Control Techniques Commander SE Series User Manual page 14

Table 3.12 Commander SE Size 3, 200V units
AC supply voltage and frequency
Input displacement factor (cos φ)
Nominal motor power - kW
Nominal motor power - HP
Output voltage and frequency
100% RMS output current - A
150% overload current for 60 secs - A
Typical full load input current - A*
Typical inrush current - A** (duration <10ms)
Drive power losses at 230VAC at 6kHz switching
frequency - W
Weight - kg/lb
Cooling fan fitted
* See section 3.1.1.
** For an explanation of inrush current, see section 3.1.2.
Table 3.13 Recommended fuses and cables
Recommended input supply fuse - A
Control cablemm²
AWG
Recommended input cablemm²
AWG
Recommended motor cablemm²
AWG
Recommended braking resistor cablemm²
AWG
Table 3.14 Braking Resistors
Minimum braking resistor value - Ω
Recommended braking resistor value - Ω
Maximum braking current - A
Resistor peak power rating - kW
Before fitting a braking resistor please read the information on Braking, and
NOTE
the Warnings on High Temperatures and Overload Protection at the end of
this section.
10
MODEL
MODEL
MODEL
SE33200...
550 750
3 phase 200 to 240V +/-10%, 48 to 62Hz
>0.97
5.5 7.5
7.5 10.0
3 phase, 0 to input voltage, 0 to 1000Hz
25.0 28.5
37.5 42.8
22.8 24.6
44
230 305
6 / 13.2
Yes
SE33200...
550 750
30
>0.5
20
4.0
10
4.0
10
4.0
10
SE33200...
550 750
11.0
15.0
28.0
11.8
Commander SE User Guide
Issue Number 5
