6.4

Saving parameters

Parameters are automatically saved when the mode button is pressed when going
from parameter edit mode to parameter view mode.
6.5

Security codes

A security code is locked into the Drive when parameter 25 is set to any value other
than 0 and then Loc is selected in parameter 10 and the STOP/RESET key pressed.
Once a security code has been locked, parameter 10 will automatically reset to L1.
Now view only access to parameters 1 to 9 is available.
Parameter 10 may be changed by the user to L2 to allow view only access to all the
parameters (1 to 44). In this case, parameter 25 will indicate a value of 0 so as not to
reveal the programmed security code.
6.6

Setting a security code

1. Set parameter 10 to L2 to allow access to parameter 25.
10
2. Set parameter 25 to a security code e.g. 5.
25
pressed. The display should show:
3. Set parameter 10 to Loc and then press the STOP/RESET key to initiate the
security code
10
4. Parameter 10 will automatically reset to L1
10
5. Security will also be set if the Drive is powered down after a code has been set
into parameter 25.
Commander SE User Guide
Issue Number 5
Figure 6.2 Selecting and changing parameters
L2
5
This code changes to 0 once the MODE key is
Loc
L1
0
25
