THEATRE MASTER
PR-3010
This product manual contains important information about the safe installation and
use of this projector. Please read and follow these instructions carefully and keep this
manual in a safe place for future reference.
PR LIGHTING LTD.
Yingbin Road, Dashi Panyu, Guangzhou, 511430 China
h t t p : / / w w w . p r- l i g h t i n g . c o m

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Theatre Master PR-3010 and is the answer not in the manual?

Questions and answers

Related Manuals for PR Lighting Theatre Master PR-3010

Summary of Contents for PR Lighting Theatre Master PR-3010

  • Page 1 Please read and follow these instructions carefully and keep this manual in a safe place for future reference. PR LIGHTING LTD. Yingbin Road, Dashi Panyu, Guangzhou, 511430 China h t t p : / / w w w . p r- l i g h t i n g . c o m...

  • Page 2: Table Of Contents

    　 INDEX 　 SECTION PAGE SAFE USAGE OF THE PROJECTOR INSTALLING THE PROJECTOR FITTING THE LAMP POWER CONNECTIONS OPERATION STAND-ALONE MODE XLR CONNECTIONS AND TERMINATOR CONTROLLER MODE – DMX 512 OPERATION MAINTENANCE KEEPING THE PROJECTOR CLEAN TROUBLESHOOTING TECHNICAL DATA ELECTRICAL DIAGRAME Please note that as part of our ongoing commitment to continuous product development, specifications are subject to change without notice.

  • Page 3: Safe Usage Of The Projector

    SAFE USAGE OF THE PROJECTOR The following points are important for safety as well as for the smooth installation and performance of the unit. When unpacking and before disposing of the package check there is no transportation damage before using the projector. Should there be any damage caused by transportation, consult your dealer and do not use the apparatus.

  • Page 4: Installing The Projector

    INSTALLING THE PROJECTOR This unit has been designed to be hung. Mount the bracket provided on the body of the projector via 2 locking knobs, then suspend the projector via its bracket using a M12 size bolt and a nut. When you want to adjust the angle of the body of the projector, you only loosen the 2 locking knobs carefully and then adjust the angle of the body.

  • Page 5: Stand-Alone Mode

    STAND-ALONE MODE Without connecting the controller, regulating the DIP switch as shown below, the apparatus will run in stand- alone mode. In stand-alone mode, the projector will run automatically the built-in programmes. XLR CONNECTORS AND TERMINATOR 　 　 　 XLR CONNECTORS 　...

  • Page 6: Controller Mode - Dmx 512 Operation

    DMX TERMINATOR In the Controller mode or Master/Slave mode, the DMX output has to be connected with a DMX terminator at the last fixture in the chain. This prevents electrical noise from disturbing and corrupting the DMX control signals. The DMX terminator is simply an XLR connector with a 120Ω (ohm) resistor connected across pins 2 and 3, which is then plugged into the output socket on the last projector in the chain.
  • Page 7 TABLE FOR SETTING THE DIP SWITCHES Each unit must be given an address so that the correct projector responds to the correct control signals. The following table lists the setting codes of the address of the DIP switches, and the luminaires are from No.1 to No.128.

  • Page 8: Maintenance

    DMX CONTROL CHANNEL FUNCTIONS The Theatre Master has 4 channels. They are shown in the following table. DMX VALUE DESCRIPTION CHANNEL 1 Iris 0-255 Iris adjust from small to large 0-15 White 16-31 32-47 Yellow 48-63 Violet 2 Colour 64-79 Green 80-95 Orange...

  • Page 9: Troubleshooting

    　 TROUBLESHOOTING 　 　 PROBLEM RESOURCE The projector does not start Check that the fuse is not blown. Check that the lamp is ok. The projector switches on but does not Check the DIP switches are correctly set. answer to commands Check the XLR cable is good.

  • Page 10: Electrical Diagrame

    LIGHT OUTPUT 　 ELECTRICAL DIAGRAM 　 　 10/12 Theatre Master manual.doc...
  • Page 11 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 　 11/12 Theatre Master manual.doc...
  • Page 12 　 　 　 　 　 　 　 　 　 　 　 　 PR LIGHTING LTD. Yingbin Road, Dashi, Panyu, Guangzhou, China Post-Code: 511430 TEL: 020-8478-1888 FAX: 020-8478-6023 　 　 P/N: 320040026 Last Revision: 24:02:2004 　 　 12/12 Theatre Master manual.doc...
