The settings for parameter 05 are explained fully on the following pages.
Parameter 5 set to A1.A2
Local voltage (A1) or remote current (A2) speed reference inputs
Input Terminal 12 Terminal 13
Source
A1 open
A1 open
A2 closed
A2 closed
If the Run Forward and Run Reverse terminals are both closed, the Drive will
NOTE
stop under the selected ramp and stopping modes.
Jog speed reference (parameter 15)
Terminal 12 Terminal 13
open or closed closed
open or closed closed
If jog speed is selected during normal running, the motor will accelerate or
NOTE
decelerate to the jog speed at the normal acceleration ramp (parameter 03) or
deceleration ramp (parameter 04) and then the jog acceleration and
deceleration ramps (0.2 seconds) will be selected. Once jog has been
selected use the Run Forward or Run Reverse terminals to jog.
40
Figure 6.3 Terminal connections
Enable Run Forward
open closed closed
open closed open
open closed closed
open closed open
Enable Run Forward
closed closed
closed open
Run Reverse Motor Action
open Run Forward
closed Run Reverse
open Run Forward
closed Run Reverse
Run Reverse Motor Action
open Jog Forward
closed Jog Reverse
