No. Function Type
Parameter RW
10
access
L1 - Level 1 access - Only parameters 1 to 10 can be selected for viewing or adjusting.
L2 - Level 2 access - All parameters 1 to 44 can be selected for viewing or adjusting.
Loc - Used to lock a security code in the Drive. See Security codes in Section 6.5.
6.10.3Level 2 parameters
No. Function Type
11 Preset 1 RW
Defines the preset speed 1.
For setting of negative preset speed values, see parameter 17.
No. Function Type
12 Preset 2 RW
Defines the preset speed 2.
For setting of negative preset speed values, see parameter 17.
No. Function Type
13 Preset 3 RW
Defines the preset speed 3.
For setting of negative preset speed values, see parameter 17.
No. Function Type
14 Preset 4 RW
Defines the preset speed 4.
For setting of negative preset speed values, see parameter 17.
No. Function Type
15
Jog RW
reference
Defines the jog speed.
No. Function Type
16 Current RW
input
mode
Defines the current input on Analog input reference 2, terminal 5. Definition of the
current input mode is given in the following sub-table:
Mode
0 - 20
20 - 0
4 - 20
20 - 4
4 - .20
20 - .4
44
Limitations Range
T L1, L2, Loc
Limitations Range
B ±1000.0
Limitations Range
B ±1000.0
Limitations Range
B ±1000.0
Limitations Range
B ±1000.0
Limitations Range
U 0 - 400.0
Limitations Range
T 0-20, 20-0
4-20, 20-4
4-.20, 20-.4
Current input 0 to 20mA (20mA full scale)
Current input 20mA to 0mA (0mA full scale)
Current input 4mA to 20mA with current loop loss (cL) trip (20mA full scale)
Current input 20mA to 4mA with current loop loss (cL) trip (4mA full scale)
Current input 4mA to 20mA with no current loop loss (cL) trip (20mA full scale)
Current input 20mA to 4mA with no current loop loss (cL) trip (4mA full scale)
Units Defaults
L1
L1
Units Defaults
Hz 0.0
0.0
Units Defaults
Hz 0.0
0.0
Units Defaults
Hz 0.0
0.0
Units Defaults
Hz 0.0
0.0
Units Defaults
Hz 1.5
1.5
Units Defaults
mA 4-.20
4-.20
Description
Commander SE User Guide
Issue Number 5
EUR
USA
EUR
USA
EUR
USA
EUR
USA
EUR
USA
EUR
USA
EUR
USA
