
Units Defaults
0 EUR
0 USA
Units Defaults
0 EUR
0 USA
Units Defaults
0 EUR
0 USA
Commander SE User Guide
Issue Number 5
