  • Page 1 XPar 348 PR-8200 This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. PR LIGHTING LTD. http://www.pr-lighting.com...
  • Page 2 INDEX SAFE USAGE OF THE PROJECTOR INSTALLING THE PROJECTOR CONTROL SYSTEM AND POWER CONNECTIONS DMX TERMINATOR SETUP OPTIONS-PROJECTOR CONFIGURATION TO SET THE DMX START ADDRESS OPERATION MENU DMX PROTOCOL INDICATION OF LED DIGITAL TUBE MAINTENANCE TROUBLESHOOTING TECHNICAL DATA ELECTRICAL DIAGRAM COMPONENT ORDER CODES Please note that as part of our ongoing commitment to continuous product development, specifications are subject to change without notice.

  • Page 3: Safe Usage Of The Projector

    SAFE USAGE OF THE PROJECTOR When unpacking and before disposing of the carton, check there is no transportation damage before using the projector. Should there be any damage caused by transportation, consult your dealer and do not use the apparatus. The projector can be used indoors and outdoors, IP67.

  • Page 4: Control System And Power Connections

    Note: Care should be taken to ensure that none of the pins touch the metallic body of the plug or each other. The body of the plug is not connected in any way. The XPar 348 accepts digital control signals in protocol DMX512 (1990).

  • Page 5: Dmx Terminator

    All of the connections are as the figure below. POWER OUT POWER OUT DMX OUT DMX OUT POWER IN POWER IN TO TERMINATER TO MAINS POWER DMX IN DMX IN TO CONTROLLER DMX TERMINATOR In the Controller mode, at the last fixture in the chain, the DMX output has to be connected with a DMX terminator. This prevents electrical noise from disturbing and corrupting the DMX control signals.

  • Page 6: To Set The Dmx Start Address

    TO SET THE DMX START ADDRESS Each Xpar348 must be given a DMX start address so that the correct projector responds to the correct control signals. This DMX start address is the channel number from which the projector starts to “listen” to the digital control information being sent out from the controller.

  • Page 7: Operation Menu

    OPERATION MENU 1st LEVEL 2nd LEVEL 3rd LEVEL 4th LEVEL AddR （XXX:1~512） (DMX address) (Standard mode) (DMX mode) (Extended mode) SHRT (Short mode) dISP CNFG (Display settings) (Shut off digital CRT without (Config settings) pressing buttons in 5 minutes) SLAV mORS (Slave) (Master /Slave Settings)
  • Page 8 Number Colour RGBW Only when setting of “Number” submenu has been done and return to “ET XX” menu, corresponding colour effect comes out. You can choose numbers from Group COL1 to COL4 separately to form a user memory. 8/18...

  • Page 9: Dmx Protocol

    DMX PROTOCOL Short Standard Extended FUNCTION DESCRIPTION mode mode mode Dimmer 000-255 Dimming from dark to light Dimmer 16 Bit 000-255 Dimmer in 16 Bit precision Invalid Colour Temperature Colour temperature adjustment from 001-255 3200K to 10000K Invalid 001-015 Colour Temperature 3200K 016-031 Colour Temperature 5600K 032-047...
  • Page 10 096-111 Preset memory 7 112-127 Preset memory 8 128-143 Preset memory 9 144-159 Preset memory 10 160-175 Preset memory 11 176-191 Preset memory 12 192-207 Preset memory 13 208-223 Preset memory 14 224-239 Preset memory 15 240-255 Preset memory 16 Invalid 001-015 User memory 1...
  • Page 11 240-255 Speed 16, the slowest Note: **** Channel priority from high to low is as the following: preset memory, user memory, RGBW dimming, HSV dimming, macro channel; ****When high priority channel is used, low priority channel is invalid. 11/18...

  • Page 12: Indication Of Led Digital Tube

    INDICATION OF LED DIGITAL TUBE DMX signal OK Decimal point of the first digital tube No DMX signal Master / slave signal is OK Decimal point of the third digital tube No master / slave signal When setting master mode Decimal point of the fourth digital tube When setting slave mode Parameters that LED digital tubes display...

  • Page 13: Technical Data

    XPar 348 TECHNICAL DATA VOLTAGES: 100~240VAC, 50/60Hz POWER CONSUMPTION: 210W@220V LED: Power consumption Quantity 48 （12R＋12G＋12B+12W） Manufacturers rated lifespan 50000 Hours COLOURS: RGBW colours mixing Linearly colour temperature correction 10000K~3200K DIMMER: 0-100% linearly adjustable STROBE: 1~20F.P.S BEAM ANGLE: Field angle(1/10 peak) 28°...
  • Page 14 AMBINENT TEMPERATURE: -20°C~40°C WEIGHT: SIZES: See it below LIGHT OUTPUT: 28° lux 2066 (RGBW) 28° lux 28° lux 28° lux 28° lux DISTANCE(m) 28° 14.88 DIAMETER(m) 2.48 12.40 4.96 7.44 9.92...

  • Page 16: Component Order Codes

    COMPONENT ORDER CODES NAME PART NO. QUANTITY REMARK 070070040 14° LED LENS 120080030B 1.7m,male SIGNAL CABLE 120080031B 1.7m,female SIGNAL CABLE 120080032 0.3,male SIGNAL CABLE 120080033 0.3,fmale SIGNAL CABLE 120080034B 1.7m,male POWER CORD POWER CORD 120080035A 1.7m,female 120080040A 1.7m,female POWER CORD 192010135 POWER SUPPLY 230060081...
  • Page 17 17/18...
  • Page 18 PR LIGHTING LTD. PR New Hi-tech Science Park, 1582 Xingye Avenue Nancun Panyu, Guangzhou, 511442 China TEL: +86-20-3995 2888 FAX: +86-20-3995 2330 P/N: 320050013B Last Revision: 20100601 18/18...
