Terminal 12
Terminal 13
open
open
closed
open
open
closed
closed
closed
If Enable negative preset speeds (parameter 17) is set, then a negative preset
NOTE
speed will cause the motor to run in the reverse direction. Alternatively,
closing terminal 11 (Run Reverse) instead of terminal 10 will change the sign
of the selected speed such that a positive preset speed will become negative
for reverse rotation.
Parameter 5 set to Pr
4 Preset speeds
Close terminals 12 and 13 as in the following table to select the desired preset speed.
Terminal 12
Terminal 13
open
open
closed
open
open
closed
closed
closed
If Enable negative preset speeds (parameter 17) is set, then a negative preset
NOTE
speed will cause the motor to run in the reverse direction. Alternatively,
closing terminal 11 (Run Reverse) instead of terminal 10 will change the sign
of the selected speed such that a positive preset speed will become negative
for reverse rotation.
42
Enable
Run Forward
closed
closed
closed
closed
closed
closed
closed
closed
Figure 6.6 Terminal connections
Enable
Run Forward
closed
closed
closed
closed
closed
closed
closed
closed
Reference
Remote speed ref. (A2)
Preset speed 2 (parameter 12)
Preset speed 3 (parameter 13)
Preset speed 4 (parameter 14)
Speed Reference
Preset speed 1 (Parameter 11)
Preset speed 2 (Parameter 12)
Preset speed 3 (Parameter 13)
Preset speed 4 (Parameter 14)
Commander SE User Guide
Issue Number 5
