OSD Menu
Exposure
_
EXPOSURE
LENS
3
BACKLIGHT
DRC
4
DEFOG
AGC
5
STARLIGHT
6
3D DNR
EXIT JUMP
7
3
DRC ( DYNAMIC RANGE COMPRESSOR )
DRC enables dark areas in images to become more visible without overexposing the bright areas to create
one perfect image. Select from : OFF / LOW / MIDDLE / HIGH
4
DEFOG
Allows the camera to process a scene that is obscured by fog or weather conditions and provides a visibly
improved image. AUTO / Manual : Select AUTO to have the WDR and DRC levels adjusted automatically.
Set the DEFOG level from LOW / MIDDLE / HIGH.
5
AGC ( AUTO GAIN CONTROL )
0~10 - AGC enhances the picture brightness in low light conditions. A higher level AGC setting makes
the images brighter, however, it could increase the amount of noise.
6
STARLIGHT
OFF / x2 ~ x32(Default: X4) - Automatically activates slow shutter function when the image is too dark.
7
3D DNR ( 3D DIGITAL NOISE REDUCTION )
OFF/LOW/MIDDLE/HIGH - 3D-DNR reduces the noise on the screen in low light conditions and allows
AUTO
OFF
___
ON
10
X4
HIGH
High values are not recommended as they may causes the image to lag.
Starlight menu cannot be controlled if the SHUTTER setting is above 1/30.
for clearer images, even at night.
DEFOG
MODE
AUTO
LEVEL
____
RETURN
