Control Board

UP
DOWN
1
Remove the camera's dome cover to access
the camera module and OSD joystick.
2
Use the Joystick to control the camera's OSD options.
3
The camera has a manual IR switch, located under
the camera's lens. You can use this switch to
manually turn the IR LED board on or off according to
the installation needs.
ON/OFF
