Digital Watchdog Star-Light DWC-V7253WTIR User Manual page 17

OSD Menu Exposure
_
1
LENS
MANUAL : Manual mode supports the fixed board lens or the manual iris lens.
AUTO : AUTO mode sets the camera's iris automatically.
EXPOSURE
LENS
1
BACKLIGHT
DRC
DEFOG
AGC
STARLIGHT
3D DNR
EXIT JUMP
Under the LENS sub-menu, you can adjust the following settings:
1. Level
Change the camera's iris value manually. If AUTO is selected, this option is disabled.
2. Brightness
Adjust the camera's brightness from 0~20. The higher the number, the brighter the image will appear.
3. Shutter
Set the shutter speed to AUTO, Manual, or FLC (Flicker-less mode).
* If AUTO is selected, select from the following options :
- NORMAL: Set when the camera is installed in an indoor environment.
- DEBLUR: Set when the camera is installed in an outdoor environment.
* Select FLC if the camera is experiencing some flickering in the image.
The shutter speed will be set to 1/100 for NTSC, or 1/120 for PAL.
* If Manual is selected, set the shutter speed from the options :
- 1/30(1/25) ~ 1/30000.
4. Focus Adjustment
When on, the default level is set automatically by controlling lens focus and based on
the installation and environment circumstances.
AUTO
OFF
OFF
OFF
10
X4
HIGH
LENS
LEVEL ___
BRIGHTNESS 10
SHUTTER AUTO
FOCUS ADJ OFF
RETURN
