  • Page 1 XR440 BEAM PR-2464 The user manual contains important information about the safe installation and use of a projector. Please read and follow these instructions carefully and keep the manual in a safe place for future reference. PR LIGHTING LTD. http://www.pr-light ing.com...
  • Page 2 INDEX 1. SAFETY AND WARNINGS 2. INSTUCTIONS CLEANING AND MAINTENANCE ● LUBRICATION ● TROUBLESHOOTING ● 3. APPEARANCE 4. INSTALLATION RIGGING ● POWER CONNECTIONS ● DMX CONTROL CONNECTIONS ● DMX TERMINATOR ● ALIGNMENT/INSTALLATION/REPLACEMENT OF A LAMP ● GOBO/COLOR FILTER REPLACEMENT ● 5.

  • Page 3: Safety And Warnings

    1. SAFETY AND WARNINGS NOTE Before a projector’s installation, power-on, operation and maintenance, please carefully read the safety information hereinafter! The following safety signs are used in the user manual. Warning User Electrical Protective Flames High Goggles Manual shock Gloves Temperature When unpacking , check if there is transportation damage before using the projector.

  • Page 4: Cleaning And Maintenance

    There are safety cord holes at the bottom of the base of a projector. In view of safety, please run the safety ● cord supplied through the safety cord holes for safety support. Before any installation, maintenance and cleaning work, please ensure the projector is disconnected from ●...

  • Page 5: Troubleshooting

    TROUBLESHOOTING ● PROBLEM ACTION  Check the fuse on the power socket. The projector doesn’t switch on  Check the lamp.  The lamp is on but the projector doesn’t respond Make sure that the fixture’s start address is right ...

  • Page 6: Installation

    4. INSTALLATION RIGGING ● Before moving a projector, Please lock Pan and Tilt. Before its operation, please unlock them. It’s forbidden to run a projector with power while it is locked. Take 2 clamps and the safety cord out from the package and mount 2 clamps on the underside of fixture with 2 retainers attached to each clamp.

  • Page 7: Dmx Control Connections

    Note: care should be taken to ensure that none of the pins touch the metallic body of the plug or each other. XLR plugs and sockets mustn’t be connected in any way other than mentioned in the above figure. The XR440 Beam accepts digital control signals in protocol DMX512 (1990).

  • Page 8: Alignment/Installation/Replacement Of A Lamp

    ALIGNMENT/INSTALLATION/REPLACEMENT OF A LAMP ● Lock the yoke before fitting/replacing the lamp. Just as Shown by Figure 1, after opening the cover at the rear of the projector by loosening 4 fastfit screws, you can open the head. To adjust the lamp as per Figure 2. Take out the lamp as per the figure 3.

  • Page 9: Setup And Configuration

    5. SETUP AND CONFIGURATION Front Panel Operation ● W-DMX Projector configuration can be set conveniently via push button and LCD display. Launch the projector and press button ENTER for more than 2 seconds to unlock the panel, the LCD will show the function menu of the projector, each main menu has its submenus and each submenu has a specific function.

  • Page 10: Master/Slave Mode

    MASTER/SLAVE MODE ● Many projectors can run synchronously in the Master/Slave mode by linking them with each other. First, connect the first fixture’s DMX output to the second fixture’s DMX input using XLR-XLR control cable and then connect the second fixture’s DMX output to the third fixture’s DMX input, and so on until all projector are connected in this way.
  • Page 11 Color Positions STEPPED Color Positions Color Positions LINEAR F-Gobo Positions STEPPED F-Gobo Positions F-Gobo Positions LINEAR Pan DMX Invert Pan DMX Invert Pan DMX Invert Tilt DMX Invert Tilt DMX Invert Tilt DMX Invert Pan Tilt Swap Pan Tilt Swap Option Settings Pan Tilt Swap Dimmer Invert...
  • Page 12 Display Contrast Display Contrast XX(1~21) Lamp Hours Reset Lamp Hours Are You Sure(UP/DOWN) Total Hours Display Board= Display Board XX℃ Driver Board 1= Driver Board 1 XX℃ Driver Board 2= Driver Board 2 XX℃ Temperature Driver Board 3= Driver Board 3 XX℃...
  • Page 13 Factory Setup Factory Setup Factory Setup Test Modes Self Test Self Test Self Test Lamp Status S= X C= X Lamp On Lamp Manual Control Turn Lamp On Turn Lamp Off Wireless Mode XLR First Wireless Mode Wireless Only Wireless Mode Wireless Mode XLR Only Wireless Options...
  • Page 14 Motors’ Speeds XXX M Speed （000~255） Delay XX s Delay （0.25s~100min） Link To Step XXX（1~200） Shutters Shutters XXX Dimmer Dimmer XXX Slow Dimmer Slow Dimmer XXX CYM Macro CYM Macro XXX Cyan Cyan XXX Yellow Yellow XXX Magenta Magenta XXX Color Wheel Color Wheel XXX Fixed G-Wheel...
  • Page 15 Prism2 Rotation Prism2 Rotation Frost Frost XXX Focus Focus XXX Pan XXX Pan Fine Pan Fine XXX Tilt Tilt XXX Tilt Fine Tilt Fine XXX Motors’ Speeds Motors’ Speeds XXX（000~255） Reset User1 Unlock 2,3,4 （Press buttons 2,3.4,ie Reset User User memory 1 memory 1 buttons has been reset...
  • Page 16 7. DMX PROTOCOL Short Standard Extended FUNCTION DESCRIPTION mode mode Mode 000-010 Close Open 011-025 Strobe speed from slow to fast 026-225 Strobe Macro 1 226-239 240-241 Macro 2 242-246 Macro 3 Open 247-255 000-003 Close Dimmer Linear dimming （0-100%） 004-255 0-255 Dimmer Fine...
  • Page 17 Fixed Gobo 021-026 Gobo3/ Steering Wheel Wheel 027-033 Gobo4/ Quadrangles 034-040 Gobo5/ Eight 041-047 Gobo6/ Five Dots 048-053 Gobo7/ Stars 054-060 Gobo8/ Rectangles 061-067 Gobo9/ Flower 068-074 Gobo10/ 8 Bars 075-080 Gobo11/ 081-087 Gobo12/ Ping 088-094 Gobo13/ Dot6 095-101 Gobo14/ Dot5 102-107 Gobo15/Dot4...
  • Page 18 Rotation （clockwise From slow to Fast） 128-163 Reverse Rotation （ anti-clockwise From slow to Fast） 164-199 200-207 Shake of Gobo 1 from slow to fast 208-215 Shake of Gobo 2 from slow to fast 216-223 Shake of Gobo 3 from slow to fast 224-231 Shake of Gobo 4 from slow to fast 232-239...

  • Page 19: Led Indication

    8. LED INDICATION DMX signal OK DMX Indication No DMX signal Flash DMX signal error No wireless signal Not linked with any transmitter W-DMX Indication Being unlinked or being linked or no wireless signal by the Flash transmitter 9. ERROR MESSAGES During the reset, the control system will detect the errors and will display information below: Sensor Err S1-M3 Rotating gobo wheel rotation (1# drive board motor 3) error...

  • Page 20: Technical Data

    Check wiring and if the sensor works Tilt Sensor Error Tilt Sensor Error well Pan Over Temp Pan Over Temperature Pan Driver Fault Pan Motor Fault Tilt Over Temp Tilt Over Temperature Tilt Driver Fault Tilt Motor Fault Pan Enc Rev Err Pan Encoder wired wrong Check the wiring as per schematic Tilt Enc Rev Err...
  • Page 21 Code No. Color Wave Length 092550001 λ=620±5nm 092550002 Light Green λ=510/570±5nm 092550003 Blue λ=510±5nm 092550004 Cyan λ=540±5nm 092550005 Yellow λ=530±5nm 092550006 Magenta λ=450/630±5nm 092550007 Orange λ=600±5nm 092550008 Green λ=485/525±5nm 092550009 Dark blue λ=480±5nm 092550010 λ=460/690±5nm 092550011 Light Yellow λ=558±5nm 090071029 λ=550nm FIXED GOBO WHEEL 1 fixed gobo wheel: 18 gobos +open...
  • Page 22 090071031 090071032 090071033 090071034 090071035 P/N： P/N： P/N： P/N： P/N： 3 black circles Spun Dots Symmetric 3 Triangles Linear Gobo1 Gobo2 Gobo3 Gobo4 Gobo5 090071036 090071037 P/N： P/N： 4 Dots in a line Double T Gobo6 Gobo7 PRISM: 2pcs of independent prisms (STD setup: 8-facet and 16-facet Prisms):Bi-directional rotation with variable speeds(options: 3-facet, 16- facet, liner prisms) FROST : 1pc frost filter FOCUS: DMX linear Focus...
  • Page 23 Optional DMX512 Wireless Transmitter HOUSING: High temperature ABS, IP20 WEIGHT Net weight: 26Kg Gross weight: 81Kg in flight case(2pcs/case) and accessories 31Kg in carton(1pc/ctn) and accessories WORKING TEMPERATURE: -20°C～40°C SIZES: LIGHT OUTPUT: 23/27...

  • Page 24: Circuit Diagram And Pcb Connections

    11. CIRCUIT DIAGRAM AND PCB CONNECTIONS CIRCUIT DIAGRAM ● 24/27...

  • Page 25: Pcb Connections

    PCB CONNECTIONS ● 1.6-Channel SLAVE1：P/N 230060447 6-Channel Slave1 Signal Output Power Supply Fan Signal Input Ballast Fan HALL1-6 Magnet Sensor 24V Power Input HALL1-5 Magnet Sensor M1-1 Motor HALL1-4 Magnet Sensor M1-2 Motor HALL1-3 Magnet Sensor M1-3 Motor M1-4 Motor M1-5 Motor Thermal Switch #2 M1-6 Motor...

  • Page 26: Component Order Codes

    12. COMPONENT ORDER CODES NAME PART NO. QUANTITY REMARK 030040233A PAN MOTOR 030040233A TILT MOTOR 030040242 DIMMER/STROBE MOTORS 030040241 CYM MOTOR 030040244 ROTATING GOBO WHEEL MOTOR 030040073A FIXED GOBO WHEEL MOTOR 030040224A COLOR WHEEL MOTOR 030040073A GOBO ROTATION MOTOR 030040243 FOCUS MOTOR 030040221A FROST MOTOR...
  • Page 27 1582 Xingye Avenue, Nancun Panyu Guangzhou, 511442 China TEL: +86-20-3995 2888 PR lighting will try its best to offer accurate and overall information about a product’s technical data. Any changes won’t be notified if necessary. Patented Products. Counterfeiting Will be Prosecuted! P/N: 320020348 Version: 20161217 (Preliminary）...
